REP WS-5305 Assembly Instructions Manual

72” reversible shelf dumbbell kettlebell
Hide thumbs

Advertisement

Quick Links

Download this manual
ASSEMBLY INSTRUCTIONS
72" REVERSIBLE SHELF
DUMBBELL
KETTLEBELL
WS-5305
STILL NEED HELP WITH ASSEMBLY?
VISIT OUR ASSEMBLY LIBRARY HERE:
HELP.REPFITNESS.COM
R E P F I T N E S S
45-0217-V1
W W W .
. C O M

Advertisement

loading
Need help?

Need help?

Do you have a question about the WS-5305 and is the answer not in the manual?

Questions and answers

Related Manuals for REP WS-5305

Summary of Contents for REP WS-5305

  • Page 1 ASSEMBLY INSTRUCTIONS 72” REVERSIBLE SHELF DUMBBELL KETTLEBELL WS-5305 STILL NEED HELP WITH ASSEMBLY? VISIT OUR ASSEMBLY LIBRARY HERE: HELP.REPFITNESS.COM R E P F I T N E S S 45-0217-V1 W W W . . C O M...

  • Page 2: Hardware And Tools

    HARDWARE AND TOOLS 24MM 36MM COMBO WRENCH 15-1797 4000 SERIES BOLT, M16X2.00 BUSHING NUT, M16X2.00 WASHER, M16 115 MM LONG LENGTH 4MM NYLON INSERT SILVER SILVER 10-0624 SILVER 10-0023 10-0761 STEP 8 10-0024 STEPS 1, 2, STEPS 1, 2, STEPS 1, 2, 4, 5, 6, 8 4, 5, 6, 8 4, 5, 6, 8...
  • Page 3 PARTS DUMBBELL/KETTLEBELL SHELF WS-5305 STEPS 3, 7, 11, 15 4000 SERIES BOLT PLATE BOLT PLATE SINGLE FINGER DOUBLE FINGER 15-1809 15-1808 STEPS 1, 2, 4, 6 STEP 5 5000 SERIES BOLT PLATE BOLT PLATE SINGLE FINGER DOUBLE FINGER 15-1767 15-1766...
  • Page 4 SAFETY ONLY USE STORAGE SHELF/SHELVES AS INTENDED. TIPPING PREVENTION • RACK MOUNTING - IF MOUNTING TO A RACK, PLEASE ENSURE THE RACK IS STABLE BEFORE INSTALLING. IF THE RACK IS UN- STABLE, RETIGHTEN ALL HARDWARE. TO INCREASE STABILITY, PLEASE USE FRONT FOOT EXTENSIONS ON THE RACK OR MOUNT YOUR RACK TO THE FLOOR OR WALL.
  • Page 5 4000 SERIES 5000 SERIES R E P F I T N E S S W W W . . C O M...
  • Page 6 COMBO WRENCH WASHER, M16 NUT, M16X2.00 10-0023 NYLON INSERT 10-0024 BOLT PLATE SINGLE FINGER 15-1809 BOLT, M16X2.00 115 MM LONG 10-0761 15-1809 10-0023 10-0024 15-1809 10-0023 10-0761 ENSURE FINGERS POINT TOWARD OTHER UPRIGHT R E P F I T N E S S W W W .
  • Page 7 COMBO WRENCH WASHER, M16 NUT, M16X2.00 10-0023 NYLON INSERT 10-0024 BOLT PLATE SINGLE FINGER 15-1809 BOLT, M16X2.00 115 MM LONG 10-0761 10-0023 15-1809 10-0024 15-1809 10-0023 10-0761 ENSURE FINGERS POINT TOWARD OTHER UPRIGHT R E P F I T N E S S W W W .
  • Page 8 DUMBBELL/KETTLEBELL SHELF WS-5305 R E P F I T N E S S W W W . . C O M...
  • Page 9 COMBO WRENCH WASHER, M16 NUT, M16X2.00 10-0023 NYLON INSERT 10-0024 BOLT PLATE SINGLE FINGER 15-1809 BOLT, M16X2.00 115 MM LONG 10-0761 15-1809 10-0023 10-0024 15-1809 10-0023 10-0761 ENSURE FINGERS POINT TOWARD OTHER UPRIGHT MUST HAVE AN ADDITIONAL SHELF FOR CONTINUOUS SHELVING R E P F I T N E S S W W W .
  • Page 10 COMBO WRENCH WASHER, M16 NUT, M16X2.00 10-0023 NYLON INSERT 10-0024 BOLT PLATE DOUBLE FINGER 15-1808 BOLT, M16X2.00 115 MM LONG 10-0761 15-1808 10-0023 10-0024 15-1808 10-0023 10-0761 R E P F I T N E S S W W W . .
  • Page 11 COMBO WRENCH WASHER, M16 NUT, M16X2.00 10-0023 NYLON INSERT 10-0024 BOLT PLATE SINGLE FINGER 15-1809 BOLT, M16X2.00 115 MM LONG 10-0761 10-0023 15-1809 10-0024 15-1809 10-0023 10-0761 ENSURE FINGERS POINT TOWARD OTHER UP RIGHTS R E P F I T N E S S W W W .
  • Page 12 DUMBBELL/KETTLEBELL SHELF WS-5305 R E P F I T N E S S W W W . . C O M...
  • Page 13 COMBO WRENCH WASHER, M16 NUT, M16X2.00 10-0023 NYLON INSERT 10-0024 10-0023 10-0024 BUSHING 10-0624 10-0624 BOLT, M16X2.00 115 MM LONG 10-0761 10-0023 10-0761 10-0023 10-0024 10-0624 10-0023 10-0761 REPEAT STEP FOR THE OTHER SIDE R E P F I T N E S S W W W .
  • Page 14 COMBO WRENCH WASHER, M24 NUT, M24X3.00 10-0026 10-0315 BOLT PLATE BOLT, M24X3.00 WASHER, M24 SINGLE FINGER 115 MM LONG SPLIT LOCK 15-1767 10-0417 10-0310 10-0026 10-0310 15-1767 10-0315 15-1767 10-0026 10-0417 ENSURE FINGERS POINT TOWARD OTHER UPRIGHT R E P F I T N E S S W W W .
  • Page 15 COMBO WRENCH WASHER, M24 NUT, M24X3.00 10-0026 10-0315 BOLT PLATE BOLT, M24X3.00 WASHER, M24 SINGLE FINGER 115 MM LONG SPLIT LOCK 15-1767 10-0417 10-0310 15-1767 10-0026 10-0310 10-0315 15-1767 10-0026 10-0417 ENSURE FINGERS POINT TOWARD OTHER UPRIGHT R E P F I T N E S S W W W .
  • Page 16 DUMBBELL/KETTLEBELL SHELF WS-5305 R E P F I T N E S S W W W . . C O M...
  • Page 17 COMBO WRENCH WASHER, M24 NUT, M24X3.00 10-0026 10-0315 BOLT PLATE BOLT, M24X3.00 WASHER, M24 SINGLE FINGER 115 MM LONG SPLIT LOCK 15-1767 10-0417 10-0310 10-0026 10-0310 15-1767 10-0315 15-1767 10-0026 10-0417 ENSURE FINGERS POINT TOWARD OTHER UPRIGHT MUST HAVE AN ADDITIONAL SHELF FOR CONTINUOUS SHELVING R E P F I T N E S S W W W .
  • Page 18 COMBO WRENCH WASHER, M24 NUT, M24X3.00 10-0026 10-0315 BOLT PLATE BOLT, M24X3.00 DOUBLE FINGER WASHER, M24 15-1766 115 MM LONG SPLIT LOCK 10-0417 10-0310 15-1766 10-0026 10-0310 10-0315 15-1766 10-0026 10-0417 R E P F I T N E S S W W W .
  • Page 19 COMBO WRENCH WASHER, M24 NUT, M24X3.00 10-0026 10-0315 BOLT PLATE BOLT, M24X3.00 WASHER, M24 SINGLE FINGER 115 MM LONG SPLIT LOCK 15-1767 10-0417 10-0310 15-1767 10-0026 10-0310 10-0315 15-1767 10-0026 10-0417 ENSURE FINGERS POINT TOWARD OTHER UPRIGHT R E P F I T N E S S W W W .
  • Page 20 DUMBBELL/KETTLEBELL SHELF WS-5305 R E P F I T N E S S W W W . . C O M...
  • Page 21 COMBO WRENCH WASHER, M24 NUT, M24X3.00 10-0026 10-0315 10-0026 10-0310 BOLT, M24X3.00 WASHER, M24 115 MM LONG SPLIT LOCK 10-0315 10-0417 10-0310 10-0026 10-0417 10-0026 10-0310 10-0315 10-0026 10-0417 REPEAT STEP FOR THE OTHER SIDE R E P F I T N E S S W W W .
  • Page 22 REPEAT STEPS AS MANY TIMES AS DESIRED. FOR ANY REMAINING QUESTIONS PLEASE REACH OUT TO OUR CUSTOMER SUPPORT TEAM AT HELP.REPFITNESS.COM R E P F I T N E S S W W W . . C O M...
