Summary of Contents for InWin F3
- Page 1 User Manual...
- Page 2 Product Video Information F3 Product Video F3 Installation Guide Video...
- Page 3 Product Story The F3, a highlight product from our F series, redefines the mini-tower PC case, offering a choice between elegant maple wood and modern glass. Designed to accommodate high-end GPUs and Micro-ATX back-connect M/B, it seamlessly blends with your lifestyle and personal taste,...
-
Page 4: Specifications
Top: 2 x 120 / 140 mm Rear: 1 x 120 mm Thermal Solution Bottom: 2 x 120 mm Compatibility (1 InWin AN120 / AN120P Fan Included) Water Cooling Radiator: Top: 1 x 240 / 280 mm Power Supply PSII: ATX12V... - Page 5 Long Lifespan Sleeve Bearing Bearing Type >36,000 hrs MTBF 541 g / 1.19 lbs Net Weight 803 g / 1.77 lbs Gross Weight 3 Years Warranty * InWin's products comply with RoHS regulations. * Specifications may vary based on different regions.
-
Page 6: Package Contents
Package Contents Accessories Bag Hexagon Head Screws x 12 2.5" SSD Screws x 12 Motherboard Stand-off Socket x 1 3.5" HDD Screws x 8 Motherboard Stand-offs x 2 GPU Support Holder x 1 Cable Ties x 5 Velcro Strips x3 PWM Fan Extension Cable x 1 ARGB Extension Cable x 1 QR Code Card x 1... - Page 7 Case Structure Power Button USB 3.2 Gen 1 HD Audio Combo (CTIA – SPK/Mic) USB 3.2 Gen 2x2 Type-C SECC Front Panel Mesh Front Panel Maple Wood Panel Tinted Glass Panel...
- Page 8 Case Structure Top Fans / Radiator Mounting Area Front Fan Mounting Area Bottom Fans Mounting Area Rear Fan Mounting Area (1 InWin AN120 or AN120P Fan Pre-Installed) PCI-E Slot x 4 Motherboard Mounting Area CPU Cooler Installation Cut-Out Hole Anti-Dust Filters...
- Page 9 Case Structure Power Supply Mounting Area 1 x 3.5" / 2.5" Drive Bays 1 x 3.5" / 2 x 2.5" Drive Bays...
-
Page 10: Cable Connection
Cable Connection I/O Wires Black(P_LED) 1 2 Black (HDD) Black(P_LED) 3 4 Black (HDD) Black(P_SW) 5 6 NC Black(P_SW) 7 8 NC Key 9 10 NC HD Audio Header PORT2_L BLUE PURPLE PORT2_R YELLOW WHITE PORT1_R PORT1_L BLACK USB 3.2 Gen 1 USB 3.2 Gen 2x2 Type-C... -
Page 11: Warranty
6. When storing the case, please keep this product away from high temperatures. Keep away from machines such as heaters that might cause high temperatures. 7. For more technical support, please visit the InWin Forum at https://forum.in-win.com ■ Warranty 1. - Page 12 Copyright © 2024 In Win Development Inc. All Rights Reserved.
