USER MANUAL
VOICE EVACUATION & PUBLIC
ADDRESS SYSTEM
VA-6200RM
Thanks for using ITC Voice Evacuation& Public Address System.
For better operation, please read this manual carefully before operating the system.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VA-6200RM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ITC VA-6200RM

  • Page 1 USER MANUAL VOICE EVACUATION & PUBLIC ADDRESS SYSTEM VA-6200RM Thanks for using ITC Voice Evacuation& Public Address System. For better operation, please read this manual carefully before operating the system.
  • Page 2 Notification WARNING To ensure the reliability of the equipment and the safety of personnel, please observe the following when installing, using and maintaining: ● If any of the following conditions are found, please immediately turn off the power, plug out and quickly contact your nearest dealer.
  • Page 3 ● This equipment is only suitable for safe use at altitudes under 2000 meters. Precautions 1. The installation environment When installing the unit, in order to ensure the normal cooling of the host, should avoid the poor ventilation of the place or high temperature environment, to avoid direct sunlight. Recommend to install cabinet or other well-ventilated place indoor.
  • Page 4 5. Agreement Please strictly follow the instructions in this manual. The software, hardware and appearance of this product will be upgraded and updated continually. The above changes will be made without notice. Non-professional maintenance personnel, do not remove the product, to avoid damage and electric shock.
  • Page 5: Table Of Contents

    Contents 1 Product picture..........................6 1.1 Product picture.......................... 6 2 Introduction to features........................7 2.1 VA-6200RM Features....................... 7 2.2 Main technical parameters......................8 3 Panel function instruction.......................10 3.1 Front panel function instruction....................10 3.2 Rear panel function description....................12 4 Instructions............................13 5 Online upgrade instructions......................
  • Page 6: Product Picture

    1 Product picture 1.1 Product picture Figure 1- 1 VA-6200RM Product picture...
  • Page 7: Introduction To Features

    2 Introduction to features 2.1 VA-6200RM Features  Support 160 zones, 16 groups paging  Support configuring any zone to any group  Support paging to any zone of any controller.  Supports mix output / microphone priority output and adjustable output volume.
  • Page 8: Main Technical Parameters

    2.2 Main technical parameters Electrical indicators ① Power supply  24V DC power supply 24V power supply through network interface  Performance ① Analog audio  MIC. input  Sensitivity 10MV ± 1mV  Frequency 200Hz ~ 10kHz  Input impedance 1kΩ ...
  • Page 9 ③ Mechanical indicators  Size (L × W × H) mm  Net weight Around 1.1 Kg  Installation Desktop or 19-inch cabinet  Color Black ④ Environmental requirements  Operating temperature +5 ℃ ~ +40 ℃  Storage temperature -20 ℃...
  • Page 10: Panel Function Instruction

    Panel function instruction 3.1 Front panel function instruction Front panel design sketch of VA-6200RM 1. Panel indicator light Power indicator(DC POWER) ① Green: Normal input voltage  Light is out: Unusual input voltage  Zone grouping status indicator (Z/G) ②...
  • Page 11  Light is out: Zone mode  Green light flashing: on-line upgrading mode  Red light flashing: on-line upgrading failed ④ Selecting all zones(ALL CALL) Grouping mode: cancel/select the corresponding 16 groups of the main controller.  Zone mode: cancel/select the associated with 16 zones of the main controller. ...
  • Page 12: Rear Panel Function Description

    3.2 Rear panel function description Figure 4- 2 VA-6200RM Rear panel renderings ① Switch ② Grounding post ③ DC voltage input ④ Line sound source input ⑤ Output volume adjustment ⑥ CAN communication network port ⑦ DIP setting: (up: enable down: off) PIN1: Can communication match resistance switch PIN2 ~ PIN6: Device address code set, using binary code address.
  • Page 13: Instructions

    4 Instructions 1. In standby mode, users can associate with any host (host ID number: 1-20) through the panel 【page up】, 【page down】 key settings. In zone / group paging mode, default partition mode, if selecting group mode, the group indicator light is green. 2.
  • Page 14: Online Upgrade Instructions

    Controller: Fill in the controller IP address: 192.168.1.253 (default IP address) Port: Fill in the port number: 69 Local File: Select the path where the VA-6200RM.bin file is located (please do not change the file name), then click the [Put] button to upload the file to the controller.
  • Page 15: Accessories: Dip Switch Table

    Accessories: DIP switch table Address code table (Address Code Description: Dial up: 0 Dial down: 1) PIN2 PIN3 PIN4 PIN5 PIN6 MIC_ID...
  • Page 17 Version: 0.2...
