SPA CONTROL UNIT PANEL
F
A
E
On/Off Button:
buttons. The light next to the button is green when activated. Press this button to turn off all
currently activated functions.
NOTE: The On/Off button may appear as a black button in the center of the control panel.
Heat Button:
until the water temperature reaches the set temperature. When the spa water temperature drops
1-2°C (1.8-3.6°F) below the set temperature the heating system will restart. When the fl ame
icon on the display is red, the heating system is activated. When the fl ame icon turns green,
the water is at the set temperature. The heating system is at rest and the fi ltration system will
continue working nonstop.
NOTE: To stop the fi ltration system while the heater is at rest mode, press the fl ame button fi rst
and then the fi lter button. Pressing the fl ame button only while the heater is at rest mode will
turn off the heating system only and the fi ltration system will operate for another 1 minute before
it turns off automatically.
IMPORTANT: The following conditions will lead to slow water heating.
• The ambient temperature is lower than 10ºC (50ºF).
• Outdoor wind speed is above 3.5-5.4 m/s (8-12 mph).
• The air bubble function is activated when heating the spa water.
• The spa is not properly covered with the spa cover when the water is heating.
Celsius/Fahrenheit Toggle button:
The temperature can be displayed in either Fahrenheit or Celsius. The system's default is
Celsius.
NOTE: The default temperature is 20°C (68°F). Temperature adjustment ranges from 10°C (50°F)
to 40°C (104°F).
Temperature Adjustment Buttons:
buttons will cause the LED to fl ash. When fl ashing you can adjust to the desired temperature
setting. If you hold these buttons down the values will rapidly increase or decrease. The new
and desired temperature setting will remain on the LED display for 5 seconds to confi rm the new
value.
Water Filter Button:
display is green when activated and fl ashing 002H which is the minimum preset operating hours.
Press again to increase the preset time from 002H, 004H to 006H. Pressing the button after the
maximum number of hours (006H) will turn off the fi lter pump and the LED display shows the
spa water temperature. If you have selected too many hours keep pressing to repeat the cycle.
Once the operating time is set, the LED display will stop fl ashing after 10 seconds and the fi lter
pump starts working. The cycle repeats itself at the same time each day for the number hours
selected.
If the heating system and the sanitization system are activated, they will override the fi lter pump
preset time function.
To view the preset time while the fi lter pump is operating, press
fl ash the preset hours for 10 seconds and then display back the remaining operating hours. To
adjust the preset time, press
steps.
NOTE: the built-in hard water treatment function works automatically in conjunction with the
fi ltration system.
S AVE THESE INSTRUCTIONS

OPERATION

Once the unit is plugged in, use this button to active the control unit panel
Use this button to activate the heating system. The pump will heat the spa water
Pressing the Temperature Increase or Decrease
This button turns the fi lter pump on and off . The water fi lter icon on the
button twice until the display is fl ashing and repeat previous
(363IO) SPA ENGLISH 7.5" X 10.3" PANTONE 295U 11/10/2023
A: On/Off Button
B
B: Heat Button
C: Celsius/Fahrenheit Toggle Button
C
D: Temperature Increase Button
E: Temperature Decrease Button
D
F: Water Filter Button
button, the display will briefl y
