CHAPTER 6 – Functions and Methods

Vertical Fill

Syntax
objectname.vertical%fill (expression, context)
Remarks
Argument
objectname
expression
context
Typical Examples
vertical%fill (50)
The current object to which this example applies is filled by 50%.
ELLIPSE_1.vertical%fill (OIL_QUANTITY, @DOWN)
The object 'ELLIPSE_1' is filled provided the point 'OIL QUANTITY' returns a valid result,
between 0 and 100.
Visible
Syntax
objectname.visible (expression)
Remarks
Argument
objectname
expression
Typical Examples
visible (TRUE)
The current object to which this example applies becomes visible.
POLYLINE_8.visible (count AND flag)
Page 46
This is the name of the object. Where a script is directly attached to an
object, objectname is not required.
This is an arithmetic expression that must return a value between 0 and 100.
On return of a valid result, the fill commences from bottom to top.
This argument may be omitted. May be one of:
@DOWN – Fill object downwards
@UP – Fill object upwards
If omitted, @UP is assumed
This is the name of the object. Where a script is directly attached to an
object, objectname is not required.
The expression can be made up of points resulting in 'TRUE' or 'FALSE'.
Description
Description
