Elements DS650KH Assembly Instruction Manual

Thank you for purchasing this quality product. Be sure to check all packing material carefully for small Hardware which
may have come loose inside the carton during shipment. Identify and count all Hardware and compare with the Hardware
List Below.
PART LIST FOR HEADBOARD
NO. PART DESCRIPTION
A KING SLEIGH HEADBOARD
B KB/ QB SLEIGH HEADBOARD LEFT LEG
C
KB/ QB SLEIGH HEADBOARD RIGHT LEG
PART LIST FOR FOOTBOARD STORAGE
NO. PART DESCRIPTION
D KING FRONT FRAME FOOTBOARD
E KB/ QB STORAGE FRAME SUPPORT LEGS
F KING BOTTOM FRAME AND DRAWER
G KING BED SLAT
H KB/ QB LONG SLAT SUPPORT LEGS WITH LEVELER
I KB/ QB SHORT SLAT SUPPORT LEGS WITH LEVELER
PART LIST FOR STORAGE RAIL
PART DESCRIPTION
NO.
J KB/ QB FRONT FRAME SIDE RAIL (LEFT AND RIGHT)
K KB/ QB STORAGE FRAME SUPPORT LEGS
L KB/ QB BOTTOM FRAME AND DRAWER
Date: 2015-04-16
ASSEMBLY INSTRUCTION
ITEM NO: DS650KH
DS650KF
DS650QKR
CODE QTY.
1 PC
KBSHB
KBLGL 1 PC
1 PC
KBLGR
CODE QTY.
1 PC
3 PCS
SFSPL
1 SET
13 PCS
KBSLT
10 PCS
KQLSL
6 PCS
KQSSL
CODE QTY.
2 PCS
6 PCS
SFSPL
2 SET
MADE IN VIET NAM
Description: KING SLEIGH HEADBOARD
& FOOTBOARD STORAGE SLATS
& STORAGE RAIL
Hardware List (Packed Inside Headboard Box )
Description
NO.
1 JCBC Screw 1/4" x 55mm
2 Spring Washer 1/4"
Flat Washer 1/4" x 19mm
3
4
Allen Key
Hardware List (Packed Inside Footboard Box )
Description
NO.
5 JCBC Screw 1/4" x 60mm
6 Spring Washer 1/4"
7 Flat Washer 1/4" x 19mm
8
Allen Key
9 JCBC Screw 1/4" x 40mm
CBS Screw M3.5 x 12mm
10
CBS Screw M3.5 x 16mm
11
PH.Screw M3.5 x 22mm
12
Plate 6 holes 100mm x 30mm x 2mm
13
Screw M4 x 32mm
14
Hardware List (Packed Inside Rail Box)
Description
NO.
15 JCBC Screw 1/4" x 60mm
16
Spring Washer 1/4"
17
Flat Washer 1/4" x 19mm
18
Allen Key
19
Screw M3.5 x 12mm
20
Screw M3.5 x 22mm
21
Plate 6 holes 100mm x 30mm x 2mm
22
23
24
25
26
27
L Bracket
28
Screw M3.5 x 16mm
Qty.
8 PCS
8 PCS
8 PCS
1 PC
Qty.
4 PCS
6 PCS
6 PCS
1 PC
2 PCS
12 PCS
2 PCS
18 PCS
2 PCS
26 PCS
Qty.
8 PCS
8 PCS
8 PCS
1 PC
24 PCS
36 PCS
4 PCS
8 PCS
8 PCS
8 PCS
8 PCS
1 PC
4 PCS
8 PCS
Page 01 of 08
