4 - INSTALLING THE PRODUCT

4.1 - Electrical connections
WARNING - Before making the connections, ensure that the control unit is not powered up
POWER SUPPLY CONNECTIONS
L Power supply 230 Vac 50-60 Hz
Earth
N Power supply neutral 230 Vac 50-60 Hz
M2 M1
SBS
ECLIPSE
TWILIGHT SENSOR
FLASH
COM
M1 M2
M2
PH1
TX
NEG POS
1
LED
M1
PH1
RX
NC
NEG POS
COM OUT
2
T2A
N
L
PH2 PH2
TX RX
NC
NEG POS NEG POS
COM OUT
1 2
