SC380
SC380 (AS05800 - AS05810)
Electronic control unit
INSTRUCTIONS FOR INSTALLATION
UK

Advertisement

loading
Need help?

Need help?

Do you have a question about the SC380 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GiBiDi SC380

Summary of Contents for GiBiDi SC380

  • Page 1 SC380 SC380 (AS05800 - AS05810) Electronic control unit INSTRUCTIONS FOR INSTALLATION...
  • Page 2 SC380 Ÿ This product has been tested by GI.BI.DI., checking the perfect correspondance of its characteristics to the current directive. Ÿ GI.BI.DI. S.r.l. reserves the right to modify the technical data without prior notice, depending on the product development. PLEASE READ CAREFULLY THIS MANUAL BEFORE PROCEEDING WITH THE INSTALLATION.
  • Page 3 SC380 DIMENSIONS ( AS05810 ) ( AS05800 )

  • Page 4: Installation

    SC380 INSTALLATION...
  • Page 5 SC380 TRANSFORMER ELECTRICAL CONNECTIONS BROWN BLACK BLUE GREY 14 Vac 22 Vac 220 Vac 380 Vac 14 Vac 22 Vac 42 43 44 RX CONNECTOR...
  • Page 6 SC380 ELECTRICAL CONNECTIONS ( AS05810 ) 42 43 44 RX CONNECTOR DL11 30 31 32 33 39 40 41 10 11 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 LED STATUS 30 31 32 33...
  • Page 7 SC380 COLLEGAMENTO CON 380 Vac 3 FASI / POWER SUPPLY 380 Vac 3 PHASES ELECTRICAL CONNECTIONS ( AS05800 ) 42 43 44 RX CONNECTOR DL11 30 31 32 33 39 40 41 10 11 15 16 17 18 19 20 21 22 23...
  • Page 8 SC380 380 Vac 3 PHASES POWER SUPPLY 380 Vac ( AS05810 ) 42 43 44 10 11 380 Vac ( AS05800 ) 10 11 380 Vac...
  • Page 9 SC380 230 Vac 3 PHASES POWER SUPPLY 230 Vac ( AS05810 ) 42 43 44 10 11 230 Vac ( AS05800 ) 10 11 230 Vac...
  • Page 10 SC380 230 Vac 1 PHASE POWER SUPPLY 230 Vac ( AS05810 ) 42 43 44 10 11 230 Vac ( AS05800 ) 10 11 230 Vac...
  • Page 11 SC380 EARTH CONNECTION 380 Vac 3 PHASES MOTOR CONNECTION 380 Vac 230 Vac 3 PHASES MOTOR CONNECTION 230 Vac 230 Vac 1 PHASE MOTOR CONNECTION 230 Vac FLASHING LIGHT CONNECTION MENU - C 2 230 Vac 40W max...
  • Page 12 SC380 M4 MULTIFUNCTION TERMINAL BLOCK MENU - E 32 3 sec 3 sec 3 Min 3 Min 3 sec 3 sec...
  • Page 13 SC380 M5 MULTIFUNCTION TERMINAL BLOCK MENU - E 34 3 sec 3 sec 10 11 3 Min 3 Min 10 11 10 11 10 11 10 11 3 sec 3 sec...
  • Page 14 SC380 CONTROL DEVICES CONNECTION 15 16 17 18 19 20 21 22 23 LIMIT SWITCHES CONNECTION MENU - C 4 / C 23 15 16 17 18 19 20 21 22 23 EXTERNAL CLOCK CONNECTION MENU - E 9 15 16 17 18 19 20 21 22 23...
  • Page 15 SC380 PHOTOCELLS 1 CONNECTION DCF180 MENU - C 40 24 25 26 27 28 29 30 31 32 33 PHOTOCELLS 1 WITH TEST CONNECTION DCF180 MENU - C 40 / E1 30 31 32 33 24 25 26 27 28 29...
  • Page 16 SC380 NC “SAFETY DEVICE 1” CONNECTION MENU - C 42 24 25 26 27 28 29 30 31 32 33 8K2 “SAFETY DEVICE 1” CONNECTION MENU - C 42 24 25 26 27 28 29 30 31 32 33 NC “ SAFETY DEVICE 2” CONNECTION...
  • Page 17 SC380 STOP CONNECTION MENU - C 44 24 25 26 27 28 29 30 31 32 33 WARNING LIGHT CONNECTION 30 31 32 33 MOTOR RPM SENSOR BLUE BROWN 36 37 BLACK 2 CONTROL BOARDS SYNCHRONIZATION 38 39 40 41...

  • Page 18: Specification Sheet

    SC380 1 - SPECIFICATION SHEET Control unit SC380 Code AS05800 AS05810 Electronic control unit for the automation of one 230Vac or Type 380Vac motor for swinging, sliding gates or bollards. 230Vac Monophase 50/60 Hz Power supply 230 / 380Vac Three-phase 50/60 Hz Line disconnector N°...
  • Page 19 SC380 2 - TECNICHAL SPECIFICATIONS AND FUNCTIONS Red warning leds of NC contacts. There is not the safety devices led (from terminals 24 to 28). See “SIGNALLING Ÿ LED” table. Green warning leds of NO contacts. See “SIGNALLING LED” table.

  • Page 20: Installation Warnings

    SC380 3 - INSTALLATION WARNINGS Use suitable cable glands to assure the correct mechanical connection of the wiring and maintain the Ip55 Ÿ protexion degree of the case. Before proceeding with the installation, it is necessary to fit a magnetothermal and differential switch with a Ÿ...
  • Page 21 SC380 5 - ELECTRICAL CONNECTIONS: TRANSFORMER Fig. Faston Cable colour Description Primary 380 Vac transformer Brown Primariy 230 Vac transformer Black Primary 0 Vac transformer Grey Secondary 14 Vac transformer Blue Secondary 22 Vac transformer 6 - ELECTRICAL CONNECTIONS: TERMINAL BOARDS Fig.
  • Page 22 SC380 6 - ELECTRICAL CONNECTIONS: TERMINAL BOARDS Terminal Position Signal Description Fig. Start Start Input ( NO) Pedestrian input (NO) Open Opening only input (NO) Close Closing only input ( NO ) Opening limit switch input (NC) (Menu C4) Closing limit switch input (NC)
  • Page 23 SC380 6 - ELECTRICAL CONNECTIONS: TERMINAL BOARDS Terminal Position Signal Description Fig. Motor revolutions sensor input +24 Vcc Power supply +24 Vdc Motor revolutions sensor Inputs common - Outputs and Negative - 24 Vdc Not used Synchronization connection with another one SC 380...

  • Page 24: Signalling Led

    SC380 7 - SIGNALLING LED Position Colour Signal Description Fig. Turns on when the START command is enabled and turns DL 1 GREEN START off at release Turns on when the PEDESTRIAN command is enabled and DL 2 GREEN PEDESTR.
  • Page 25 SC380 9 - DISPLAY FROM LCD The contacts of terminal M8 are multifunction and can be programmed with menus C40-C41-C42-C43-C44, in the manual they will be identified with the name of their default or primary function. 24 25 26 27 28 29 During rest phase (Close gate) it is possible to display on the LCD the state of safety contacts (terminal M8 ).

  • Page 26: Buttons Description

    SC380 10 - BUTTONS DESCRIPTION At rest the buttons have the following functions - -- Button ( - ) to enable the PEDESTRIAN command Button ( ESC ) is not enabled Button ( OK ) is enabled to activate STOP command...
  • Page 27 SC380 11 - PROGRAMMING, ACCESS AND PASSWORD ENTRY With control unit at rest press the buttons ( ESC and OK ) at the same time ----- for 3 seconds, it will immediately appear MENU, then PASS. MENU To go on with the programming, press button ( OK ) To go out from the programming, press button ( ESC ) for 3 seconds.
  • Page 28 SC380 12 - PROGRAMMING, EXAMPLE OF PASSWORD ( 0000 ) ENTRY Make the access to the programming as described in chapter 11. Press the button ( OK ) to confirm. OOOO The second digit will blink O OO Press the button ( OK ) to confirm...
  • Page 29 SC380 14 - PROGRAMMING, EXAMPLE OF SETTING E9=4 The procedure used in this example for MENU (E) is valid for MENUS ( A , C) also . AC HE Make the access to the programming as described in chapters 11 and 13.
  • Page 30 SC380 15 - PROGRAMMING, EXAMPLE OF SETTING H2 = 20 The procedure used in this example for MENU (H) is valid also for MENU ( E ) with 4 digits settings . AC HE Make the access to the programming as described in chapters 11 and 13.

  • Page 31: Reset Procedure

    SC380 16 - PROGRAMMING, QUIT THE PROGRAMMING It is possible to leave the programming from the main menu pressing the button ( ESC ) for 3 seconds. AC HE EXIT ----- 17 - RESET PROCEDURE It is possible to make a reset of the control unit to come back to factory parameters.

  • Page 32: Menu Description

    SC380 18 - MENU DESCRIPTION WARNING: The DEFAULT settings are in grey spaces 18.1 - DESCRIPTION MENU ( A ) Menu Function Status Description It configures the system for swing gate. With this configuration: the electronic brake is automatically excluded.
  • Page 33 SC380 18.1 - DESCRIPTION MENU ( A ) Menu Function Status Description It enables the STEP BY STEP Logic Operation after a START command: Close gate OPEN → Ÿ STEP BY STEP LOGIC During opening CLOSE → Ÿ Open gate CLOSE →...
  • Page 34 SC380 18.2 - DESCRIPTION MENU ( C ) DESRCIZIONE MENU ( A ) Menu Function Status Description It disables the fast closing function. After the interception and the subsequent freeing of the photocells,the pause time will be reloaded. FAST CLOSING It enables the fast closing function.
  • Page 35 SC380 18.2 - DESCRIPTION MENU ( C ) DESRCIZIONE MENU ( A ) Menu Function Status Description It enables the hammer stroke function both in opening and closing to help the release of the electric lock (see menus E32 and E34).
  • Page 36 SC380 18.2 - DESCRIPTION MENU ( C ) DESRCIZIONE MENU ( A ) Menu Function Status Description It disables the “Hydraulic block maintenance” function It enables the “Hydraulic block maintenance” function. Operation: When the gate is close and not active, a 2 seconds pulse is given in closing every hour.
  • Page 37 SC380 18.2 - DESCRIPTION MENU ( C ) DESRCIZIONE MENU ( A ) Menu Function Status Description Input DISABLED. Input programmed as STOP Operation: The STOP enabling blocks the automation and the restart of the motion will occur only after a START / PEDESTRIAN / OPEN / CLOSE command.
  • Page 38 SC380 18.2 - DESCRIPTION MENU ( C ) DESRCIZIONE MENU ( A ) Menu Function Status Description Input DISABLED. Input programmed as STOP Operation: STOP enabling blocks the automation and the restart of the motion will occur only after a START / PEDESTRIAN / OPEN / CLOSE command.
  • Page 39 SC380 18.2 - DESCRIPTION MENU ( C ) DESRCIZIONE MENU ( A ) Menu Function Status Description Input DISABLED. Input programmed as STOP Operation: STOP enabling blocks the automation and the restart of the motion will occur only after a START / PEDESTRIAN / OPEN / CLOSE command.
  • Page 40 SC380 18.2 - DESCRIPTION MENU ( C ) DESRCIZIONE MENU ( A ) Menu Function Status Description Input DISABLED. Input programmed as STOP Operation: The STOP enabling blocks the automation and the restart of the motion will occur only after a START/ PEDESTRIAN /OPEN /CLOSE command.
  • Page 41 SC380 18.2 - DESCRIPTION MENU ( C ) DESRCIZIONE MENU ( A ) Menu Function Status Description Input DISABLED. Input programmed as STOP Operation: STOP enabling blocks the automation and motion restart will occur only after a START / PEDESTRIAN / OPEN / CLOSE command.
  • Page 42 SC380 18.3 - DESCRIPTION MENU ( H ) DESRCIZIONE MENU ( A ) Menu Function Status Description Door opening time. MOTOR OPENING TIME 0 - 300 seconds (adjustable at intervals of 1 second ) Door closing time. MOTOR CLOSING TIME...
  • Page 43 SC380 18.4 - DESCRIPTION MENU ( E ) DESRCIZIONE MENU ( A ) Description Menu Function Status It disables the safety devices test. This function enables the safety devices test SET AS EDGE 8K2 or EDGE NC. Operation for EDGE 8K2: All the safety inputs set as edge 8K2, after a command motion star,t will be tested (8K2 value).
  • Page 44 SC380 18.4 - DESCRIPTION MENU ( E ) DESRCIZIONE MENU ( A ) Menu Function Status Description It disables the RESERVE input It enables the RESERVE input (for the connection of an external clock, a magnetic loop or a different command device)
  • Page 45 SC380 18.4 - DESCRIPTION MENU ( E ) DESRCIZIONE MENU ( A ) Menu Function WARNING! A programming of the function different from the configuration preset from the manufacturer, although it allows, if correctly done, the reduction of the cases of stop of the system in intermediate position (as a simply...
  • Page 46 SC380 18.4 - DESCRIPTION MENU ( E ) DESRCIZIONE MENU ( A ) Menu Function Status Description REL1 set as electric lock. Enabled for 3 seconds at the beginning of opening and closing REL1 set as courtesy light Enabled for 3 minutes more after motor stop...
  • Page 47 SC380 18.4 - DESCRIPTION MENU ( E ) DESRCIZIONE MENU ( A ) Menu Function Status Description It disables the reading of the motor revolutions sensor. It enables the reading of motor revolutions sensor. VERY HIGH intervention sensitivity Operation: After a reduction of the number of revolutions of the motor (for...
  • Page 48 SC380 18.4 - DESCRIPTION MENU ( E ) DESRCIZIONE MENU ( A ) Menu Function Status Description It allows to display the setting of terminal 24, defined with menu C40, and the number of safety intervention, determined by the input if set as EDGE N.C. or as EDGE 8K2.
  • Page 49 SC380 18.4 - DESCRIPTION MENU ( E ) DESRCIZIONE MENU ( A ) Menu Function Status Description It allows to display the setting of terminal 27, defined with menu DISPLAY OF SETTING AND C43, and the number of safety interventions, determined by the INTERVENTIONS NUMBER input if set as EDGE N.C.
  • Page 50 SC380 DESRCIZIONE MENU 19 - SYNCHRONISM ( A ) By the terminal M11it is possible to synchronize two control units, se e figure 31. Connections: Connect only one button START to one of the two control units. Ÿ Connect the photocell 1 to terminal 24 of one of the two control units. The command, by terminal M11, will be Ÿ...
  • Page 51 The SC380 + BX-6M system allows to control up to six single-engine rising bollards or three twin-engined rising bollards and allows to control all the rising bollards at the same time or only a group chosen by the switch SW1 present on BX-6M.
  • Page 52 SC380 23 - FLASHING LIGHT SIGNALLINGS SUMMARY DESRCIZIONE MENU ( A ) Device Signalling Effect Photo 2 intercepted at rest in presence of START 5 fast flashings When released, it opens command Edge intercepted at rest in presence of START...
  • Page 53 S.r.l. Via Abetone Brennero, 177/B, 46025 Poggio Rusco (MN) ITALY eclares that the products ELECTRONIC CONTROL UNIT SC380 Are in conformity with the following CEE Directives: LVD Directive 2006/95/CE and subsequent amendments; • • EMC Directive 2004/108/CE and subsequent amendments;...
  • Page 54 SC380 NOTES...
  • Page 55 SC380 NOTES...
  • Page 56 GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B 46025 Poggio Rusco (MN) - ITALY Tel. +39.0386.52.20.11 Fax +39.0386.52.20.31 E-mail: info@gibidi.com Numero Verde: 800.290156 w w w . g i b i d i . c o m...

This manual is also suitable for:

As05800As05810
