Summary of Contents for InWin IW-A1PLUS-BLACK
- Page 1 User Manual...
- Page 2 An InWin 650W, 80 PLUS Gold PSU is prebuilt within the A1 PLUS with cables already managed. The A1 PLUS also comes with two Sirius Loop addressable RGB fans, and an enhanced Qi 1.2 10W charging panel...
-
Page 3: Specifications
1 x 120mm Side Fan Compatibility 1 x 120mm Rear Fan / 120mm Radiator 2 x 120mm Bottom Fans Power Supply InWin 650W PSU Included ATX12V V2.4 Compatibility Product Dimensions 273 x 224 x 357mm (H x W x D) with screw &... - Page 4 Dimensions(L x W x H) 140 x 150 x 86 mm Warranty 5 Years Connectors Motherboard 24-pin CPU 4+4-pin PCIE 6+2 pin Peripherals SATA Floppy Power ■ InWin products comply with RoHS regulation. ■ Specifications may vary based on different regions.
- Page 5 Air Flow 50 CFM Air Pressure 1.67mm/ H2O Connector 4-Pin Noise Level 27 dB(A) Max. Bearing Type Long Lifespan Sleeve Bearing Life Expectancy >30,000 hrs ■ InWin products comply with RoHS regulation. ■ Specifications may vary based on different regions.
-
Page 6: Package Content
Package Content A1 PLUS Chassis InWin 650W 80PLUS Gold PSU InWin Sirius Loop fans x 2 Fan RGB One-Click Controller x 1 QR Code Card Accessory Bag... -
Page 7: Accessories Bag
Accessories Bag Hexagon Head Screws X 8 2.5” HDD Screws X 10 Graphic Card Holder X 1 Cable Ties X 5 Anti-Slip Strips X 4 ARGB One-Click Controller v1.1 x 1... - Page 8 Case Structure Tempered Glass Logo SECC Front/ Side Panel Power Button HDD/Power LED indicator USB 3.0 Ports Audio Ports (Earphone and Microphone)
- Page 9 a. 2.5 Drive Bay b. Side Fan Mounting Area c. Rear Fan/ Radiator Mounting Area d. Bottom Fan Mounting Area e. Motherboard Mounting Area f . CPU Cooler Installation Cut-Out Hole g. PCI-E Expansion Slot h. Extra PCI-E Supporting Mounting Hole i.
-
Page 10: Opening The Chassis
Installation Guide Please follow the related chapters to assemble Opening the Chassis For the side panel, please pull the two tool-less tabs and lift up. Motherboard Installation Parts Required: Hexagon Head Screws Expansion Card Installation Parts Required: Hexagon Head Screws, Graphics Card Holder... - Page 11 I/O Wires Installation Switch/LED Connector Blue(P_LED) 1 2 Red (HDD) White(P_LED) 3 4 White (HDD) Brown(P_SW) 5 6 NC White(P_SW) 7 8 NC Key 9 10 NC...
- Page 12 2.5” Drive Bays Installation Parts Required: 2.5” HDD Screws Fan/ Liquid Cooling Radiator Installation...
- Page 13 Addressable RGB-Cable Installation If your motherboard supports the addressable RGB effect, please follow the direction of sign and connect as followed: Connect the case’s addressable RGB Y-Cable to a motherboard’s addressable RGB header. The fan cable, addressable RGB Y-cable and their counterparts are attached to each. Please connect as followed: ...
- Page 14 If your motherboard does not support an addressable header, please use the included Fan RGB One-Click Controller to connect to your PSU’s SATA cable and the case’s Addressable RGB Y-Cable in order to use the 14 different lighting effects. 1st fan’s addressable PSU’s SATA cable RGB Y-Cable case’s addressable...
-
Page 15: Completing Installation
Completing Installation Parts Required: Cable Ties... -
Page 16: Warranty
■ Warranty * For more detailed warranty information, please visit the InWin retail website at www.in-win.com. * The actual product is subject to change without prior notice. InWin Development Inc. reserves the right to make final modifications. - Page 17 InWin IW-WT02 Wireless Charger User Manual...
- Page 18 Specifications Input 5V/2A or 12V/1.8A Output Support Qi 5V/1A (OUTPUT:5V/2A), 7.5W / 10W Fast Charging (OUTPUT :12V/1.8A) Power Transfer Efficiency Product Dimensions (HxWxD) 72 x 49 x 8mm Warranty 1-year limited warranty (Effective date based on the purchasing date from consumers) User Guide 1.
- Page 19 ■ Note to use 1. To avoid any computer and computer-related component damage, please use IW-WT02 on InWin approved products. 2. To indicate that the mobile device battery is at a full charge, the platform will continuously beep. To cease the beeping sounds, simply remove the device.
- Page 20 Copyright © 2019 InWin Development Inc. All Rights Reserved.
