Dexter Laundry WCVD Series Parts And Service Manual

Opl washers
Hide thumbs Also See for WCVD Series:
Table of Contents

Advertisement

Quick Links

USE THE BLUE TABS LOCATED ON THE
RIGHT AND LEFT SIDES OF THE FOLLOWING
DOCUMENT TO ADVANCE TO EACH SECTION.
8533-075-001 6/22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WCVD Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dexter Laundry WCVD Series

Summary of Contents for Dexter Laundry WCVD Series

  • Page 1 USE THE BLUE TABS LOCATED ON THE RIGHT AND LEFT SIDES OF THE FOLLOWING DOCUMENT TO ADVANCE TO EACH SECTION. 8533-075-001 6/22...
  • Page 2 Equipment Safety Warnings Symbols and Terminology Used in this Equipment Indicates an imminently hazardous situation, which if not avoided, will result in death or serious injury. Indicates a potentially hazardous situation, which if not avoided could result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
  • Page 3 Equipment Safety Warnings Indicates an imminently hazardous situation, Symbols and Terminology Used in this Equipment which if not avoided, will result in death or seri- ous injury. Indicates a potentially hazardous situation, Warning! Do not operate equipment if door glass is which if not avoided could result in death or damaged in any way.
  • Page 4 WARNING WARNING • All washers must be installed in accordance to all applicable electrical, plumbing and all other local codes. Children should be supervised to ensure they do not operate or play • These installation and operation instructions are in or around equipment. for use by qualified personnel only.
  • Page 5 Warning! Do not operate equipment if door glass is Prohibited! Do not attempt to open, touch, or pro- damaged in any way. ceed before referring to the manual or unless quali- fied. Mandatory! Read all supporting documentation be- Warning! Keep clear of rotating parts. fore operating or maintaining equipment.

  • Page 6: Table Of Contents

    Dexter Safety Table of Contents Notes Guidelines Section 1: Machine Mounting & Installation WARNING T-750 .............14 T-900 & T-950..........15 T-1200 & T-1450 ..........16 T-750 Installation ...........17 These washers are equipped with devices and T-900 Installation ...........18 features relating to their safe operation. To avoid injury or electrical shock, do not perform T-950 Installation ...........19 and service, unless qualified to do so.
  • Page 7 Section 9: Back Panel Removal ........48 Display Push Button .........61 50 Hz Models Drain Valve Access .........48 Drain Valve Cleaning ........48 Delta Variable Frequency Drive .......62 -59 Parts..........164 & 165 Detergent Dispenser ........48 Delta VFD Motor Leads........62 -21 Parts............166 Vaccuum Breaker/ Delta VFD Dynamic Braking 50HZ Diagrams &...
  • Page 8 Mounting Dimensions Section 1: Machine Mounting Dexter Laundry, Inc. 2211 W. Grimes, Fairfield, Iowa 52556 www.dexterlaundry.com 1-800-524-2954 © Rev. 9. 3/2011, Dexter Laundry, Inc. Dexter reserves the right to change specifications without notice. Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...
  • Page 9 T-950 Machine Dimensions www.dexterlaundry.com Dexter Commercial T-950 Express Washer T-1450 Machine Dimensions 1-800-524-2954 Mounting Dimensions © Rev. 3. 3/2009, Dexter Laundry, Inc. 12 13/16” Dexter reserves the right to change specifications without notice. 7 &200(5&,$/ :$6+(5 27 1/8” 2 3/4”...
  • Page 10 T-900 Mounting Pad Dimensions T-750 Mounting Dimensions CONCRETE PEDESTAL MOUNTING FLOOR OUTLINE CONCRETE PEDESTAL MOUNTING FLOOR OUTLINE Figure 1-1 Figure 1-2 Figure 1-1 Figure 1-2 Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...
  • Page 11 T-950 Mounting Dimensions T-1200 Mounting Pad Dimensions CONCRETE PEDESTAL MOUNTING FLOOR OUTLINE CONCRETE PEDESTAL MOUNTING FLOOR OUTLINE Figure 1-1 Figure 1-2 Figure 1-1 Figure 1-2 Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...
  • Page 12 T-1450 Mounting Pad Dimensions Notes Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...

  • Page 13: Installation

    Washer Installation All washers must be installed in accordance with all local, state and national building, electrical, and plumbing codes in effect in the area. Foundation Requirements The washer must be securely bolted to a substantial concrete floor, or mounted upon a suitable base which is securely bolted and machine grouted to a substantial concrete floor.
  • Page 14 Liquid Chemical Connection To Make Electrical Connections In the left rear corner of the washer is the chemical injection as- Disconnect all power to the washer. Remove screw and lift out the cover located in the upper left corner sembly. This is where all chemical hose connections are made. of the machine (as viewed from the back).

  • Page 15: Detergent Measurements By Model

    Washer Operating Instructions Detergent Measurements By Washer Model Safety Door Lock This machine is equipped with a Safety Door Lock that locks the door closed from when the cycle is started until the cycle is complete. The door lock prevents opening the door for up to 3 minutes if the power is interrupted during the cycle.
  • Page 16 TRANSIENT VOLTAGE SURGE SUPPRESSORS Notes Like most electrical equipment your new machine can be damaged or have its life shortened by voltage surges due to lightning strikes which are not covered by factory warranty. Local power distribution problems also can be detrimental to the life of electrical components. We recommend the installation of transient voltage surge suppressors for your new equipment.

  • Page 17: Machine Programming Instructions

    Bath Cycle Time “ct” 0 to 15 minutes for Prewash, Rinse1 and Rinse 3 to 15 minutes for Wash and Final Rinse. For the baths that can, if the time is set to zero, then that bath will be eliminated from the cycle. Bath Water Temperature “t”...
  • Page 18 Cycle 1: Sheets and Pillowcases (Health Care) Cycle 4: Guest Laundry (Hotel / Motel / Healthcare) Bath Bath Cycle Water Water Delay Spin Injection Bath Bath Cycle Water Water Delay Spin Injection Time (min) Temp. Level Fill Time (min) Source Time (min.) Temp.

  • Page 19: Rapid Advance Mode

    Washer Programming Instructions Rapid Advance Mode To enter the Rapid Advance mode, turn the key CCW. The Rapid Advance setting is not marked next to THERE ARE TWO WAYS TO MODIFY PROGRAMMING OF THE V-SERIES OPL SIX (6) the key, but turning the CCW until it stops selects this mode. The Rapid Advance mode can be entered PREPROGRAMMED FORMULAS from either the Idle mode or during the cycle.
  • Page 20 Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...
  • Page 21 Notes Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...

  • Page 22: Trouble Shooting

    Common Troubleshooting Solutions Symptom Probable Cause Suggested Remedy Machine Power Supply Check these areas: Circuit breakers, Voltage, Power leads, does not Power connections. Is front display LED showing a dollar start amount. Door Switch Check for continuity through door switch when door is closed.
  • Page 23 Common Troubleshooting Solutions Common Troubleshooting Solutions Symptom Probable Cause Suggested Remedy Symptom Probable Cause Suggested Remedy Hot water Water Valve Coil Check coil continuity at terminals and replace if no continuity. Machine Check VFD by removing inspection panel and record any does not Check for 120 V power from main relay PCB does not...

  • Page 24: Troubleshooting Machine Fault Errors

    Troubleshooting Machine Fault Errors Fault# Description Customer Action Wrong size drive installed Check VFD fault code before turning off power.Check to ensure all the harnesses are properly connected to the The following are descriptions of fault codes that will appear on the front of the washer. There is a chart format that shows what fault code that will be displayed at washer front.
  • Page 25 Fault# Description Customer Action Fault# Description Customer Action The temperature sensor Step 1: Make sure the cooling fins on the VFD heatsink The variable frequency Check the data communication cable between the inside of the variable and the ventilation louvers on the VFD cooling fan cover drive (VFD) and the washer computer and the variable frequency drive frequency drive detects that...

  • Page 26: Variable Frequency Drive Control Digital Readout Faults

    Variable Frequency Drive Control Optional water valve PCB Soft reset control. Digital Readout Faults removed or water valve has been replaced . Fault# Description Customer Action VFD unit has been added or Soft reset control. loose connection. VFD received an illegal Reset drive.
  • Page 27 Variable Frequency Drive Control Notes Digital Readout Faults Fault# Description Customer Action OL or Overload of the drive or (Check drive fault code before powering down). Check motor the washer motor to ensure it turns freely. Check the wiring for loose connections to the drive and motor.

  • Page 28: Machine Service Procedures

    Top Panel Removal Top Soap Dish Step 1: Remove 4 screws that hold detergent dispenser to top panel. (for T750, T900, T950) Step 2: Unlock top panel lock. Step 3: Raise top panel, slide to the rear to release from back clips and lift off. Top Panels Removal Front Soap Dish Step 1: Unlock top panel locks.

  • Page 29: Air Gap

    Vacuum Breaker (also called an air gap) Door cam Flat blade screw on In the left rear of the cabinet is the vacuum breaker. It guides the water to the tub and dispenser and prevents check position door switch latching a back flow of water.

  • Page 30: Adjusting The Loading Door

    Loading Door Disassembly Adjusting the Loading Door Step 1: Remove the loading Step 2: While holding down on Step 3: Work all the way around door as outlined above. the door glass, lift up the gasket and the glass The door can be adjusted by changing the number of shims behind the door hinge and the door lock Lay the door on a flat on the door ring and roll is out.

  • Page 31: Door Locking Solenoid

    Cylinder (basket) Door Locking Solenoid (Original Models) Step 1: Remove the top panel as described previously. The door locking solenoid is powered shut with Step 2: Remove lower service panel as described previously. control voltage to lock the door and releases when Step 3: Remove front panel as described previously.
  • Page 32 Water Seals Reassembly of the Cylinder Replacement Step 1: Use the hub of the drive pulley, a stack of 5/8” flat washers and a 3” long 5/8” bolt to pull the cylinder shaft through the bearings. After the 3” bolt a 2” long bolt will be required to finish pulling Step 1: the cylinder shaft through.

  • Page 33: Bolt Torque Chart

    Notes T-750 Bolt Torque Chart Bolt Size Where Used Torque 1/2”x 1 1/4” bolt Tub End of Bearing Hsing. 9545-017-009 70-110 ft/lbs 5/8”x 1 1/2” bolt Tub End of Bearing Hsing. 9545-060-001 120-150 ft/lbs 1/2”x 1 1/4” bolt Mtg. of Tub to Cradle Asy. 9545-017-009 70-110 ft/lbs 5/8”x 2 1/2”bolt Mtg.

  • Page 34: Control Mounting Trough

    Control Mounting Trough Remove top panel to access control trough. (see Removing Top Panel) It sets on the right side of the machine and holds the control PCB’s, transformers,and pressure switch. Main Data Communication Cable Goes between front PCB board and Variable Frequency Drive unit mounted center rear of machine. It has telephone type connectors at each end and is inserted at Controller PCB and the Variable Frequency Drive.

  • Page 35: Pressure Switch

    Add-Bleach LED This LED light indicates to the user the correct time to add bleach. This LED is polarity sensitive and must Delta Variable Frequency Drive: be connected correctly. Main power is connected to terminals L1, L2, and L3 on the Delta drive. If the washer is connected to a Pressure Switch Caution (Not recommended by Factory!) three phase source, there should be voltage present on all three terminals.

  • Page 36: Start Circuit

    Electrical Path Circuit Schematics Start Circuit Power travels into the machine on L1 & L2 & (L3) ( if 3 phase used). 208- 240VAC goes to a Control Transformer ( must be checked at start -up to coincide with machine operating voltage) that steps the voltage down to 115VAC for the controls.

  • Page 37: Wash Circuit

    Wash Circuit Notes As the washer fills the tub through the back of the machine with either one or both the C1 Cold and H1 Hot Water Valves, the Wash Basket will tumble one direction for 12 seconds, pause, and then reverse di- rection for 12 seconds.
  • Page 38 50lb Express Notes WCVD50HCB-12SZ Schematic Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...
  • Page 39 60lb 100G 50lb Express WCVD60HCB-12 Schematic WCVD50HCB-12SZ Diagram Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...
  • Page 40 60lb 100G 60lb Express WCVD60HCB-12 Diagram WCVD60HCB-12SZ Schematic Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...
  • Page 41 60lb Express 80lb 100G WCVD60HCB-12SZ Diagram WCVD80HCB-12 Schematic Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...
  • Page 42 80lb 100G 90lb Express WCVD80HCB-12 Diagram WCVD90HCB-12SZ Schematic Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...
  • Page 43 90lb Express Notes WCVD90HCB-12SZ Diagram Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...
  • Page 44 Kits, Assemblies, & Common Parts V-Series Accessories Loading Door & Door Lock Components Part Number *WCVD45HC_-12SZ 208-240 volts 60hz. Single Phase or Three Phase Door Glass Gasket (Large Door) 9206-431-001 (Parts differences for the regular door T650 will be found on pages 104-105) Door Glass Gasket (Standard Door) 9206-419-001 Door Handle Only (Small)

  • Page 45: Parts Data

    Wiring Harness Part # by Model Description T750 T-900 T950 T-1200 T1450 Wiring Harness (Add Bleach Lite 9794-001-001 9794-001-001 9794-001-001 9794-001-001 9794-001-001 assy included) Wiring Harness, Door Lock 9627-791-005 9627-791-005 9627-791-005 9627-791-005 9627-791-005 Wiring Harness, 9627-796-002 9627-796-002 9627-796-002 9627-796-002 9627-796-002 Drain,Thermo,DoorSol Data Cable 9806-015-001...

  • Page 46: Cabinet And Front Panel Group Part

    Cabinet and Front Panel Group Part # by Model Large Door Before Serial # 535659 Description T750 T-900 T950 T-1200 T1450 Panel, Side (Left or Right) - 9454-812-001 stainless Panel, Side (Left or Right) - 9454-813-001 9732-359-003 stainless Bolt-1/4-20x1/2 (side panel Front 9545-018-013 9545-018-013 9545-018-013...
  • Page 47 Cabinet and Front Panel Group Part # by Model Large Door After Serial # 535659 Description T-750 T-900 T950 T-1200 T1450 Panel, Side (Left or Right) - 9454-812-001 stainless Panel, Side (Left or Right) - 9732-359-002 9732-359-002 9732-359-003 9732-359-004 stainless Bolt-1/4-20x1/2 (side panel Front 9545-018-013 9545-018-013...

  • Page 48: Soap Dish

    Cabinet and Front Panel Group Part # by Model Top Mount Detergent Dispenser Front Soap Dish Description T-750 T-900 T-950 T-1200 T-1450 Dispenser Soap 9122-005-004 9122-005-004 Nut, Spring ss 8640-399-007 8640-399-007 3&4 Flow restictors 9475-002-002 9475-002-002 Flow restictors Optional (Smaller) 9475-002-003 9475-002-003 Door, Dispenser 9108-095-005...

  • Page 49: Rear View Access Part # By Model

    Rear View Access Part # by Model Description T-750 T-900 T-950 T-1200 T-1450 Drive Motor, 3 Phase (Inverter 9376-298-001 9376-308-001 9376-298-001 9376-298-001 9376-328-001 duty) Rod, Motor Mtg 9497-222-004 9497-222-004 9497-222-004 9497-222-004 9497-222-004 10,11 Collar, Shaft (w/set screws) (old) 9076-052-002 9076-052-002 9076-052-002 9076-052-002 Motor Bushing (plastic)
  • Page 50 Rear View Access Part # by Model Continued Description T-750 T-900 T-950 T-1200 T-1450 Channel, Rear 9081-148-001 9081-152-001 9081-152-002 9081-140-001 9081-153-001 Screw #10Bx1/2 9545-008-026 9545-008-026 9545-008-026 9545-008-026 9545-008-026 Nut, Spring 8640-399-008 8640-399-008 8640-399-008 8640-399-008 8640-399-008 Plate-Cover, Water Valves 9452-794-001 Screw, 10Bx1/2 9545-008-026 Plug, 7/8”...

  • Page 51: Cylinder, Seals & Bearings Part

    Cylinder, Seals & Bearings Part # by Model Description T-750 T-900 T-950 T-1200 T-1450 Bearings and Seal Kit 9732-219-007 9732-219-007 9732-219-007 9732-219-007 9732-219-009 Housing, Bearing- Assembly (items #2-#6) 9803-187-001 9803-187-001 9803-187-001 9803-187-001 9803-209-001 Housing, Bearing 9241-181-004 9241-181-004 9241-181-004 9241-181-004 9241-195-003 Bearing, Front (LARGE) 9036-159-006 9036-159-006...
  • Page 52 Door Lock Assembly (All Models) Gear Motor Door Lock Assembly Description T-750 T-900 T-950 T-1200 T-1450 Actuator Assembly (Includes 1-10, 9892-015-001 9892-015-001 9892-015-001 9892-015-001 9892-015-001 Rod NOT included) Screw - hxwshdsl 10-24 - 1.25f, 9545-046-007 9545-046-007 9545-046-007 9545-046-007 9545-046-007 Key Description All Models Key Description All Models...
  • Page 53 Original Door Lock Solenoid Assembly Original Door Lock Solenoid Assembly Key Description T-750 T-900 T-950 T-1200 T-1450 Solenoid Ass’y, Door Locking 9922-011-001 9922-011-001 9922-011-001 (includes 23 thru 32) Bracket, (Door Locking Sole- 9029-073-001 9029-073-001 9029-073-001 noid) Bracket Ass’y, Solenoid Slide 9985-169-001 9985-169-001 9985-169-001...
  • Page 54 Large Door & Hinge Group (After #514975) Description T750 T-900 T950 T-1200 T1450 Shaft, Door Locking 9537-195-002 9537-195-002 9537-195-002 9537-195-002 9537-195-002 Description T-750 T-900 T-950 T-1200 T-1450 Cam, Locking 9095-040-002 9095-040-002 9095-040-002 9095-040-002 9095-040-002 Door Hinge Assembly (mounts 9955-031-001 9955-031-001 9955-031-001 9955-031-001 9955-031-001...
  • Page 55 Loading Door and Panel Differences For T650 Express - 45lb Express Machine Notes Description T-650 Loading Door, Complete #1-10 9960-274-002 Loading Door, Ring 9487-265-001 Gasket, Loading Door 9206-419-001 Window, Loading Door 9635-016-001 Shaft Assy, Locking (includes 4 9913-134-003 thru 7) Shaft, Door Locking 9537-195-002 Cam, Locking...

  • Page 56: Water Inlet Part # By Model

    Water Inlet Part # by Model Description T 750 T-900 T-950 T-1200 T-1450 Injector Assembly 9883-005-001 9883-005-001 9883-005-001 9885-005-001 9885-011-001 Valve, Water Inlet (dual outlet) (see 9379-183-003 9379-183-003 9379-183-003 9379-183-003 9379-183-003 Water Inlet Valve Breakdown for individual parts) Screw, Valve Mtg 9545-008-026 9545-008-026 9545-008-026...
  • Page 57 Water Inlet Valve Breakdown Part # by Model Key Description T-750 T-900 T-950 T-1200 T-1450 Valve, Water Inlet (includes 1 thru 9379-183-012 9379-183-012 9379-183-012 9379-183-012 9379-183-012 6) - Invensys Screen, Inlet end of valve 9555-056-001 9555-056-001 9555-056-001 9555-056-001 9555-056-001 Coil Assy., 120 V Invensys 9089-017-001 9089-017-001 9089-017-001...

  • Page 58: Drain Valve Group Part # By Model

    Drain Valve Group Part # by Model Notes Key Description T-750 T-900 T-950 T-1200 T-1450 Valve, Drain (includes #2 thru 9379-202-001 9379-202-001 9379-202-001 9379-202-001 9379-202-001 #11) Body, Valve (w/ball) 9064-070-001 9064-070-001 9064-070-001 9064-070-001 9064-070-001 Motor & Gear Train (complete) 9914-137-011 9914-137-011 9914-137-011 9914-137-011...

  • Page 59: Chassis And Drain Part # By Model

    Chassis and Drain Part # by Model Description T750 T-900 T950 T-1200 T1450 Base Assy,Frame 9945-112-002 9945-155-002 9945-155-002 9945-125-002 9945-133-002 Outer Tub Assy Before Serial 9930-148-001 9930-147-001 9930-150-001 #535659 Outer Tub Assy After Serial 9930-157-001 9930-157-001 9930-155-001 #535659 Tub & Cylinder Assy Before 9869-025-001 9869-023-003 9869-022-001...

  • Page 60: Electrical Components

    Electrical Components - Top Compartment Electrical Components - Top Compartment Description T-750 T-900 T-950 T-1200 T-1450 Trough Assy,Controls 208-240 9857-159-001 9857-154-002 9857-154-002 9857-160-002 9857-191-002 volt (all parts below #2-#43 & trough) Trough only 9839-015-001 9839-015-001 9839-015-001 9839-015-001 9839-017-001 Screw, Trough Sides 9545-008-026 9545-008-026 9545-008-026...

  • Page 61: Control Panel Part # By Model

    Control Panel Part # by Model 5, 6 Description T-750 T-900 T-950 T-1200 T-1450 Panel Control Assembly(panel 9989-480-001 9989-480-001 9989-480-001 9989-480-001 9989-530-001 only) After Serial #530673 Nameplate,Control Panel (one 9412-163-001 9412-119-001 9412-134-001 piece) Blue Nameplate,Control Panel (one 9412-185-001 9412-186-001 9412-187-001 9412-189-001 9412-195-001 piece) Black...

  • Page 62: Labels And Diagrams All Wcad Models

    Labels and Diagrams All WCVD Models Notes Description T750 T-900 T950 T-1200 T1450 Booklet Owners 8514-160-001 8514-161-001 8514-161-001 8514-162-001 8514-206-001 Wiring Diagram, Coin 9506-366-001 9506-019-001 9506-487-001 9506-049-001 9506-489-001 Wiring Schematic, 9506-365-001 9506-020-001 9506-050-001 Transient Voltage Surge Sup- 8507-330-001 8507-330-001 8507-330-001 8507-330-001 8507-330-001 pressor Infomational...

  • Page 63: Parts

    Transformer, Electrical Filter -59 models Key Component T-750 T-900 T-950 T-1200 T-1450 Circuit Breaker 5198-211-002 5198-211-002 5198-211-002 Harness, Power Ter- 9627-865-003 9627-865-003 9627-865-003 minal block Assembly, Control 9857-159-006 9857-154-006 9857-160-006 Trough Instructions, Trans- 8507-230-003 8507-230-003 8507-230-003 former Connect Control Transformer 8711-008-002 8711-008-002 8711-008-002...
  • Page 64 -59 models Water Valve, Drain Valve -59 models Key Component T-750 T-900 T-950 T-1200 T-1450 Key Component T-750 T-900 T-950 T-1200 T-1450 Water Valve (Duel) 24V 50Hz 9379-183-013 9379-183-013 9379-183-013 Bracket, Switch- 9029-182-001 Screen, Inlet end of valve 9555-056-001 9555-056-001 9555-056-001 Instability Diaphragm Invensys (EPDM)
  • Page 65 Gear Motor Door Lock Assembly 24V AC Original Door Lock Solenoid Assembly Key Description T-750 T-900 T-950 T-1200 T-1450 Solenoid Ass’y, Door Locking 9922-011-001 9922-011-001 9922-011-001 (includes 23 thru 32) Bracket, (Door Locking Sole- 9029-073-001 9029-073-001 9029-073-001 noid) Bracket Ass’y, Solenoid Slide 9985-169-001 9985-169-001 9985-169-001...
  • Page 66 WCVD50HC_-59SZ 230/50/1 Voltage Schematic Original Door Lock Solenoid Assembly 11, 12, 13 Part # 8533-075-001 6/22...
  • Page 67 WCVD50HC_-59 230/50/1 Voltage Diagram WCVD60HC_-59 230/50/1 Voltage Schematic...
  • Page 68 WCVD60HC_-59 230/50/1 Voltage Diagram WCVD80HC_ -59CN 230/50/1 Voltage Schematic Part # 8533-066-001 5/11 Part # 8533-075-001 6/22...
  • Page 69 WCAD80KCB -59CN 230/50/1 Voltage Diagram Notes Part # 8533-075-001 6/22 Part # 8533-066-001 5/11 Part # 8533-075-001 6/22...

  • Page 70: Maintenance

    Preventative Maintenance Daily Step 1: Check that the loading door remains securely locked and cannot be opened during an entire cycle. Step 2: Clean the top, front, and sides of the cabinet to remove residue. Step 3: Clean the soap dispenser and lid and check that all dispenser mounting screws are in-place and tight.
  • Page 71 Notes Notes Part # 8533-075-001 6/22 Part # 8533-075-001 6/22...
