Putting the components into operation
28
Connecting external audio sources
You can connect an external audio source such as a CD
player, MP3 player, tape player, etc. to the bodypack
transmitter. (Please note that you cannot connect a
second microphone.) Both signals – the microphone
input signal and the line input signal – are mixed
together equally in the transmitter.
Connect the line output of the external audio
source to the line input
mitter.
Lock the plug by screwing down the coupling ring.
Switch the line input on as described on page 40.
Adjust the sensitivity of the line input as described
on page 41.
Mic input (dynamic):
Mic input (Electret):
Signal
Signal
LINE input: LINE input:
Signal
Attaching the bodypack transmitter to clothing
The bodypack transmitter is attached to clothing (e.g.
belt, waistband) with the supplied belt clip
The clip is detachable so that you can also attach the
bodypack transmitter with the antenna pointing
downwards. To do so, withdraw the clip
fixing points and attach it the other way round.
of the bodypack trans-
LINE input:
Signal Signal
.
from its
