SI22 Solar Pump Inverter Manual
CONTENS
1. Security Tips .................................................................... 1
2. Technical Specification .................................................... 1
3. Product Model ................................................................. 1
4. Appearance and Dimension ............................................. 2
5. Solar Pump Controller Wiring .......................................... 3
6. Basic Operation ............................................................... 4
