K-array KK 200 Datasheet

KK200
3D line-array element
Features:
• Unique performance-to-size ratio
• Vertical, Horizontal and 3D line-array applications
• Multiple 2" long-excursion full-range cone drivers
• Wide horizontal coverage
• Electronically protected
• Integrated mounting hardware and accessories
• Selectable 4 Ohm or 16 Ohm impedance
• Selectable channel A or B
• Top quality components for outstanding
performance
• Weather proof, suitable for outdoor installations
• Available in black or white
Applications:
• Theatre, Club, Churches
• Front fi ll and under-balcony fi ll
• Portable and installed AV systems
• Stage and AV studio monitoring
The KK200 is a compact, line array element comprised of 32 x
2" neodymium transducers in a strong stainless steel chassis.
Its wide dispersion pattern can be confi gured horizontally
or vertically. A number of KK200 speakers can also be put
together in multiple array confi gurations. Due to their slim
profi le and minimum distance between drivers they exhibit
excellent phase coherent pattern control.
The speaker has an impedance of 16 Ohms eliminating the
need for 70volt transformers in distributed systems. The
KK200 reproduces the full vocal frequency range with clear
HP Sound Equipment s.r.l. Viale Roma 7/i - 50037 - San Piero a Sieve (FI), Italy
tel. +39 055 8487222 - fax. +39 055 8487238 - e-mail: info@k-array.com
DATASHEET
intelligibility. This can be augmented with the KKS50 or KL12
sub to extend the operating frequency range.
A variety of accessories provide numerous mounting options
for permanent and portable installations.
KA series amplifi ers have presets specifi cally optimized for
KK200 applications.
All KK200 components are designed by the K-array R&D
department and custom made under the K-array quality
control system.
