Summary of Contents for HOMCOM 713-034V01

  • Page 1 IN240400075V01_GL_713- IN240400075V01_GL_713-034V01 US_CA...
  • Page 2 Maintenance 1. The exterior of this rollator walker should be cleaned periodically with a soft damp cloth. Do not use abrasive cleaners or caustic chemicals. 2. Check the parts for any looseness, wear, or damage periodically. If any problems are found, correct them before using them.
  • Page 3 NOTE EN_Do not confuse similar screws.Do not tighten bolts fully until all parts are connected! FR_Ne pas confondre des vis similaires.Ne serrez pas les boulons à fond tant que toutes les pièces ne sont pas connectées! ES_No confunda tornillos similares.No apriete los tornillos completamente hasta que todas las partes están conectadas! PT_Não confundir parafusos semelhantes.
  • Page 4 EN_Joint ALUMINUM FRAME (7) to ALUMINUM FRAME (6) , with 1PC SCREW (D) 1PC PLASTIC GASKETS (C) and 1PC METAL GASKETS (B) in each side, insert Bucket Hanging Bracket (8) into ALUMINUM FRAME (6) , following Previous step again. FR_Assembler le CADRE EN ALUMINIUM (7) au CADRE EN ALUMINIUM (6), avec 1 vis (D), 1 joint en plastique (C) et 1 joint en métal (B) de chaque côté, insérer le support de suspension du seau (8) dans le CADRE EN ALUMINIUM (6), en suivant à...
  • Page 5 EN_Joint two ARMRESTS (1) to ALUMINUM FRAME (6) , with 1PC SCREW (D) , 2PCS METAL GASKETS (B) and 1PC SCREW NUT (A) in one hole of each side (each side has two holes). Notes: Please make sure the semi-closed bracket face front to avoid bucket falling down.
  • Page 6 EN_Nut facing outside FR_Écrou tourné vers l'extérieur ES_Tuerca hacia el exterior PT_Porca virada para o exterior DE_Mutter nach außen IT_Dado rivolto verso l'esterno EN_Joint two ARMRESTS (1) or BACKREST WITH HANDLES (2), with 1PC SCREW (D), 2PCS METAL GASKETS (B) and 1PC SCREW NUT (A) in one hole of each side (each side has two holes).
  • Page 7 EN_Put BUCKET (3) on the BUCKET HANGING BRACKET (8). FR_Placer le BUCKET (3) sur le SUPPORT D'ACCROCHAGE DU BUCKET (8). ES_Coloque el CANGILÓN (3) en el SOPORTE PARA COLGAR CANGILONES (8). PT_Colocar o balde (3) no suporte de suspensão do balde (8). DE_Setzen Sie den Eimer (3) auf die Eimeraufhängung (8).
