Blue Ridge Blaze / Western Blaze 18" on DGSS Burner

STEP 1. Place 2 brick risers at back of grate as shown here.

STEP 2. Place the back log H-0637 on top of the brick risers. Place log H-0808 as shown below.

Then place logs H-0811 & H-0810 on the ﬂoor in front of the grate.

H-0637

H-0808

H-0811

H-0810

STEP 3. Place the right log H-0800 & H-0803 as shown below.

H-0803

H-0800

Need help?

Do you have a question about the Blue Ridge Blaze and is the answer not in the manual?

Questions and answers

Summary of Contents for Heatmaster Blue Ridge Blaze

Page 1 Blue Ridge Blaze / Western Blaze 18” on DGSS Burner STEP 1. Place 2 brick risers at back of grate as shown here. STEP 2. Place the back log H-0637 on top of the brick risers. Place log H-0808 as shown below.
Page 2 Blue Ridge Blaze / Western Blaze 18” on DGSS Burner STEP 4. FIRST, place log H-0806. Then place log H-801 as shown below. H-0806 H-0801 STEP 5. FIRST, place log H-0804. Then place log H-0802 as shown below. H-0802 H-0804...
Page 3 Blue Ridge Blaze / Western Blaze 18” Logs H-0637 Brick riser A-0305 x 2 H-0808 H-0806 H-0804 H-0800 H-0810 H-0801 H-0811 H-0803 H-0802...
Page 4 Blue Ridge Blaze / Western Blaze 24” on DGSS Burner STEP 1. Place 2 brick risers at back of grate as shown here. STEP 2. Place the back log H-0809 on top of the brick risers. Then place logs H-0811 & H-0810 on the ﬂoor in front of the grate.
Page 5 Blue Ridge Blaze / Western Blaze 24” on DGSS Burner STEP 5. Place logs H-0802 & H-803 as shown below. H-0802 H-0803 STEP 6. Place logs H-0804 & H-801 as shown below. H-0804 H-0801...
Page 6 Blue Ridge Blaze / Western Blaze 24” Logs H-0809 Brick riser A-0305 x 2 H-0815 H-0808 H-0806 H-0805 H-0804 H-0807 H-0800 H-0810 H-0811 H-0801 H-0803 H-0802...
Page 7 Blue Ridge Blaze / Western Blaze 30” on DGSS Burner STEP 1. Place 2 brick risers at back of grate as shown here. STEP 2. Place the back log H-0631 on top of the brick risers. Place logs H-0815 & H-0808 as shown below.
Page 8 Blue Ridge Blaze / Western Blaze 30” on DGSS Burner STEP 5. Place logs H-0802 as shown below. H-0802 STEP 6. Place logs H-0803, H-0804 & H-0801 as shown below. H-0804 H-0803 H-0801...
Page 9 Blue Ridge Blaze / Western Blaze 30” Logs H-0631 Brick riser A-0305 x 2 H-0815 H-0808 H-0806 H-0805 H-0804 H-0807 H-0800 H-0810 H-0811 H-0801 H-0803 H-0802...
