Features

Watchdog Timer
The Watchdog Timer function allows your application to regularly "clear" the sys-
tem at the set time interval. If the system hangs or fails to function, it will reset
at the set time interval so that your system will continue to operate.
CompactFlash
The system board is equipped with the CompactFlash
CompactFlash card. CompactFlash
TM
device designed with flash technology - a non-volatile storage solution that does
not require a battery to retain data indefinitely. The CompactFlash
is widely used in products such as portable and desktop computers, digital cam-
eras, handheld data collection scanners, PDAs, Pocket PCs, handy terminals and
personal communicators.
DDR2
DDR2 is a higher performance DDR technology whose data transfer rate delivers
bandwidth of 4.3 GB per second and beyond. That is twice the speed of the con-
ventional DDR without increasing its power consumption. DDR2 SDRAM modules
work at 1.8V supply compared to 2.6V memory voltage for DDR modules. DDR2
also incorporates new innovations such as the On-Die Termination (ODT) as well
as larger 4-bit pre-fetch against DDR which fetches 2 bits per clock cycle.
Graphics
The Intel 945GSE Express Chipset features an integrated 32-bit 3D graphics
®
engine based on the Intel
ing sophisticated graphics for large display applications. Graphics interfaces such
as single-channel SDVO, VGA and dual-channel LVDS support multiple graphics
display options.
LVDS
The Low-Voltage Differential Signaling (LVDS) interface allows the Intel Graphics
Media Adapter to communicate directly to the flat-panel display. The LVDS inter-
face supports pixel color depths of 18 and 24 bits.
PCI Express
PCI Express is a high bandwidth I/O infrastructure that possesses the ability to
scale speeds by forming multiple lanes. The x1 PCI Express lane supports trans-
fer rate of 2.5 Gigabytes (250MBbps) per second which is nearly 4 times faster
than the traditional PCI.
card is a small removable mass storage
TM
Graphics Media Accelerator 950 architecture; deliver-
®
Introduction
socket for inserting a
TM
technology
TM
1
11
