RA8T1 Group
Renesas RA Family
RA8 Series
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corp. without notice. Please review the latest information published by
Renesas Electronics Corp. through various means, including the Renesas Electronics Corp.
website (http://www.renesas.com).
www.renesas.com
MCB-RA8T1 User's Manual
Rev 1.00 Jan 23, 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RA Series and is the answer not in the manual?

Questions and answers

Related Manuals for Renesas RA Series

Summary of Contents for Renesas RA Series

  • Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corp. without notice. Please review the latest information published by Renesas Electronics Corp. through various means, including the Renesas Electronics Corp.
  • Page 2 General Precautions in the Handling of Microprocessing Unit and Microcontroller Unit Products The following usage notes are applicable to all Microprocessing unit and Microcontroller unit products from Renesas. For detailed usage notes on the products covered by this document, refer to the relevant sections of the document as well as any technical updates that have been issued for the products.
  • Page 3 Renesas Electronics disclaims any and all liability for any damages or losses incurred by you or any third parties arising from the use of any Renesas Electronics product that is inconsistent with any Renesas Electronics data sheet, user’s manual or other Renesas Electronics document.

  • Page 4: Table Of Contents

    MCB-RA8T1 User’s Manual Renesas RA Family MCB-RA8T1 User's Manual Contents Overview ..........................3 Presupposition and precautions of this document .................. 3 Product Contents ........................4 Product Order Information ....................... 4 Hardware Configuration and Default Setting ................5 Hardware configuration ........................... 5 Block diagram ............................
  • Page 5 Renesas RA Family MCB-RA8T1 User's Manual Figure of contents Figure 2-1 Product contents ..........................4 Figure 4-1 CPU board block diagram ........................ 6 Figure 4-2 CPU Board Layout ........................... 7 Figure 4-3 Standoffs and Screws assembly ...................... 7 Figure 4-4 Default jumper pin/register setting of CPU board ................9 Figure 4-5 Board connection example ......................

  • Page 6: Overview

    Renesas RA Family MCB-RA8T1 User's Manual 1. Overview MCB-RA8T1 is a CPU board for motor control evaluation. By using this product in combination with an inverter board, motor control using RA8T1 can be easily performed. 1.1 Presupposition and precautions of this document 1.

  • Page 7: Product Contents

    Renesas RA Family MCB-RA8T1 User's Manual 2. Product Contents This kit consists of the following parts. 1. CPU Board (RTK0EMA5K0C00000BJ) x1 2. USB Cable x1 3. Screw x4 4. Standoff x4 Figure 2-1 Product contents 3. Product Order Information Product number to order MCB-RA8T1 : RTK0EMA5K0C00000BJ R12UZ0134EJ0100 Rev 1.00...

  • Page 8: Hardware Configuration And Default Setting

    Inverter board connector (2 pair)  USB connector for J-Link OB  USB connector for RA8T1  SCI connector for Renesas Motor Workbench communication  Through hole for CAN communication  20 pin through hole for Arm debugger  Pmod connectors (Type6A + Type2A/3A) ...

  • Page 9: Block Diagram

    Renesas RA Family MCB-RA8T1 User's Manual 4.2 Block diagram Figure 4-1 CPU board block diagram R12UZ0134EJ0100 Rev 1.00 Page 6 of 21 Jan 23, 2024...

  • Page 10: Board Layout

    Renesas RA Family MCB-RA8T1 User's Manual 4.3 Board Layout Figure 4-2 CPU Board Layout 4.4 Standoffs and Screws Before using this product, assemble the included standoffs and screws as shown below. Figure 4-3 Standoffs and Screws assembly R12UZ0134EJ0100 Rev 1.00...

  • Page 11: Jumper Pin Setting

    Renesas RA Family MCB-RA8T1 User's Manual 4.5 Jumper pin setting Default settings and functions of the jumper pins/registers are as follows. Table 4-2 Jumper pins/registers setting of CPU board for INV1/INV2 Function in use resisters INV1 INV2 Default setting *3 &...
  • Page 12 Renesas RA Family MCB-RA8T1 User's Manual Figure 4-4 Default jumper pin/register setting of CPU board R12UZ0134EJ0100 Rev 1.00 Page 9 of 21 Jan 23, 2024...

  • Page 13: Board Connection

    Renesas RA Family MCB-RA8T1 User's Manual 4.6 Board Connection Figure 4-5 show connection examples when using this product with the inverter board kit (product name: MCI-LV-1, model name: RTK0EM0000S04020BJ) and the communication board (product name: MC-COM, model name: RTK0EMXC90S00000BJ). Figure 4-5 Board connection example R12UZ0134EJ0100 Rev 1.00...

  • Page 14: Cpu Board Specification

    Renesas RA Family MCB-RA8T1 User's Manual 5. CPU Board Specification This section describes the specification of the CPU Board. Functions 5.1.1 Power supply When not connected to the inverter board, power should be supplied from the USB connector (CN11). When connecting to the inverter board, power supply from the USB connector or from the inverter board will be automatically selected.

  • Page 15: Inverter Board Connector

    Renesas RA Family MCB-RA8T1 User's Manual 5.1.5 Inverter board connector Two inverter boards can be connected to this board with CN1 and CN2, and the 2nd inverter board is connected with CN3 and CN4. The pin assignments of the connectors are shown in in Table 5-1, Table 5-2,Table 5-3,Table 5-4.
  • Page 16 Renesas RA Family MCB-RA8T1 User's Manual Table 5-3 2nd Inverter board connector (CN3) pin assignment Pin No. Pin Function RA8T1Pin Pin No. Pin Function RA8T1 Pin AGND - (AVSS) P000/AN100 AGND - (AVSS) P513/AN016 P001/AN101 P002/AN102 P003/AN104 (*) P806/AN018 (*)

  • Page 17: Serial Communication

    Figure 5-2 Connection for CPU board and inverter board 5.1.6 Serial communication For serial communication using Renesas Motor Workbench, the CPU board has SCI connector. Pin assignment for SCI connector is listed in Table 5-5. Table 5-5 SCI connector (CN8) pin assignment Pin No.

  • Page 18: Can Communication

    Renesas RA Family MCB-RA8T1 User's Manual Table 5-6 LED pin assignment RA8T1 port LED1 LED2 LED3 LED4 PA12 Output HIGH Output LOW PA14 Output HIGH Output LOW P606 Output HIGH Output LOW PA06 Output HIGH Output LOW 5.1.9 CAN Communication This product has through holes for CAN communication.

  • Page 19: Ra8T1 Pin Function List

    Renesas RA Family MCB-RA8T1 User's Manual 5.2 RA8T1 pin function list Table 5-10 RA8T1 pin function list Pin No. RA8T1 pin function Signal function P301/SD0DAT3 SDHI P304/SD0DAT0/TDATA3 SDHI,ARM debugger P306/SD0CD/TDATA1 SDHI,ARM debugger P308/SD0CLK/TCLK SDHI,ARM debugger P905/IRQ8 INV1 HALL_V P909 TP43...
  • Page 20 Renesas RA Family MCB-RA8T1 User's Manual Pin No. RA8T1 pin function Signal function P407/USB_VBUS P411 Pmod6A(GPIO) P410/GTIOC9B Smart Driver (INV1 EN)/HV1_PWM_PFC P414/CRX1 PA09/IRQ5 INV2 HALL_W P613/GTETRGA INV1 OverCurrent/Smart Driver (INV1 nFault)/HV1_OC_PFC P615/GTETRGC INV1 ENC_Z P610/GTIOC4A INV2 ENC_A PA13 INV1 SW2...
  • Page 21 Renesas RA Family MCB-RA8T1 User's Manual Pin No. RA8T1 pin function Signal function PB05 TP17 VSS1 AVCC_USBHS XTAL 24MHz EXTAL 24MHz VSS_DCDC VSS8 VCC8 P607 TP14 P813 TP46 VCC5 VSS5 VSS8 VCC7 PB02 PB06 TP19 PB07 TP21 VSS9 XCOUT XCIN...
  • Page 22 Renesas RA Family MCB-RA8T1 User's Manual Pin No. RA8T1 pin function Signal function P007/AN004 INV2 IPS_B# P805/AN017 INV2 VW/INV2 IPS_B P402/ET0MDIO Ether P406/RMII0TXD1 Ether P700/RMII0TXD0 Ether PB03 TP13 P100/MISOB Smart Driver (MISO) P801/IRQ12 INV2 HALL_V P803/GTIOC12B INV2 PWM_UL P604 INV2 SW1...

  • Page 23: Design And Manufacture Information

    MCB-RA8T1 User's Manual 6. Design and Manufacture Information You can obtain information on the design and manufacture of this product from renesas.com. 7. Website and Support In order to learn, download tools and documents, apply technical support for RA family MCU and its kit, visit the below Web site.

  • Page 24: Revision History

    Renesas RA Family MCB-RA8T1 User's Manual Revision History Rev. Date Description Page Summary 1.00 Jan 23, 2024 First edition R12UZ0134EJ0100 Rev 1.00 Page 21 of 21 Jan 23, 2024...
  • Page 25 MCB-RA8T1 User's Manual Publication Date: Rev 1.00 Jan 23, 2024 Published by: Renesas Electronics Corporation...
  • Page 26 MCB-RA8T1 User's Manual R12UZ0134EJ0100...
