Furuno FCV-600 Manual

Furuno FCV-600 Manual

Remote display by apps
Hide thumbs Also See for FCV-600:

Advertisement

Table of Contents

Remote Display by Apps
1.
Remote Display by Apps
2.
Getting Started
3.
TZ iBoat App
3.1.
Getting Fish Finder Module
3.2.
Available Functions
3.3.
Screen Gallery
4.
NavNet Viewer App
4.1.
Getting Fish Finder Module
4.2.
Available Functions
4.3.
Screen Gallery
5.
Notes
5.1.
Connectable Quantity of Devices
5.2.
Recommended Software Version of
FCV-600 and FCV-800
Number of Pages: 11
Date: April 9, 2024
INDEX
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FCV-600 and is the answer not in the manual?

Questions and answers

Related Manuals for Furuno FCV-600

Summary of Contents for Furuno FCV-600

  • Page 1 Getting Fish Finder Module Getting Started 4.2. Available Functions TZ iBoat App 4.3. Screen Gallery 3.1. Getting Fish Finder Module Notes 3.2. Available Functions 5.1. Connectable Quantity of Devices 3.3. Screen Gallery 5.2. Recommended Software Version of FCV-600 and FCV-800 NavNet Viewer App...
  • Page 2 The FCV-600 and FCV-800 with a built-in Wireless LAN allow for the connection of a second display, such as a second FCV-600 or FCV-800 display, an iPhone/iPad with the TZ iBoat app, or Android devices with the NavNet Viewer app.

  • Page 3: Overview Of Apps

    Section 4.2 for NavNet Viewer app for available operation and settings. (4) Points entered on TZ iBoat app will not be transferred to the FCV-600/800. Points entered on the FCV-600/800 will not be transferred to TZ iBoat app. (5) Echoes will be digitally enlarged on Landscape orientation with NavNet Viewer app.

  • Page 4: Getting Started

    2. Getting Started Option 1 – Set up the FCV-600 or FCV-800 as an access point for smart devices to be used. Option 2 – Connect both FCV-600/800 and smart devices to a common access point. Option 1 Option 2 (1) Access [Menu] –...

  • Page 5: Available Functions

    [✔], as well as the Fish icon available on the plotter screen. 3.2. Available Functions Highlight Clear images from the FCV-600/800 are visible on iPhone/iPad. ACCU-FISH™ and Bottom Discrimination functions are supported. (Compatible transducers are required on the FCV-600/800.) Operation and settings are available on the TZ iBoat app.

  • Page 6: Fish Finder Menu

    Clutter (for manual gain ✓ ✓ only) E.g., [Settings] Auto Gain Offset ✓ ✓ – [Fish Finder] ACCU-FISH Icon ✓ ✓ : Individual settings available ✓ (Sync.) : Settings synchronized with FCV-600/800 (no individual settings) : No settings available on TZ iBoat app...
  • Page 7 3.3. Screen Gallery General (iPhone) Left: Single Frequency Color: White Color Expand: ON Middle: Single Frequency Color: Green Color Expand: ON Right: Dual Frequency Color: Green Color Expand: ON ACCU-FISH™ and Bottom Discrimination (iPhone) Left: Single Frequency Color: White Color Expand: ON Right: Dual Frequency Color: White...
  • Page 8 Left: ACCU-FISH™ icon tapped: Fish depth and size shown on a data box. Right: Screen tapped: Cursor information including Bottom Discrimination data shown on a data box. Landscape (iPhone) Left: Single Right: Dual Point Entry (iPad) Left: Screen tapped Right: Point entered Tips: Landscape vs.
  • Page 9 (3) NavNet Viewer app supports single frequency screen mode only, i.e., NO dual screen mode. When the FCV-600/800 is in dual frequency mode, HF or MF echoes are shown on NavNet Viewer app. When the FCV-600/800 is in zoom mode, the right-side screen for full range echoes is shown on NavNet Viewer app.
  • Page 10 4.3. Screen Gallery General Left: Fish Finder echoes only Right: ACCU-FISH™ icons overlay Note: In landscape orientation, echoes will be enlarged in width. Adjustment Left: Gain Middle: Clutter Right: Auto Gain Offset...

  • Page 11: Number Of Devices

    5.2. Recommended Software Version of FCV-600 and FCV-800 When utilizing the TZ iBoat app and NavNet Viewer app, be sure to use FCV-600 and FCV-800 software v2.05 and later. --- END --- - All brand and product names are registered trademarks, trademarks or service marks of their respective holders.

This manual is also suitable for:

Fcv-800
