 Normal operating temperature is 0 ~ 40℃.
Humidity
 Do not expose machine in rain, damp or place near water.
 Ensure the indoor drying, cool.
Ventilation
 Keep the ventilation openings clear.
 Ensure that the unit has enough space for ventilation around: left, right and back >10cm, top> 20cm.
Earphone
 It will affect the hearing if you listen to noisy sound for a long time.
 Before using earphone, please turn down the volume in advance.

2. Installation

2.1. Bearing Capacity

If the product is installed in a wall-mounted way, the bearing capacity of the surface for installation must be at least
four times of the weight of the product. If the surface for installation is a wall or the ceiling of a building, the
surface must be made of solid bricks, concrete or other materials with equal intensity. If the product is installed on
a surface made of loose material such as an old brick wall, wood plank wall, solid brick wall, a metal or non-metal
structure surface, or a surface with a thick decoration layer, take necessary consolidating measures to ensure that
the product is stably installed.
Step1: Punching holes in the wall
Mark 8 holes location on the wall according to wall mounting bracket A and use the drill bit drilling the 8 holes.
Depth of holes not less than 90mm (Ref. Picture 1)
1
