CHAPTER 8
Colour Palette
This chapter discusses the colour palette. A colour may be specified by its name or number. The
following table provides a cross-reference between these. Some colour names made up of more than
one word are separated by an underscore or a hyphen. A specified colour can be changed in the CX-
Supervisor development environment for the current session; such changes cannot be saved to a Page
or Project, unless colours are changed from the Colour Palette located under the General Settings
submenu in the Project menu.
Using a 16 colour-based screen resolution (consult the Microsoft Windows documentation for further
information) colours 16 to 65 are dithered from the sixteen base colours. Higher colour-based
resolutions are not dithered.
Revision 2.0
No. Colour
0 black
1 blue
2 green
3 cyan
4 red
5 magenta
6 yellow
7 white
8 dark_blue
9 dark_green
10 blue-green
11 brown
24-65
CHAPTER 8 – Colour Palette
No. Colour
12 purple
13 olive
14 dark_grey
15 light-grey
16 pale-green
17 light-blue
18 off-white
19 grey
20 cherry
21 silver
22 apple
23 orange
Not used
