Spike 78-2600-R Installation Instructions

READ AND UNDERSTAND THESE INSTRUCTIONS COMPLETELY BEFORE INSTALLATION TO
AVOID INJURY TO YOURSELF, DAMAGE TO THE VEHICLE OR ACCESSORY.
• Torque specifications must be followed when tightening bolts. Over-tightening any and/or all screws will cause
• As specified on carton label, once protective film on shields is removed, product cannot be returned.
• As specified on carton label, damage caused by packaging staples is not covered by warranty. All staples must be
• ANY cutting, trimming, drilling or altering of this product as delivered is not covered under warranty.
• Failure to follow these installation instructions completely may void any warrantable components and result in
• Do not use Loctite/Super Glue or any other similar fastener adhesive. These types of products react to plastics
• Our windshields are made from the highest quality material providing optimum transparency and clarity.
Blurriness and/or extrusion marks may or may not appear when looking through windshield from a wide, side-
• The application of improper cleaners, abrasive and/or dirty cleaning towels can severely damage the product.
Failure to follow cleaning recommendation (provided herewith) may void any warrantable components.
These instructions contain important information for future reference and must be given to the customer at time of
ITEM
A
B
C Co-extruded bulb seal (¼")
INSTRUCTION
D
BAG
1. Installation
a) Find a clean flat area where you can safely lay down the
windshield (Item A). Partially remove the protective film
on both sides and apply the co-extruded bulb seal (Item C)
using manual pressure to ensure good adhesion and cut
any excess.
78-2600-R - Instructions MAVERICK TRAIL-SPORT-COMMANDER Vent Rear Windshield - rev00
CANAM MAVERICK TRAIL/SPORT & 2021 COMMANDER
IMPORTANT NOTICES
• For proper installation, TWO people are required .
cracks around mounting holes which is not covered by any warranty.
removed prior to removing product from carton.
product damage or personal injury.
and cause cracking. Not covered by any warranty.
angle. This is normal for all extruded clear plastic materials.
purchase or upon completion of installation.
Parts List
(parts available with kit only and not available separately)
PART NAME
Windshield
Vent assembly
Windshield Hardware
Co-extruded bulb seal ¼"
(+/- 83")
INSTALLATION INSTRUCTIONS
REAR WINDSHIELD - VENT
PART # 78-2600-R
DEALER
CNC windshield cut-out made of ⅛" thick GE polycarbonate or equivalent
Includes: 1 vent cover, 1 vent flap assembly, 1 rubber vent seal and 7 vent mounting screws
Includes: 84" Co-extruded bulb seal (¼") / #77-95BS [end user to cut to exact length]
Includes: 4 metal plate hooks, 4 phillips truss head screws M6 x 20 and 4 plastic shoulder
DESCRIPTION
washers M6
www.spikepowersports.com / 888-769-2295
QTY
1
1
1
1
1
