Summary of Contents for InWin 103
- Page 1 User Manual...
- Page 2 Product Story The 103 presents a gamer feel with its pinstripe design and sharp exterior. It maintains a clean exterior but serves as inspiration to the gamer inside everyone! The InWin logo possesses addressable RGB lighting effect, which creates a brilliant visual experience.
- Page 3 Specifications Model Part Number IW-103-Black, IW-103-White Colors Black, White Case Type Mid Tower Materials SECC, ABS, PC, Tempered Glass M/B Compatibility 12" x 10.5" ATX, Micro-ATX, Mini-ITX Expansion Slots PCI-E x 7 Maximum VGA Card Length: 421mm (Maximum) Compatibility VGA Card Length: 305mm...
- Page 4 Package Contents 103 Chassis QR Code Accessory Bag...
- Page 5 Accessory Bag A. Motherboard Stand-offs x 7 B. Motherboard Stand-off Socket x 1 C. Hexagon Head Screws x 18 D. 2.5” HDD Screws x 12 E. Water-cooling System Washers x 8 F. Cable Ties x 10 G. Pin Header x 1 H.
- Page 6 Case Structure Power Button Logo USB 3.0 Ports Audio Ports (Earphone and Microphone)
- Page 7 Case Structure 3.5”/2.5” Drive Bay Side Fan/ Radiator Mounting Area Rear Fan/ Radiator Mounting Area Bottom Mounting Area/ Radiator Mounting Area Motherboard Mounting Area PCI-E Expansion Slot Extra PCI-E Supporting Mounting Hole...
- Page 8 Case Structure Power Supply Mounting Area 2.5” Drive Bay Shock-Proof Stand Fan Dust Filter...
- Page 9 Installation Guide (Please follow the related chapters to assemble) Opening the Chassis For the side panel, please pull the two tabs and lift the glass up. Power Supply up to 200mm Installation Parts Required: Hexagon Head Screws Power supply must be mounted on the top bracket.
- Page 10 Expansion Card Installation Parts Required: Hexagon Head Screws, Graphics Card Holder...
- Page 11 * If your motherboard doesn't have a 3-pin ADD header, please use the provided RGB controller to connect the InWin logo ADD RGB module to your PSU to set the default lighting. * The bottom on the controller is to switch lighting modes.
- Page 12 5-2 3-pin Header IN-WIN LOGO ADD RGB Module Motherboard Add_header 3 Pin-header Other Addreassble Light I/O Wires Installation Parts Required: Power SW/ HD Audio/ USB3.0 Header POWER SW...
- Page 13 USB3.0 Header 2.5” / 3.5” Drive Bays Installation...
- Page 14 Fan / Liquid Cooling Radiator Installation Parts Required: Water-cooling System Washers Completing Installation Parts Required: Cable Ties...
- Page 15 CD-ROM, motherboard and CPU, etc.) Warranty ■ For more detailed warranty information, please visit the InWin retail website at www.in-win.com. ■ The actual product is subject to change without prior notice. In Win Development Inc. reserves the right to...
