DFI NP102-N16C User Manual page 71

Super IO Device
Move the cursor to this field and press <Enter>. The following screen will appear.
Power On Function
x Hot Key Power ON
PWRON After PWR-Fail
Onboard Serial Port 1
Serial Port 1 Use IRQ
Onboard Serial Port 2
Serial Port 2 Use IRQ
Onboard Serial Port 3
Serial Port 3 Use IRQ
Onboard Serial Port 4
Serial Port 4 Use IRQ
W83627DHG.WDT Time
: Move Enter: Select
↑↓→←
F5: Previous Values
The settings on the screen are for reference only. Your version may not be identical to
this one.
Power On Function
This field allows you to use the PS/2 keyboard or PS/2 mouse to power-on
the system.
Keyboard 98
When this option is selected, press the "wake up" key of the Windows 98
compatible keyboard to power-on the system.
Button only
Default setting. Uses the power button to power on the system.
Hot Key
When this option is selected, select the function key you would like to use to
power-on the system in the "Hot Key Power On" field.
Mouse Left
When this option is selected, double-click the left button of the mouse to
power-on the system.
Mouse Right
When this option is selected, double-click the right button of the mouse to
power-on the system.
Any Key
Press any key to power-on the system.
Phoenix - AwardBIOS CMOS Setup Utility
Super IO Device
BUTTON ONLY
Ctrl-F1
Off
3F8
IRQ4
2F8
IRQ3
3E8
IRQ10
2E8
IRQ11
0
+/-/PU/PD: Value F10: Save
F6: Fail-Safe Defaults
BIOS Setup
Item Help
Menu Level

ESC: Exit F1: General Help
F7: Optimized Defaults
3
71
