- Page 1 Installation & Operating Instructions Finnische sauna: J60130 | J61130...
-
Page 2: Safty Instruction
(3) Children over 6 years old can only use the sauna under the supervision of adults, (4) If you feel uncomfortable when using the infrared cabin, stop immediately and contact your doctor. 2. TECHNICAL DATA Modell J60130 | J61130 Kabinenmaterial Spruce Länge... -
Page 3: Part List
3. PARTLIST NAME Floor panel Ceiling panel Left panel Right glass window Left frame batten of right panel Right frame batten of right panel Upper frame batten of right panel Lower frame batten of right panel Fixing battens of right glass 4pcs/set Rear panel Left frame batten of front panel... -
Page 4: Installation Site
Rear part of oven guard Glass door Front glass window Fixing battens of front glass 3pcs/set Hinge Door handle Bucket & Ladle Thermometer Sand timer Sauna stone Glass seal Screw M3.5*30 Screw M6*100 4. MONTAGEANLEITUNG 4.1 INSTALLATION SITE (1) The flat and firm ground indoor, (2) dry and moisture-resistant, (3) 230V or 400V power supply with ground wire. - Page 5 (3) Put Left panel next to Floor panel, and connect it to Rear panel properly with preset Outside buckles. (4) Assemble the frame of right panel with Screws M6*100, Then install it next to Floor panel, and connect it to rear panel properly with preset Outside buckles. Fixing battens 4pcs/set and Screws M3.5*30 Install the Right glass window with...
- Page 6 (6) Screw Bench supporting panel to Rear panel (7) Place Benches on the preset and Floor panel with Screws M3.5*30. battens of installed panels, (8) Assemble the frame of front panel with Screws M6*100, then install it next to Floor panel, and connect it to Left/Right panel properly with preset inside buckles. (9) Install the Front glass window with Fixing battens 3pcs/set and Screws M3.5*30...
- Page 7 (10) Install Glass door by screwing the pre-installted (11) Install Door handle. hinges to front frame. (12) Assemble Oven guard with Screws M3.5*40. (13) Install sauna oven on the fence according to oven manual. (14) Place Ceiling panel on the installed panels (15) Install the wooden lamps by preset hooks, and plug in the cable connectors on roof.
- Page 8 4.3 LAMP CABLE CONNECTION Make the lamp cables through the preset roof holes, and plug the connectors: 4.4 OVEN CABLE CONNECTION type H07RN-F or its equivalent. (1) Use the rubber cable for the oven: (2) please read the oven manual carefully before oven cable installation. (3) Install the oven cable by an electrician.
- Page 9 (4) Do not use chemical cleaning agents to clean the cabin, (5) Please tighten the screws of the bench and glass every three months, avoid loosening or falling. 5.2 GARANTIEKARTE Finnische Sauna: J60130 | J61130 Holz: Hemlock Strahler: Sauna ofen Nennspannung:230Volt/380Volt...
