Heatmaster Seamless remote Manual

Seamless remote summary guide.
MODES
There are 3 different operational MODES you can select on your Seamless remote.
*To change MODES, press the MODE button which will display the mode you are operating to at the bottom of
the LCD screen 'MANUAL' 'FLAME' or 'AUTO'
MODE
FLAME
MANUAL
(Thermostat)
AUTO
(Automatic program)
Flame & Fan LEVELS
There are three set LEVELS (flame and fan combinations) the Seamless operates at:
LEVEL
1
2
3
Power flue fan always operates
Description
The unit will operate on FRONT BURNER only.
•
To change ROOM FAN SPED, use the arrow buttons.
•
ROOM FAN SPEEDS are indicated by the number 1, 2 next to the
flame icon.
The unit will work towards your desired temperature set on your thermostat
remote.
•
When desired temperature is greater than 2° of the room
temperature the unit will operate on LEVEL 3 with the front and back
burners and FAN speed 2
•
When desired temperature is within 2° of the room temperature the
unit will operate on LEVEL 2 with the front burner and FAN speed 1
•
When desired temperature is 2° over room temperature the unit will
operate on LEVEL 1 with front burner only and ROOM FANS off.
•
When room temperature drops 1° below desired temperature the
FAN Speed will turn back on to speed 1 and go through the above
steps again
The unit will operate to a set Burners and FAN SPEED at a set time. See
remote manual for programming your own set times, alternatively the remote
comes pre-programmed with the following settings:
Time Period Start Time
Period 1 6.00 am
Period 2 8.30 am
Period 3 5.00 pm
Period 4 10.30 pm
Flame
FRONT BURNER
FRONT BURNER
FRONT AND BACK BURNER
Heatmaster Pty Ltd
Email: sales@heatmaster.com.au
Website: www.heatmaster.com.au
ACN 006 442 717 ABN 64 641 709 587
Main Showroom & Display
Address: 2/9 Nicole Close
Bayswater Victoria 3153
Telephone: (03) 9761 7130
Facsimile: (03) 9761 7134
Desired Temperature.
20 °C
15 °C
21 °C
15 °C
Fan speed
OFF
1
2
