DC Electronic Load
PEL-3000(H) Series
QUICK START GUIDE
GW INSTEK PART NO. 82EL-31110MD1
ISO-9001 CERTIFIED MANUFACTURER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PEL-3000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GW Instek PEL-3000 Series

Summary of Contents for GW Instek PEL-3000 Series

  • Page 1 DC Electronic Load PEL-3000(H) Series QUICK START GUIDE GW INSTEK PART NO. 82EL-31110MD1 ISO-9001 CERTIFIED MANUFACTURER...
  • Page 2 This manual contains proprietary information, which is protected by copyright. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will Corporation. The information in this manual was correct at the time of printing.

  • Page 3: Afety Instructions

    AFETY INSTRUCTIONS This section contains the basic safety symbols that may appear on the accompanying User Manual CD or on the instrument. For detailed safety instructions and precautions, please see the Safety Instructions chapter in the user manual CD. Safety Symbols These safety symbols may appear in the user manual or on the instrument.
  • Page 4 Power Cord for the United Kingdom When using the instrument in the United Kingdom, make sure the power cord meets the following safety instructions. NOTE: This lead/appliance must only be wired by competent persons. WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in this lead are coloured in accordance with the following code: Green/ Yellow: Earth...

  • Page 5: Etting Started

    ETTING STARTED The Getting Started chapter introduces the instrument’s main features, appearance, and set up procedure. Overview The PEL-3000(H) Series is a family of high performance DC electronic loads positioned to test a wide range of different power sources. The DC electronic loads are fully programmable to simulate anything from basic static loads to complex dynamic loads.
  • Page 6 High capacity when used in • parallel: 5250W, 1050A(262.5A), PEL-3111(H) x 5) 9450W, 1890A(472.5A), PEL-3111(H) + PEL-3211(H) x 4) • High resolution – 16 bit • 7 operating modes: CC, CV, CR, Features CP, CC+CV, CR+CV, CP+CV • Independent and parallel operation •...
  • Page 7 Package Contents and Accessories Standard Accessories Item Part Number User /Programming Manual CD Quick Start Guide (this document) Load input terminal Cover, M3 PEL-011 screw x1 Terminal fittings: 2 sets of PEL-012 bolts/nuts/springs/washers (type: M8), terminal cover x1 (for PEL- 3000H series only), monitor out cover x 1(for PEL-3021H, PEL- 3041H, PEL-3111H only)
  • Page 8 Rack mount frame for PEL- GRA-414-J 3021(H), PEL-3041(H), PEL- 3111(H)/JIS GPIB cable, 2.0m GTL-248 USB cable. Type A - Type B GTL-246 Dust filter PEL-010 CR123A 3V lithium battery for 3813-030D0501 clock. Connect Cu Plate PEL-005 Connect Cu Plate PEL-006 Connect Cu Plate PEL-005 Connect Cu Plate...

  • Page 9: Front Panel

    Front Panel PEL-3021 and PEL-3041 Local Main File FUNC Utility Help Short Load Preset Shift CAL. Lock Clear Enter 175W 1.5 - 150V 0 - 35A I MON OUT TRIG OUT PEL-3021H and PEL-3041H Local Main File FUNC Utility Help Short Load A/ B...
  • Page 10 PEL-3111 Local Main File FUNC Utility Help Short Load Preset Shift I MON TRIG CAL. Lock 1050W 1.5 - 150V Clear Enter 0 - 70A PEL-3111H Local Main File FUNC Utility Help Short Load Preset Shift CAL. Lock 1050W 5 - 800V Clear Enter 0 –...

  • Page 11: Rear Panel

    Rear Panel PEL-3021 and PEL-3041 FRAME CONT WARNING TO AVOID ELECTRIC SHOCK THE POWER CORD RS232C PROTECTIVE GROUNDING CONDUCTOR MUST BE CONNECTED TO GROUND. NO OPERATOR SERVICEABLE COMPONENTS INSIDE. DO NOT REMOVE COVERS. REFER SERVICING TO QUALIFIED PERSONNEL. GPIB 100 - 120 VAC 200 - 240 VAC 47 - 63 Hz 90 VA MAX.

  • Page 12: Exhaust Fan

    PEL-3111 Local Main File FUNC Utility Help Short Load Preset Shift 1050W I MON TRIG CAL. Lock 1.5 - 150V Clear Enter 0 - 70A PEL-3111H PEL-3211 Booster Pack PEL-3211H Booster Pack Description 1. Frame control ports, J1, J2 2. Remote sense inputs 3.

  • Page 13: Display Overview

    Display Overview RS232 LOAD 03/Sep/2012 0.000 0.00 0.000 CC A Value 0.000 CC B Value 0.000 Fine SlewRate 2500.00 mA/us A Value Mode I Range V Range Function Configure H 35A L 15V Static Description 1. Date and time 2. Main frame status panel 3.
  • Page 14 3. If the unit doesn’t turn on, press the ON/STBY key on the front panel.  The ON/STBY key will go from standby (red) to ON (green). 4. The unit will show the splash screen and then load the settings from when the unit was last powered down.
  • Page 15 Updating the Firmware The PEL-3000(H) allows the firmware to be updated by end-users. Before using the PEL-3000(H), please check the GW Instek website or ask your local distributor for the latest firmware. Before updating the firmware, please check the firmware version.
  • Page 16 Do not turn the load generator off or Warning remove the USB memory when the firmware is being read or upgraded. Conventions The following conventions are used throughout the user manual. Read the conventions below for a basic grasp of how to operate the PEL-3000(H) menu system using the front panel keys.
  • Page 17 Toggle Parameter or State Function/Item Mode Parameter or State This type of soft-menu icon has the function/item on the top of the label and the selected setting or mode on the bottom of the label. Repeatedly press the associated function key (F1~F5) to cycle through each setting.
  • Page 18 RS232 LOAD 03/Sep/2012 0.000 0.00 0.000 Parameter CC A Value 0.000 CC B Value 1.000 Fine SlewRate 2500.00 mA/us A Value Mode I Range V Range Function Configure H 35A L 15V Static 4. Press the Enter key again to finish editing the parameter value.
  • Page 19 Entering Alphanumeric Characters When renaming files, creating memos or notes, you will be required to enter alphanumeric characters when the character entry screen appears.  Only alphanumeric characters as well as space [ ], underscore [_] and minus [-] characters are allowed. 1.
  • Page 20 PECIFICATIONS The following are the basic specifications for the PEL- 3000(H) series. For detailed specifications, please see the user manual Rating Model PEL-3021(H) PEL-3041(H) PEL-3111(H) Voltage 0V-150V(0V/800V) Current 35A(8.75A) 70A(17.5A) 210A(52.5A) Min. Operating 1.5V at 35A 1.5V at 70A 1.5V at 210A Voltage (5V at 8.75A) (5V at 17.5A)
  • Page 21 L Range 0.233336S-4μS 0.46667S-8μS 1.40001S-24.24μS (4.28566Ω (2.1428Ω (714.27mΩ -250kΩ) /(H) -125kΩ) /(H) -41.6667kΩ) /(H) 17.5mS-0.3μS 35mS-0.6μS 105mS-2μS (57.1Ω-3.33MΩ) (28.5Ω-1.66kΩ) (9.52Ω-500kΩ) CV Mode Operating Range Model PEL-3021(H) PEL-3041(H) PEL-3111(H) H Range 1.5V-150V 1.5V-150V 1.5V-150V (5V-800V) (5V-800V) (5V-800V) M Range 1.5V-15V 1.5V-15V 1.5V-15V (5V-80V) (5V-80V)
  • Page 22 Slew Rate CR Mode Setting Range Model PEL-3021(H) PEL-3041(H) PEL-3111(H) H Range 250uA/μs 500uA/μs 1.602mA/μs -250mA/μs(H) -500mA/μs(H) -1.6002A/μs(H) 0.01400mA/μs 0.0280mA/μs- 0.0840mA/μs- -14.000mA/μs 28.00mA/μs 84.00mA/μs M Range 25uA/μs 50uA/μs 160.2uA/μs -25mA/μs(H) -50mA/μs(H) ~160.02mA/μs 0.001400mA/μ 0.00280mA/μs- (H)0.0840mA/μ s-1.4000mA/μs 2.800mA/μs s-8.400mA/μs L Range 2.5uA/μs 5uA/μs 16.02uA/μs -2.5mA/μs(H)
  • Page 23 EC Declaration of Conformity (PEL-3000 series) GOOD WILL INSTRUMENT CO., LTD. No.7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan PEL-3021, PEL-3041, PEL-3111 satisfies all the technical relations application to the product within the scope of council: Directive: 2014/30/EU; 2014/35/EU; 2011/65/EU; 2012/19/EU...
  • Page 24 EC Declaration of Conformity (PEL-3000H series) GOOD WILL INSTRUMENT CO., LTD. No.7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan PEL-3021H, PEL-3041H, PEL-3111H satisfies all the technical relations application to the product within the scope of council: Directive: 2014/30/EU; 2014/35/EU; 2011/65/EU; 2012/19/EU The above product is in conformity with the following standards or other normative documents: ◎...
