01/24 MN048027EN
Manual
easyE Remote Touch
DisplayManual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the easyE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eaton easyE

Summary of Contents for Eaton easyE

  • Page 1: Easye Remote Touch Displaymanual

    01/24 MN048027EN Manual easyE Remote Touch DisplayManual...

  • Page 2: Company Information

    No part of this manual may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, micro-filming, record- ing, or otherwise, without the prior written permission of EATON. Subject to alteration.

  • Page 3: Before Starting With The Installation

    DANGER! Hazardous Electrical Voltage! Before starting with the installation   Installation requires qualified electrician desktop devices and portable devices only when   the housing is closed. Disconnect the power supply of the device.     Measures should be taken to ensure the proper Secure against retriggering  ...

  • Page 5: Table Of Contents

    Nameplate Support UL listing 1.10 Marine approvals Safety regulations Basics Mandatory requirements, personnel requirements 2.2.1 Occupational safety 2.2.2 Personnel qualifications 2.2.3 Device documentation 2.2.4 Installation, maintenance, and disposal 2.2.5 Prerequisites for proper operation Device-specific hazards easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 6 Preparing the device for operation 3.6.1 Power supply – electrical connection External connections USB interface Ethernet Commissioning Setup Wizard – Setting up the easyE Remote Touch Display Initial commissioning 5.2.1 Setting passwords 5.2.2 Setting a language 5.2.3 Access restrictions for the user groups...
  • Page 7 Cleaning Resistive Touch Display 10.2 Repairs 10.3 Storage, transport and disposal 10.3.1 Storage and transport 10.3.2 Disposal Appendix Technical data A.1.1 Data sheet A.1.2 Dimension and weight specifications A.1.3 Approvals and declarations Further usage information Alphabetical index easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 8 Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 9: About This Documentation

    0.1 About this documentation 0.1 About this documentation This Manual contains all the information you will need in order to use the easyE Remote Touch Display safely and effectively. The Manual easyE Remote Touch Display manual is considered an integral part of the devices and must always be readily available in the device's close proximity so that users have access to it.

  • Page 10: Target Group

    Remote Touch Display as an operating and monitoring device or as an integrated operating and control device in their own applications.

  • Page 11: Legal Disclaimer

    In particular, this information does not guarantee any particular properties. Do not use the easyE Remote Touch Display before reading and understanding this manual. Hazards posed by the RTD cannot be eliminated if the safety instructions are not observed –...

  • Page 12: Writing Conventions

    Warns about the possibility of material damage. Prohibited uses, actions, etc. Explains the prohibition Explains the instruction Notes Indicates useful tips. Indicates instructions to be followed Additional information, background information, information worth knowing, useful additional information easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 13 Documents (such as manuals) are listed after the icon together with the cor- responding name and Eaton number. Publication title For identifying the Eaton publication code External Internet addresses. They will be shown after the icon. Destination address easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 14 0.1 About this documentation easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 15: Description

    . It is possible to edit timer func- tion blocks using the easyE RTD Advanced​ . In addition to a visualization project file on the easyE RTD Advanced, this visua- lization requires an easyE4 control relay Generation 08 or higher with firmware≥...
  • Page 16 1. Description Engineering information The easyE RTD Standard can only be used to mirror the display of a connected easyE4 at the same time. It is possible to switch back and forth between several easyE4 basic devices.   The easyE RTD Advanced can only mirror the display of a connected easyE4 in the easyE4 mirroring device menu.

  • Page 17: Use As Intended

    The RTD devices are approved for use in closed spaces. The easyE RTD must be used only in locations for which the easyE4 is approved. Make sure to read and follow the information and labels on the nameplate for the RTD, as well as section Approvals and decla- rations in the appendix.

  • Page 18: Configuration Easye Rtd

    Ethernet protocol is only supported between easyE4 and RTD   One USB 2.0 host port for firmware updates and exporting log information, as well as the visualization project file for the easyE RTD Advanced. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 19: Operating And Indication Elements

    Color display, TFT Standard front with standard membrane (fully enclosed) Slot For microSD cards (for Eaton Service only). Not intended for use by customers. CTRL Pushbutton - → Section "Resetting the device to factory settings - Factory Settings", page 98 Available with FW ≧...

  • Page 20: Connections And Interfaces To Peripheral Devices

    24 VDC power supply (-20%/+25%)   Grounding option Connection lug 4.8 x 0.8 mm ② Ethernet RJ-45 socket, 8-pole, 2 LEDs (CAT5e/6), LAN1, 10/100 Mbps ③ USB host USB 2.0, not galvanically isolated, plug type A easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 21: What The Different Parts Of The Part Number Mean

    RTD Advanced 1.6 Accessory devices A variety of accessories are available for RTDs. ATTENTION Only use original accessories. Order accessories through your supplier or through the Eaton online catalog Eaton.com/ecat article no. Catalog Number 139808 ACCESSORIES-Res-Touch-Pen-10 Ten styli for using a resistive operator panel...

  • Page 22: Nameplate

    EPAS code (digital nameplate)   Power supply requirement   Serial-No.   MAC address   Type approval and certification marks and information   Layout of ports/interfaces and controls   Installation orientation Fig. 4: Example for a nameplate easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 23: Support

    To get fast and effective support, make sure to provide Customer Service with the fol- lowing information from the nameplate:   Part-No.   Serial-No For service and support, please contact your local sales team. Contact info. Eaton.com/contact Service page: Eaton.com/aftersales easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 24: Ul Listing

    The devices must be installed in a suitable fire protection enclosure that provides protection against the spread of fire. The torque used to tighten the screw terminals on the plug-in connection for the power supply must not exceed 0.22 ... 0.25 Nm. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 25: Marine Approvals

    1. Description 1.10 Marine approvals 1.10 Marine approvals The easyE RTD has been certified by Det Norsk Veritas. Obtained type approvals The RTD has the shipping classification for Det Norsk Veritas (DNV).   Tests performed according toDNV-CG-0339, Edition August 2021 "Environmental test specification for electrical, electronic and programmable...
  • Page 26 1. Description 1.10 Marine approvals easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 27: Safety Regulations

      Follow the safety instructions for the easyE RTD! The section on safety instructions must be read and understood by everyone who will be working with the RTD before the actual work is performed RTD.

  • Page 28: Device Documentation

    2.2 Mandatory requirements, personnel requirements 2.2.3 Device documentation This manual is considered an integral part of the easyE RTD and must always be rea- dily available in the device's close proximity so that users have access to it. Make sure that every person who will be working with the RTD, regardless of the life- cycle stage involved, has read and understood the relevant parts of the docu- mentation for the RTD.

  • Page 29: Prerequisites For Proper Operation

      Device failures or function disturbances   Improper use and/or handling   Not following the instructions or observing the information in the documentation for the RTD   Alterations, changes, and repairs to the RTD easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 30: Device-Specific Hazards

    Electrostatic discharges may damage or ruin assembly parts. Because of this, it is necessary to take precautions whenever hand- ling the cards. Please refer to the guidelines for electrostatic-sensitive components for more information (ESD guidelines). easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 31 If necessary, route an equipotential bonding conductor, with a cross-sectional area that is several times larger than that of the cable shielding, parallel to the cable. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 32 The mounting cutout must be located in a position that will not defeat the purpose of stabilizing webs or other reinforcing elements in the control panel. If necessary, reinforcing elements must be instal- led/added. An IP65 degree of protection will only be ensured if there is sufficient easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 33 RTD units are products designed for use in industrial environments as defined in ICE/EN 6100−6-4. These products can cause radio inter- ference in domestic environments. In this case, the party operating the products must implement appropriate radio interference sup- pression measures. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 34 2. Safety regulations 2.3 Device-specific hazards easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 35: Installation

    Electrostatic discharges may damage or ruin assembly parts. Because of this, it is necessary to take precautions whenever hand- ling the cards. Please refer to the guidelines for electrostatic-sensitive components for more information (ESD guidelines). easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 36: Prerequisites For The Location Of Use

    See also   → " Use as intended", page 17   Label on the → "Nameplate", page 22 The specifications in → "The environmental ambient conditions for operation must not exceed the specified values:", page 38. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 37: Installation Position

    Protect the Resistive Touch Display unit from direct sunlight and other sources of UV radiation.   Make sure that the RTD does not overheat.   The minimum clearance to components that radiate heat, such as transformers under heavy loads, is 15 cm. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 38: Temperatures

    Max. 2000 m above sea level Temperature   Operation ± 0 – +50 °C (+32 – +122 °F) Storage / Transport -20 – + 60 °C (-4 – +140 °F) Humidity Relative humidity 10 - 95 % Condensation non-condensing easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 39: Aeration And De-Aeration

    Ambient temperature with natural convection: ϑ: 0°C (32°F) ≦ T ≦ 50°C (122°F) The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data as necessary for design verification in conformity with IEC EN 61439 – please refer to the data sheet for the RTD in the online catalog at Eaton.com/ecat.

  • Page 40: Technical Conditions For Acceptance By Underwriters Laboratories Inc. (Ul)

    The devices must be installed in a suitable fire protection enclosure that provides protection against the spread of fire. The torque used to tighten the screw terminals on the plug-in connection for the power supply must not exceed 0.22 ... 0.25 Nm. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 41: Unpacking And Checking The Equipment Supplied

    Missing parts or damage If you notice anything wrong, please contact your distributor or Eaton Service +1 877-386-2273 (en) / 877-ETN-CARE (877-386-2273) The package for the RTD device comes with: Tab. 2: Std. pack...

  • Page 42: Mounting

    2 mm (0.08") ≦ d ≦ 5 mm (0.2") List of tools:   M2 Allen key, hex width across flats: 2 mm   PZ2 Pozidriv screwdriver   Torque wrench with Newton meter scale easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 43: Preparations

    The purpose of the holding brackets is to secure the RTD in the installation cutout, e.g., on the control panel door. To this end, the brackets must be hooked into the enclosure and screwed against the control panel door, etc. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 44 If the device is installed properly, the following IP degrees of protection will be ensured:   In the front: IP65 (at front) - not UL tested   In the back: IP20 (at rear) - not UL tested easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 45: Easye Rtd Mounting

    7. Check that the device is in its correct, centered position and that the gasket is in contact all around; adjust if necessary 8. Tighten the set screws in a criss-cross sequence with a max. torque of >0.08 ≦ 0.1Nm (>0.70 ≦ 0.86 lb-in). easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 46: Preparing The Device For Operation

    (PELV) set forth in ICE/UL 61010-2- 201. Pay attention to the polarity. WARNING The device should only be run with safety extra-low voltage (func- tional extra-low voltage with protective separation). The power transformer must conform to the relevant standards. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 47: Power Supply - Electrical Connection

    The required MC 1.5/ 2-ST-3.5 BK connector is included as standard. Tab. 3: Plug connection configuration MC 1.5/ 2-ST-3.5 BK   signal Configuration Power supply + 24VDC + 24 VDC SELV (safety extra low voltage)/PELV (protective extra low voltage) 0 V power supply easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 48 +24 V DC = 24 V DC (19.2 - 30 V DC) ≦ 0.3 A 2.5 mm 0.22 - 0.25 Nm (1.94 - 2.21 lb-in) +24 V Fig. 10: Connecting the screw terminals on the plug connector easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 49 60950 and – in connection with the UL listing – the requirements for a low- voltage source set forth in UL 61010-2-201, UL61010-1. The easyE Remote Touch Display is now ready to run on 24 VDC. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 50 3. Installation 3.6 Preparing the device for operation easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 51: External Connections

    4. External connections 4. External connections With its ports, Eaton's RTD makes it possible to connect a variety of peripheral devices and components. DANGER STRAY CURRENTS Large equalizing currents between the functional earthing system and the ground system of different devices may result in fire or in mal- functions due to signal interference.

  • Page 52: Usb Interface

    Do not connect the connector to the RTD or disconnect it without first de-energizing the system. Only use standard USB cables with a shield. Max. cable length: 5 m. USB host Fig. 12: USB 2.0, not galvanically isolated, plug type A easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 53: Ethernet

      Protect the RJ45 plug-in connection from strong vibrations.   Protect the RJ45 plug-in connection from tensile forces at the socket. Eaton recommends implementing measures for protecting against cyberattacks. Eaton cyber security Eaton.com/us/en-us/company/news-insights/cybersecurity.html Eaton.com/cybersecurity easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 54 4. External connections 4.2 Ethernet easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 55: Commissioning

    5. Commissioning 5. Commissioning When the easyE RTDs are used as intended, they will often be installed in a machine or system to function as controls and will be wired accordingly. In this case, the RTDs will need to be switched on and off using the corresponding machine controller.

  • Page 56: Setup Wizard - Setting Up The Easye Remote Touch Display

    When the Setup Wizard begins, you will have the option of importing an *.rtd visu- alization project. The configuration for the RTD and the visualization project for the easyE RTD Advanced can be imported independently of each other. In the case of brand new devices, this Setup Wizard will start directly by asking you to select the menu language you want.

  • Page 57: Initial Commissioning

    Repeat the steps above for the Operate password Repeat the steps above for the Administrate password After you set up the passwords, the Device information menu will appear. None of the user groups will be logged in at this point. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 58: Setting A Language

    After logging in, you can use the main menu ( ) to configure the remaining RTD system settings in the language you selected. You can save this RTD configuration in the *.rtd visualization project file → Section " Import / Export menu", page 86. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 59: Access Restrictions For The User Groups

          visualization Display Brightness Brightness Display easyE4 when Timeout monochrome dimmed mode   Administer This user group has no access restrictions and can access all device menus. → "Device menus ", page 65 easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 60 5. Commissioning 5.2 Initial commissioning easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 61: Running The Rtd

    6.1 Visualization 6. Running the RTD Once the easyE Remote Touch Display has been initially commissioned, it will run whenever it is connected to the power supply. In other words, it does not have to be separately switched on and off.
  • Page 62 Select the file you want from the list of available *.rtd files on the USB storage device. Press the Import button. As soon as the visualization project file parts have been loaded in the easyE RTD Advanced, the corresponding settings will be applied and a message will be shown.  ...

  • Page 63: Operation

    7.1 Handling easyE Remote Touch Display 7. Operation 7.1 Handling easyE Remote Touch Display To navigate on the easyE Remote Touch Display, operators can: Tap the button icons in order to open menus (e.g., Tap the arrows to move through pages within a menu.
  • Page 64 7. Operation 7.1 Handling easyE Remote Touch Display Fig. 15: Display in the RTD window Fig. 16: Full screen mode easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 65: Device Menus

    Brightness Brightness Display easyE4 when Timeout monochrome dimmed mode Update       Security Auto Logout Enable USB Enable USB   autostart Setup Wizard         Import / Export Import Export     easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 66: Login/Logout Menu

    Enable the field by tapping on it and enter the six- character password for the user group you selec- ted. User group Selection: Watch Operate Administrate Change button You can change the password for the selected user group by tapping the Change but- easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 67: Device Info Menu

    MAC address Page 2 Version information Image name   Image version   Bootloader Version Page 3 RTD information OS Version   easyE RTD Version   Host Name Page 4 RTD information Serial Number   Panel Name easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 68 RTD with the Show but- ton. The following are available: Authentication Log: Log for authentication at the operating system level SystemLog: Comprehensive log for all other system messages, including mounting external USB drives, hardware driver messages, and network events. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 69 You will need to update to the latest firmware version again. The visualization project will be deleted when this happens. Reboot device button Tapping this button will restart the RTD. None of the user groups will be logged in. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 70: Easye4 Mirroring Menu (Formerly Remote Easye4)

    The selected IP address will then be found in the address field. Tapping and holding a list entry will have the same effect as the SEL button. Fig. 23: easyE4 mirroring/Search easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 71 Back to previous default IP button Tapping the green button will enter the last IP address set as the default into the address field. You can then establish a connection to the easyE4 device by tapping the Connect but- ton. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 72 Fig. 25: easyE4 mirroring Exit screen button Tap the button to exit the menu page. Enabled only if there is a connection to the easyE4 device. See also   → Section " Automatic Start", page 76 easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 73: Easye4 Visualization Menu

    7.2 Device menus 7.2.4 easyE4 visualization menu available only for easyE RTD Advanced EASY-RTD-DC-43-03B2-00 This menu is used to start and display the visualization project. A connection will be established to the easyE4 configured in the visualization project. Access to the visualization can be optionally password-protected on top of the device Login/Logout.
  • Page 74 7. Operation 7.2 Device menus Fig. 26: easyE4 visualization example See also   → Section " Automatic Start", page 76 easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 75: Network Menu

    Page 6 Gateway To enter: Tap one of the number groups until the input assistance opens use the arrow buttons above and below the number groups to change the easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 76: Automatic Start

    For easyE4 mirroring, the Watcher or Operator user group can be logged in for this purpose for all RTDs. In addition, the easyE4 visualization device menu is available for the easyE RTD Advanced. For this selection, logging in requires the passwords that were assigned for the visualization project.
  • Page 77 If you do this, the base device's selectable backlight (white/red/green) will also be mirrored on the RTD.     Enable – The easyE4's background color will be kept monochrome in order to make it easier to see LED colors. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 78: Update Menu

    Fig. 30: Update Start update. A firmware update security prompt will appear. Confirm by tapping "Start update." You will need to restart the RTD after the update. Restart the device.   easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 79: Security Menu

    USB port. Default factory setting: Disabled Unmount All button Tapping this button will make the operating system cut access to all the par- titions on the USB drive that is plugged in.   easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 80: Setup Wizard Menu

    → Section "Connecting to the RTD", page 89 Familiarize yourself with how to use the RTD→ Section "Handling easyE Remote Touch Display", page 63. Fig. 32: Selecting a language for the wizard Recommendation: If you have already connected the easyE4, tapping Next will make the device search for available devices so that they will be available for selection.
  • Page 81 If a USB drive is not detected, a message to this effect will appear. As soon as the visualization project file parts have been loaded in the easyE RTD Advanced, the corresponding settings will be applied and a message will be shown.
  • Page 82 Fig. 38: Setup step 5 - IP address configuration For more information, please refer to: Network menu, → page 75. Select Auto-IP if the easyE4 is set up that way as well. Tapping the Next button will apply the network setting easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 83 The list with the easyE4 devices found will be offered for selection. Fig. 41: Setup step 5 - selecting an easyE4 If a name has been assigned to the easyE4 with easySoft, the name will be shown before the comma. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 84 Fig. 42: Setup step 6 - saving the setup configuration as an *.rtd file After this, you can connect the RTD directly to the easyE4. In order for this to work, the setting on the easyE4 in System Options, Ethernet, easyE RTD must allow this access.
  • Page 85 Fig. 45: Example showing what happens once a connection has been established. Access to the device may change depending on the imported visu- alization project file! Fig. 46: Example easyE RTD Advanced connection has been established. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 86: Import / Export Menu

    Importing a project through the USB port or a transfer via Ethernet will overwrite the existing visualization project on the RTD. Plug a USB drive into the USB port. Firmware files for the RTD can be loaded with the Update menu. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 87 Select the file you want from the list of available *.rtd files on the USB storage device. Press the Import button. As soon as the visualization project file parts have been loaded in the easyE RTD Advanced, the corresponding settings will be applied and a message will be shown. Export Fig.
  • Page 88 7. Operation 7.2 Device menus easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 89: Connecting To The Rtd

    RJ45 connectors.   Fig. 49: Ethernet connection using the ports on the RTD and easyE4  2. Power the devices  3. Log in to the RTD  4. Open the easyE4 mirroring menu (formerly Remote easyE4) easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 90 Tapping the SEL button will select the IP address that is currently highlighted in the list and exit the page. The selected IP address will now be in the address field.  7. Tap the Connect button to establish a connection to the selected easyE4 easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 91 Fig. 54: easyE4 mirroring You can also enter the IP address directly in the input fields with the arrow buttons or the input assistance. After doing this, tap the Connect button to establish the con- nection. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 92: Easye4 Settings

    RTD.             Tab. 11: System option- s\Ethernet\easyE RTD\access inhibit Set up access permissions for each user NO ACCESS ✓ WATCH   group. OPERATE   ADMINISTRATE           easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 93 For more information on how to establish an Ethernet connection with the easyE4 itself, please refer to manual MN050009, application note AP0050013, and the easySoft programming software program. See also   → Section " easyE4 visualization menu ", page 73 easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 94: Easye4 Connection With The Rtd Through An Ethernet Switch

    Ethernet switch. As soon as the Ethernet switch is connected between the existing connection between easyE4 and RTD, the Ethernet connection will be disconnected and will then be automatically re-established with auto IP. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 95: Easye4, Easysoft Connection With The Rtd

    Under the Ethernet tab in the Project view   The connection to the easyE4 device in the Communication view. See also   Documentation for the easyE4; "Establishing an Ethernet connection and trans- ferring a program or visualization project" section. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 96 8. Connecting to the RTD 8.3 easyE4, easySoft connection with the RTD easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 97: Faults

    9. Faults 9. Faults This section provides troubleshooting information for your easyE Remote Touch Display in case it does not behave as expected. Fault Cause Remedy No 24 VDC power supply (- Check the power cord and RTD will not boot up...

  • Page 98: Resetting The Device To Factory Settings - Factory Settings

    9.1 Resetting the device to factory settings - Factory Settings 9.1 Resetting the device to factory settings - Factory Settings The easyE Remote Touch Display can be reset to its factory settings (in the event that you lost your password, for example).

  • Page 99: Maintenance

    Do not use aggressive or abrasive cleaning products or solvents. Make sure that no liquids get into the device (short-circuit hazard) and that the RTD is not damaged in any way. Clean the frame and the display with a clean, soft, damp cloth. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 100: Repairs

    10. Maintenance 10.2 Repairs 10.2 Repairs For repairs, please contact your vendor or Eaton's Technical Support. CAUTION DESTRUCTION The RTD should only be opened by the manufacturer or by an author- ized center. Operate the Resistive Touch Display until only with the enclosure fully closed and sealed.

  • Page 101: Storage, Transport And Disposal

    If the Resistive Touch Display has condensation in or on it, or if it has been exposed to environmental fluctuations, let the RTD settle into the existing ambient temperature before switching it on. Do not expose the device to direct thermal radiation from heating appli- ances. easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 102: Disposal

    Tab. 13: Materials used in the packaging Packaging Material Outer packaging Cardboard Inner packaging Closed cell polyethylene foam, free of CFCs / plastic bag: poly- ethylene (PE) Inner packaging RTD Cardboard; plastic film and bag: Polyethylene (PE)   easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 103: Appendix

    Appendix Appendix A.1 Technical data A.1.1 Data sheet A.1.2 Dimension and weight specifications A.1.3 Approvals and declarations A.2 Further usage information easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 104: Technical Data

    A.1 Technical data A.1 Technical data A.1.1 Data sheet The current specifications for the device can be found in the data sheet for the device in the Eaton online catalog. Article no. and type Description 199740 - EASY-RTD-DC-43-03B1-00 easyE Remote Touch Display,...

  • Page 105: Dimension And Weight Specifications

    ≦ 0.5 mm (0.02") with a surface roughness Rz ≦ 120; IP 65 ￫ DIN ISO 2768-2 (K)   Hole diameter built-in: e = 123 mm (4.84") ± 0,5 mm (0.02"), f = 87 mm (3.43") ± 0,5 mm (0.02") easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 106: Approvals And Declarations

    Appendix A.1 Technical data A.1.3 Approvals and declarations The following specifications apply to all easyE Remote Touch Display units. Approvals anddeclarations RTD complies with all applicable European Union (EU) Directives and features the CE marking. UL-File no. E205091 DNV-CG-0339, Edition August 2021, TAA0000366...

  • Page 107: Further Usage Information

    Enter "easyE4" into the search box and the catalog will take you directly to the cor- responding product group in the Automation, Control and visualization section. Eaton.com/documentation Eaton.com/ecat Product information For up-to-date information, please consult the product page on the Internet. Eaton.com/easy easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...
  • Page 108 Appendix A.2 Further usage information easyE Remote Touch Display  01/24 MN048027EN  Eaton.com...

  • Page 109: Alphabetical Index
