- Page 1 F4 PLUS F4 PLUS (AS05950) Electronic control unit INSTRUCTIONS FOR INSTALLATION...
-
Page 2: Technical Specifications
• STOP input control with functioning as STOP (lock) or frame (obstacle freeing). • Hydraulic retention for hydraulic motors (DIP1_10 ON). • DIP switch to disable the LIMIT SWITCH and PHOTOCELL inputs if not used. Thank you for choosing GIBIDI. CAREFULLY READ THESE INSTRUCTIONS BEFORE PROCEEDING WITH INSTALLATION. WARNINGS: This product has been tested by GI.BI.DI. -
Page 3: Installation Warnings
F4 PLUS 3 - INSTALLATION WARNINGS • Before proceeding with installation, fit a differential magnetothermal switch with a maximum capacity of 10A upstream of the system. The switch must guarantee omnipolar separation of the contacts with an opening distance of at least 3mm. •... - Page 4 F4 PLUS 5 - ELECTRICAL CONNECTIONS: TERMINAL BOARDS Terminal Position Signal Description Motor 1 connection (opening) Motor 1 connection (common) Motor 1 connection (closing) Motor 2 connection (opening) Motor 2 connection (common) Motor 2 connection (closing) COURTESY LIGHT output (PHASE) if DIP1_9 = OFF Fixed output for FLASHLIGHT if DIP1_9 = ON COURTESY LIGHT output (NEUTRAL) if DIP1_9 = OFF Fixed output for FLASHLIGHT if DIP1_9 = ON...
-
Page 5: Protection Fuses
F4 PLUS 6 - PROTECTION FUSES Position Value Type Description Protects the circuit board and the motors. FAST 160mA FAST Protects the circuit board and the accessories. 7 - WARNING LEDs Signal Colour Description Always on. Goes off when the CLOSING LIMIT SWITCH of motor 2 FCCM2 is reached. - Page 6 F4 PLUS 8 - DIP SWITCH DIP1 The settings are stored during the rest phase (gate closed). The default settings are highlighted in the boxes with grey background. Description Function Status When the photocell is intercepted during both opening and closing, the gate motion is locked until the photocell is freed.
- Page 7 F4 PLUS Disables the limit switch input MOTOR 1 OPENING DIP1_4 LIMIT SWITCH Enables the limit switch input Disables the limit switch input MOTOR 1 CLOSING DIP1_5 In the case of a system with only one LIMIT SWITCH Enables the limit switch input motor and using the limit switches, the DIP switches 4, 5, 6 and 7 are Disables the limit switch input...
-
Page 8: Trimmer Adjustment
F4 PLUS 10 - JUMPER SW15 The settings are stored during the rest phase (gate closed). The default settings are highlighted in the boxes with grey background. Description JUMPER Function Status N.C. devices are connected to STOP/COSTA input (23) TERMINAL 23 SW15 FUNCTIONING Resistive 8,2Ohm devices are connected to STOP/COSTA input (23) - Page 9 F4 PLUS • Power the device. • Check that the red LEDs of the N.C. contacts are on and the green LEDs of the N.O. contacts are off. • Check by tripping the limit switches (if used and enabled with the appropriate DIP switches) that the corresponding LEDs go off. •...
- Page 10 F4 PLUS NOTES...
- Page 11 F4 PLUS NOTES...
- Page 12 GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B 46025 Poggio Rusco (MN) - ITALY Tel. +39.0386.52.20.11 Fax +39.0386.52.20.31 E-mail: info@gibidi.com Numero Verde: 800.290156 w w w . g i b i d i . c o m...
