AX1735
Skid plate
TM Racing MX85
What's in the box ?
2 NE01-11-001 - Special screws
4 NE01-04-003 - EM6F bolts
4 NE01-03-001 - M6 washers
4 NE01-02-005 - TFHC 6x35mm
2 NE01-04-002 - Clamped bolts
1 PM02-01-038 - Front steel fixation
1 PM01-10-022 - Rear hook 30mm
1 PM01-04-276 - Rear fixation 20mm
1 NE04-01-261 - Sticker
The paper instructions may be limitless, a tutorial video is available online to
help you.
Scannez le QR code pour regarder la vidéo de montage.
Approximate time of assembly: 15 minutes.
A skid plate is made to protect the vital components of your bike and does not have
a « life warranty ». However, production default may happen and we cover it during
the first year of use.
In case of premature breakage, please write to contact@axpracing.com
1
Place the clamped bolts in the
front steel fixation.
Follow the steps !
2
Clip the rear fixation and the hook together.
Assembling
instructions
