Renesas RA6T2 Application Note

Renesas RA6T2 Application Note

120-degree conducting control of permanent magnetic synchronous motor using hall sensors
Hide thumbs Also See for RA6T2:

Advertisement

Quick Links

Download this manual
120-degree conducting control of permanent magnetic
synchronous motor using hall sensors
For Renesas Flexible Motor Control Series
Abstract
This application note describes the sample program for a permanent magnetic synchronous motor drive with
120- degree conducting method using hall sensors based on Renesas microcontroller. This application note
also describes how to use the motor control development support tool, 'Renesas Motor Workbench'.
The targeted software for this application is only to be used as reference purposes only and Renesas
Electronics Corporation does not guarantee the operations. Please use this after carrying out a thorough
evaluation in a suitable environment.
Operation checking device
Operations of the target software of this application note are checked by using the following device.
・ RA6T2 (R7FA6T2BD3CFP)
・ RA6T3 (R7FA6T3BB3CFM)
・ RA4T1 (R7FA4T1BB3CFM)
・ RA8T1 (R7FA8T1AHECBD)
Target software
The following shows the target software for this application:
・ RA6T2_MCILV1_SPM_HALL_120_E2S_V110
・ RA6T3_MCILV1_SPM_HALL_120_E2S_V100
・ RA4T1_MCILV1_SPM_HALL_120_E2S_V100
・ RA8T1_MCILV1_SPM_HALL_120_E2S_V100
R01AN6843EJ0110 Rev.1.10
Jan 23, 2024
APPLICATION NOTE
Page 1 of 83
