- Page 1 Use r M a n u a l...
- Page 2 Product Video Information POC ONE Product Video POC ONE Assembly Guide Download Link - 2 -...
- Page 3 Product Story All is One Pre-linked as ONE, and to build into ONE. POC ONE brings joy to PC DIY enthusiasts with its straightforward assembly. With the versatile combination of the materials, POC ONE complements various lifestyles. - 3 -...
-
Page 4: Specifications
(L x W x H) 20.5 x 20.1 x 4.7" Net Weight 4.4 kg / 9.7 lb Gross Weight 5.4 kg / 11.9 lb * InWin's products comply with RoHS regulations. * Specifications may vary based on different regions. - 4 -... - Page 5 MTBF >30,000 hrs Net Weight 200 g Package Dimensions (L x W x H) 185 x 125 x 30mm Warranty 2 years * InWin's products comply with RoHS regulations. * Specifications may vary based on different regions. - 5 -...
-
Page 6: Package Contents
Package Contents POC ONE Chassis x 1 M/B Anti-Dust Covers x 2 Structure Support Bar A x 4 POC ONE Sticker Pad x 1 Structure Support Bar B x 4 I/O Module x 1 Handles x 2 PCI-E 4.0 Riser Cable x 1... - Page 7 Package Contents – Accessories Bag Hex Screws x 12 Screws x 13 SSD Screws x 2 Fan Screws x 4 Hexagon Head Screws M/B Stand-offs A x 2 M/B Stand-offs B x 2 Stand-off Socket x 1 x 14 GPU Stand-offs x 2 Radiator Screws x 8 L-shaped Hex Wrench x 1 Wrenches x 2...
- Page 8 Case Structure Handles Aluminium Magnetic Plate I/O Panel Shock-Proof Stand Motherboard Mounting Area CPU Cooler Installation Cut-Out Hole 2.5" SSD Mounting Area Side Fan Mounting Area Power Supply Mounting Area Rear Fan / Radiator Mounting Area PCI-E Expansion Slots Graphic Card Mounting Area Cable Routing Port - 8 -...
-
Page 9: Cable Connection
Cable Connection Blue(P_LED) 1 2 Red (HDD) White(P_LED) 3 4 White (HDD) Brown(P_SW) 5 6 NC White(P_SW) 7 8 NC Key 9 10 NC I/O Wires PURPLE PORT2_R YELLOW WHITE PORT1_R HD Audio Header PORT1_L BLACK USB 3.2 Gen 1 Header USB 3.2 Gen 2x2 Type-C Header... - Page 10 7. For more technical support, please visit the InWin Forum at https://forum.in-win.com/ Warranty ■ 1. For more detailed warranty information, please visit the InWin retail website at www.in-win.com. 2. The actual product is subject to change without prior notice. In Win Development Inc. reserves the right to make final modifications.
- Page 11 Copyright © 2024 In Win Development Inc. All Rights Reserved.
