Assa Abloy 440F Series Installation Instructions

440F Series
Exit Device Trim
Installation Instructions
For use with ASSA ABLOY Exit Devices (Wood and Metal Doors)
441F & 446F
Non-Handed
*Field Prep: Cut tailpiece off, not to engage the device.
All dimensions are in inches (mm) unless
otherwise noted.
WARNING
This product can expose you to lead which is known to the state of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.P65warnings.ca.gov.
WARNING
Attention Installer: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening,
and ASSA ABLOY makes no representations or warranties concerning what such impact may be in any specific situation. When
retrofitting any portion of an existing fire-rated opening, or specifying and installing a new fire-rated opening, please consult with a
code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
1-800-438-1951 • www.assaabloy.com
Copyright © 2008, 2012, 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
LEVER TYPE TRIM
441F
Key In
Lever
446F
448F
Plain
Lever
449F
Sectional Lever Trim
FUNCTION DESCRIPTION
F03 (NL) Key retract bolt(s)
F08 Key locks/unlocks lever
Passage Lever retracts bolt(s)
F02 Dummy trim*
F02 Dummy trim
ABBREVIATION
PPHMS
PTHMS
448F & 449F
Non-Handed
REMARKS
Free wheeling lever
Free wheeling lever
Lever always active
Free wheeling lever
Rigid lever
FASTENER DESCRIPTION
PHILLIPS PAN HEAD MACHINE SCREW
PHILLIPS TRUSS HEAD MACHINE SCREW
80-8470-0441-000 12/23
