Sennheiser HDE 2020-D Quick Manual

HDE 2020-D

FEATURES

Digital RF signal reception
Intuitive operating concept
8 hours battery life
Sturdy earbows
Backlit LC display
Large rotary volume control
ARCHITECT'S
SPECIFICATIONS
Digital Tourguide stethoset receiver
The HDE 2020-D
stethoset TourGuide receiver is
comfortable to wear and integrates both the receiver
and headphones. The powerful battery ensures up to
8 hours operating time. The stethoset receiver
automatically deactivates itself the moment that it
is taken off, thus battery life will be preserved. Tour
participants will be able to individually adjust the
volume through a rotary control on the receiver,
without the need to even take the device off. The
LC display provides information of volume, battery
status, quality of reception and the channel being
listened to. Channels can easily be set and adjusted by
using the middle buttons.

TECHNICAL DATA

Modulation: ........................................................... 2 FSK
RF frequency range ............................................. 863 - 865 MHz
Number of channels (tourguide mode) .......... 6
Number of channels (conference mode) ........ 8
Frequency response ............................................ 100 – 7,000 Hz
Sound pressure level ........................................... 120 dB SPL at 1 kHz
THD at 1 kHz ......................................................... < 1 %
Typical operating time ........................................ 8 hrs
Lithium polymer battery .................................... 830 mAh
Operating temperature ...................................... 0 – 50 °C
Dimensions ........................................................... 245 x 125 x 20 mm
Weight incl. Battery ............................................ 70 g (2.47 oz)
Delivery includes .................................................. HDE 2020-D (10 pcs), Manual
926 - 928 MHz (US-Version)
(9.65" x 4.92" x 0.79")
