Dexter Laundry T1200 Installation & Operation Instructions

80lb capacity computer control coin washer
Hide thumbs Also See for T1200:
Table of Contents

Advertisement

Quick Links

See also: Owner's Booklet , Operator's Manual
P/N 8514-159-001C
DEXTER
LAUNDRY,
INC.
WARNING - THIS WASHER IS EQUIPPED WITH DEVICES AND FEATURES RELATING TO ITS SAFE
OPERATION. TO AVOID INJURY OR ELECTRICAL SHOCK, DO NOT PERFORM ANY SERVICING
UNLESS QUALIFIED TO DO SO.
IT IS THE RESPONSIBILITY OF THE OWNER TO CHECK THIS EQUIPMENT ON A FREQUENT
BASIS TO ASSURE ITS SAFE OPERATION.
A machine should not be allowed to operate if any of the following occur:
- Excessively high water level.
- If machine is not connected to a properly grounded circuit.
- If the door does not remain securely locked during the entire cycle.
- Vibration or shaking from an inadequate mounting or foundation.
1. Always shut off power and water supply before servicing.
2. Do not overload the washer.
3. Do not open door when cylinder is in motion or it contains water.
4. Do not bypass any safety devices of this washer.
5. Do not use volatile or flammable substances in or near this washer.
6. Keep all panels in place. They protect against shock and injury and add rigidity to the washer.
DAILY
- Check that the loading door remains securely locked and cannot be opened during the entire cycle.
- Check the water connections for leaks.
- Clean the top and sides of the cabinet to remove residue.
- Clean the soap dispenser and lid.
- Check the drain valve for leaking and that it opens properly.
- Check the loading door for leaks. Clean the door seal of all foreign matter.
- Leave the loading door open to aerate the washer when not in use.
QUARTERLY
- Make sure the washer is inoperative by switching off the main power supply.
- Check the V-belts for wear and proper tension.
- Clean lint and other foreign matter from around motor.
- Check all water connections for leaks.
- Wipe and clean the inside of the washer and check that all electrical components are free of moisture and dust.
- Remove and clean water inlet hose filters. Replace if necessary.
- Check anchor bolts - retighten if necessary
IMPORTANT: Replace any and all panels that were removed to perform daily and/or quarterly maintenance.
OWNER'S BOOKLET
INSTALLATION & OPERATION
INSTRUCTIONS
Please read this information and retain for reference.
WARNING - FOR SAFETY
PREVENTIVE MAINTENANCE REQUIREMENTS
MODEL T1200
80LB CAPACITY
COMPUTER CONTROL
COIN WASHER

Advertisement

Table of Contents
loading

Related Manuals for Dexter Laundry T1200

Summary of Contents for Dexter Laundry T1200

  • Page 1 P/N 8514-159-001C MODEL T1200 80LB CAPACITY COMPUTER CONTROL COIN WASHER DEXTER LAUNDRY, INC. OWNER'S BOOKLET INSTALLATION & OPERATION INSTRUCTIONS Please read this information and retain for reference. WARNING - THIS WASHER IS EQUIPPED WITH DEVICES AND FEATURES RELATING TO ITS SAFE OPERATION.
  • Page 2 1 Load laundry, close and latch door. 2 Add detergent and fabric softener Quarters Only into dispenser on front of machine. Detergent 3 Select wash temperature. 4 Insert coins/card. FINAL 5 Press START button. Bleach WASH RINSE RINSE SPIN 6 Add bleach when light comes on. (Optional) Fabric Softener Door Locks when machine starts, and...

  • Page 3: Installation Instructions

    MODEL T1200 DEXTER LAUNDRY, INC. INSTALLATION INSTRUCTIONS All washers must be installed in accordance with all local, state and national building, electrical, plumbing and other codes in effect in the area. WARNING - THESE INSTALLATION AND SERVICING INSTRUCTIONS ARE FOR USE BY QUALIFIED PERSONNEL ONLY. TO AVOID INJURY...
  • Page 4 CONCRETE PEDESTAL MOUNTING FLOOR OUTLINE Figure 1-1 Figure 1-2...

  • Page 5: Fusing Requirements

    PLUMBING Water supply hoses are furnished with each machine. The threaded connections on the hoses are ¾- 11 ½ NHT. The small 3/8 ID supply hoses and supplied brass shut off valves connect to the lower hot and cold valves which flush the soap box. The brass shut off valves can connect to either the store supply side or the machine inlet side.

  • Page 6: Controls Transformer

    CONTROLS TRANSFORMER: The controls transformer is located inside the control trough and steps a range of 208 to 240 volts down to 115 volts. There are two terminals on the controls transformer for the primary (incoming) power. Use the terminal marked “208V” for power supplies between 208 and 215 volts. Use the terminal marked “230V”...

  • Page 7: Emergency Stop / Safety Door Lock

    If the washer was stopped during final extract, the cycle will be ended. If the washer is stopped for more than 1 hour, the cycle will be terminated. SPECIFICATIONS MODEL T1200 80LB WASHER CAPACITY 80LBS/11.5 CUBIC FT. (36.3 kg/325 l) CYLINDER SIZE 30”...

  • Page 8: Programming Instructions

    PROGRAMMING INSTRUCTIONS: Programming can be accomplished manually using the machine controls or by connecting to the machine control using a PDA (personal digital assistant). For instructions on using a PDA with this washer control, please contact your local Dexter distributor. Please read below for manual programming instructions.
  • Page 9 WATER TEMPERATURE PRICING The washer can be set for different levels of pricing for Cold, Warm and Hot water. The Cold water setting is considered as the base price, which is the normal washer cycle price. Stage 4: Warm Water Price – The next step in the pricing program is to set the additional price for Warm water usage.
  • Page 10 WASH CYCLE PROGRAMMING To change a feature of the wash cycle, push and hold the Hot temperature button and then push the programming pushbutton on the controller. The Washer must be in the Idle mode to enter the Wash Cycle Programming mode. When entering the cycle programming mode, the Bleach LED will start to blink and continue to blink as long as you are in the Cycle Programming mode.
  • Page 11 additional push of the Up button, the lit bath mode changes from left to right: Prewash, Wash, Rinse and Final Rinse. As there are two possible Rinse bathes, for Rinse1 the Rinse LED and the display changes to “b” in the left digit and “r1" in the two right hand digits. For Rinse2, the display changes to “b”...
  • Page 12 COIN WASHER CYCLE PARAMETER RANGES The range of each cycle parameter is shown below: Cycle Time “ct” 0 to 15 minutes for Prewash, Rinse1 and Rinse2 3 to 15 minutes for Wash and Final Rinse For the bathes that can, if the time is set to zero, then the bath will be eliminated from the cycle.

  • Page 13: Rapid Advance Mode

    RAPID ADVANCE MODE To enter the Rapid Advance mode, push and hold the Cold water temperature button and then push the programming button on the controller. There will be no observed change to the washer or the display. The Rapid Advance mode can be entered from either the Idle mode or during the cycle.
  • Page 14 SETTING THE ELECTRONIC COIN ACCEPTOR SWITCHES Some washer models come equipped with an electronic coin acceptor. Follow the instructions below for setting the switches for the desired country and currencies. 1) The electronic coin acceptor has switch settings depending on the coins and country. See the table below for available values of the left and right coin inputs for the available countries.
  • Page 15 WASHER ERROR CODES Fault# Description Customer Action (F #) The door failed to close and lock or the door Turn off the power to the washer. Check wire connections to door /lock switches. Check wire failed to remain locked after three tries of connections from switches to controller.
  • Page 16 The drive size setting has changed. Turn off the power to the washer. Check to ensure all the harnesses are properly connected to the controller. Check to ensure the drive horsepower is proper for this size of washer. Turn on power to the washer. (See Note) If problem reappears, contact your Dexter representative.
  • Page 17 ACCESSORIES INSTALLATION: (Furnished) QTY. 9990-027-013 Hose, Water Supply 9990-027-011 Hose, Water Supply 9379-197-001 Valve, Shut Off 8641-242-000 Washer, Inlet Hose 9565-003-001 Strainer, Inlet Hose Contact your distributor or Dexter Laundry, Inc. if a steel-mounting base is required. www.dexterlaundry.com...
