INSTRUCTION
Model No.
713-061
N.W. 17KG Weight Capacity
Material：Aluminum frame . PU seat ,seat cover,backrest and armrest.
Seat Height（R2）
Seat Width（R1）
460mm
540mm
Height（R6）
Length（R5）
980mm 1020mm
Height（ R9max）Height（R9min）
1330mm 1060mm
R7
R1
R3
R6
R2
Please check the following parts list before assembly .
Backrest
① Main Frame 1PC ② 1PC
③ Pentagram Knob
Right Footrest Seat 1PC
⑥ 1PC ⑦ ⑧
Description
Aluminum Reclinling Commode Chair
120KG
Seat Depth（R3）
Backrest Height（R4）
490mm
400mm
Width（R8）
Armrest Height（R7）
240mm 590mm
Height（R10min）
Height（R10max）
175mm 25mm
R4
R8
R9
R5
R10
Headrest 1PC
2PCS ④ ⑤ Left Footrest
Commode
Seat Cover 1PC ⑨ 1PC ⑩
Extra U-shaped buckles
ASSEMBLE STEPS
1
1.1 Prepare part ① x1,②x1;
1.2 Insert part ② to the tube as shown in <fig.1>, and align
the holes of these 2 parts；
1.3 After match the bottom holes of part ②, Use part
align the side holes and fasten , as shown in <fig.1>；
2
2.1 Prepare part ④x1;
2.2 Insert part ④ into the tube,then use part E to fasten
it as shown in <fig.1>；
2.3 The method of tightening and loosening is shown
in <fig.2>；
2.4 When part is blocked and can not be locked to
F
the positions, pull it outward , and disengage from
the internal tooth position meanwhile rotate it and
adjustment position , till it can be locked or loosened ;
When the caregiver is accompanying the rear , adjust
its position to avoid being touched . The operation
method is shown in <fig.3>.
2.5 Fix part , the brake cable to the frame with 2
M
buckles, at the positions as shown in <fig. 1> .
1PC
F
< figure 2 >
to
③
①
Tighten
Loosen
< figure 3 >
EN C191121
④
E
E
②
M
3
Fix the knob from
back to front
< fig.1 >
Adjust Position
Pull
