Solar pump inverter
Hide thumbs Also See for SI22-D1 Series:

Advertisement

Quick Links

Contents
Chapter 1 Safety Requirement and Cautions ............................................ 1
1.1 Safety Definition .......................................................................... 1
Chapter 2 Specification and Basic Operation ............................................ 3
2.1 Technical Specification ................................................................ 3
2.2 Product Model ............................................................................. 3
2.3 Appearance and Dimension ........................................................ 4
2.4 Solar Pump Controller Wiring ...................................................... 5
2.5 Basic Operation ........................................................................... 6
Chapter 3 Parameters List ......................................................................... 7
Chapter 4 Operation Guidance ................................................................ 14
SI22 Solar Pump Inverter Manual
Chapter 1 Safety Requirement and Cautions
To ensure safety of your health, equipment and property, please read this chapter carefully before
using solar pump inverter and act in compliance with the instructions when installing,ebugging,
running and overhauling solar pump inverter.
1.1 Safety Definition
● Installation
1. Only qualified personnel can operate the equipment. Before operating, be sure to carefully
read the manual about safety, installation, operation and maintenance. The safe operation
depends on the proper processes of choosing models, carrying, installation, operation and
maintenance.
2. Please install solar pump inverter on metal or other nonflammable material, and keep it away
from the combustible material. Otherwise there is danger of fire;
●Wiring
Danger
1. Wire is connected only when the main circuit is cut off, otherwise there is a danger of shock.
2. Wire is connected by professional person only. Otherwise there is a danger of shock.
3. Earth must be reliable. Otherwise there is a danger of shock.
4. AC power supply should not be connected with output ports U, V, W, otherwise there is a
danger of damage to frequency inverter.
5. No drop of bolt, spacer, metal stick, conducting wire or other things into the inner of frequency
inverter; Otherwise there is a danger of fire or damage to frequency inverter.
●Electrification
Danger
1. Please make sure that voltage grade of power supply is consistent with frequency inverter's
voltage and then check whether the wiring is correct and firm, and whether there is short
circuit in peripheral equipment's circuit. Otherwise it will damage frequency inverter and other
equipment.
2. Before solar pump inverter is connected to the input power supply, make sure that the cover
SI22 Solar Pump Inverter Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SI22-D1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Veichi SI22-D1 Series

  • Page 1: Table Of Contents

    SI22 Solar Pump Inverter Manual SI22 Solar Pump Inverter Manual Contents Chapter 1 Safety Requirement and Cautions Chapter 1 Safety Requirement and Cautions ..........1 To ensure safety of your health, equipment and property, please read this chapter carefully before 1.1 Safety Definition ................
  • Page 2: Chapter 2 Specification And Basic Operation

    (KW) 1. Before running, please check and confirm the application range of the machine and (KW) equipment once more; Otherwise it will cause accidents. SI22-D1 series, DC60-400VDC input, 3 phase 110-230VAC output, suitable for 110VAC pump 0.75 0.75 175~380 0-320 2.
  • Page 3: Appearance And Dimension

    SI22 Solar Pump Inverter Manual SI22 Solar Pump Inverter Manual 2.3 Appearance and Dimension 2.4 Solar Pump Controller Wiring ● Standard Wiring for three phase motor output reactor (60-400VDC) Power Solar Pump Inverter Input shielded cables +24V (grounding resistor lower than 10 Ω) (forward running) +24V 线圈...
  • Page 4: Basic Operation

    SI22 Solar Pump Inverter Manual SI22 Solar Pump Inverter Manual 2.5 Basic Operation Chapter 3 Parameters List Indicator and Key ● Icon Name Function “●”:Stands for parameters can modify during running “〇”:Stands for parameters can’t modify during running Power ON: The power is 60-400VDC. “×”:Stands for parameter read only, can’t modify OFF: Power is abnormal.
  • Page 5 0:Asynchronous motor(AM) Note: If you need a detailed description of parameters, please download "AC100 Vector F5.00 Motor type 1:Permanent magnet motor × 0x500 (PM) Inverter manual" from https://www.veichi.org/ F5.01 Poles of motor 2~48 0x501 〇 F5.02 Rated power of motor 0.4~1000.0kW...
  • Page 6 SI22 Solar Pump Inverter Manual SI22 Solar Pump Inverter Manual ★ Photovoltaic Pump Special Parameters Low speed FE.15 0.0~3000.0s 10.0s 0xE0F ● protection detect time Low speed Default Comm FE.16 protection restore 0.0~3000.0s 10.0s 0xE10 ● Function name Setting range and definition setting .
  • Page 7 SI22 Solar Pump Inverter Manual SI22 Solar Pump Inverter Manual Read FE.37 Flow curve point 0 0.0~999.9m3/h 0xE25 C-01 Output frequency 0.01Hz 2101H ● m3/h only Read FE.38 Flow curve point 1 0.0~999.9m3/h ● 0xE26 C-02 Output current 0.1A 2102H m3/h only 10.0...
  • Page 8: Chapter 4 Operation Guidance

    SI22 Solar Pump Inverter Manual SI22 Solar Pump Inverter Manual will cause inverter damage. c. Connect motor wire and ground wire to corresponding U, V, W, E terminals. Chapter 4 Operation Guidance 2) Parameters setting and trial run: a) . Set F0.00 to 6, F0.02 for 0, and F0.09=100.00, F0.11=100.00; F0.14, F0.15 can be set according to demand.
  • Page 9 SI22 Solar Pump Inverter Manual SI22 Solar Pump Inverter Manual H. PQ Curve Function B. Low-frequency Protection Function This model provides a self-defined PQ curve for users to set up five groups of PQ corresponding During the operation of the photovoltaic pump, for some reason, the output frequency is lower than points according to the pump cases, to achieve real-time traffic speed, daily flow, cumulative flow, FE.14 (low frequency detection frequency), and after FE.15 (under frequency detection time) time, generating capacity, cumulative electricity consumption;...
