Wireless Setup guide
The purpose of this guide is to check or edit the 2.4 GHz and 5 GHz Wi-Fi network name and password.
Please note that the default Wi-Fi network name and password on the gateway is unique, randomly
generated and considered to be secure and are available on the Gateway label.
If you are planning to change the Wi-Fi network name and password it is recommended to keep it same for
both 2.4 GHz and 5 GHz band. This will allow the wireless clients to auto select suitable band and for
optimum MESH performance.
Login to Web User Interface
1
Connect your device to the Gateway using wired or wireless connection.
Important – A computer connected using an Ethernet cable is strongly recommended.
2
Open a web browser (such as Google Chrome, Safari or Mozilla Firefox), type following address into
the address bar and press Enter.
http://192.168.20.1
3
Enter Gateway Login Username and Password printed on the label at the back of Gateway and press
the Sign in button.
Wireless Setup Guide – NL19MESH
FA01371 v. 1.0 August 2021
Wireless Setup Guide
Sign in screen
NL19MESH

Advertisement

loading
Need help?

Need help?

Do you have a question about the NL19MESH and is the answer not in the manual?

Questions and answers

Related Manuals for Casa Systems NL19MESH

Summary of Contents for Casa Systems NL19MESH

  • Page 1 Enter. http://192.168.20.1 Enter Gateway Login Username and Password printed on the label at the back of Gateway and press the Sign in button. Sign in screen Wireless Setup Guide – NL19MESH FA01371 v. 1.0 August 2021...

  • Page 2: Wi-Fi 2.4Ghz/Wifi 5Ghz

    2 of 6 If no authentication prompt is displayed or you see a request time out message, refer to “NL19MESH Connect Note – to Gateway Web Interface Guide” from the FAQs section. Wi-Fi 2.4GHz/WiFi 5GHz The gateway allows you to maintain separate wireless settings for both 2.4GHz and 5GHz wireless services.

  • Page 3: Wireless Security

    Use a client device like a computer, laptop, mobile or iPad to scan the Wi-Fi network name, select the right Wi-Fi network name/SSID and enter the displayed Wi-Fi password to join the network. NL19MESH – Wireless Setup Guide FA01371 v. 1.0 August 2021...

  • Page 4: Connect To Your Wireless Network

    Enter the WiFi Network security key/password and click the Next button. Your computer connects to the WiFi network. If you are still facing difficulty to connect the Wi-Fi network name, refer to NL19MESH - Connect to Gateway Web Interface Guide from the FAQs section.

  • Page 5: Apple Iphone

    [1] (in this example, it is “ ”), enter the WiFi password [2] and press Join [2]. NetComm 8386 If you are still facing difficulty to connect the Wi-Fi network name, refer to NL19MESH Connect to Gateway Web Interface Guide from the FAQs section Android The following is an example of connecting to the Wi-Fi network using an Android phone.
  • Page 6 Airport icon again. Your WiFi network has a ✓ tick next to its name. The wireless network configuration is complete, and you can now use the Internet. You can disconnect the Ethernet cable, if you wish. NL19MESH – Wireless Setup Guide FA01371 v. 1.0 August 2021...
