GS-S12-P10R
GS-S12-P04R
GS-S12-P04S
User's Manual
Rev. 1001
28A08-0S12M-0CAR
To reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GS-S12-P10R and is the answer not in the manual?

Questions and answers

Related Manuals for Gigabyte GS-S12-P10R

Summary of Contents for Gigabyte GS-S12-P10R

  • Page 1 GS-S12-P10R GS-S12-P04R GS-S12-P04S User's Manual Rev. 1001 28A08-0S12M-0CAR To reduce the impacts on global warming, the packaging materials of this product are recyclable and reusable. GIGABYTE works with you to protect the environment.
  • Page 2 Information in this manual is protected by copyright laws and is the property of GIGABYTE. Changes to the specifications and features in this manual may be made by GIGABYTE without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without GIGABYTE's prior written permission.
  • Page 3 Server Warnings and Cautions Before installing a server, be sure that you understand the following warnings and cautions. WARNING! To reduce the risk of electric shock or damage to the equipment: • Do not disable the power cord grounding plug. The grounding plug is an important safety feature.
  • Page 4 Electrostatic Discharge (ESD) CAUTION! ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE, PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP ATTACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER WHEN HANDLING PARTS.

  • Page 5: Table Of Contents

    Installing the Memory ..................25 Installing the PCI Expansion Card ..............27 Installing the Hard Drive ................. 29 Installing the Redundant Power Supply for GS-S12-P04R/GS-S12-P10R ... 30 Back Panel Connectors .................. 31 Internal Connectors ..................32 Chapter 5 BIOS Setup ....................42 Startup Screen ....................

  • Page 6: Chapter 1 Model Lineup

    Chapter 1 Model Lineup 1U Server Module Model • GS-S12-P04R/GS-S12-P04S (4-Bay) HDD00 HDD01 HDD02 HDD03 • GS-S12-P10R (10-Bay) HDD01 HDD03 HDD05 HDD07 HDD09 HDD00 HDD02 HDD04 HDD06 HDD08 - 6 -...

  • Page 7: System Components

    System Components Riser System fan #1 Power Supply Unit System fan #3 (Redundant type for GS-S12-P04R/ System fan #4 GS-S12-P10R) System fan #5 Power Supply Unit (Single type for GS-S12-P04S) System fan #6 DDR4 Memory (for CPU1/Primary) Hard Disk Drives...
  • Page 8 Box Contents 5 GS-S12-P10R, GS-S12-P04R, or GS-S12-P04S Barebone 5 Driver disk 5 Quick installation guide 5 User’s manual 5 CPU1 heatsink 5 CPU2 heatsink 5 Rail kit 5 Two power cords (GS-S12-P10R, GS-S12-P04R) 5 One power cord (GS-S12-P04S) - 8 -...

  • Page 9: Chapter 2 Hardware Installation

    Chapter 2 Hardware Installation Installation Precautions The motherboard/system contain numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user's manual and follow these procedures: • Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or warranty sticker provided by your dealer.

  • Page 10: Server System Features

    Server System Features • Remote KVM (Graphics console and HTML5 support) • Virtual Media and Media Redirection (ISO images) • Remote server power control • Remote Serial over LAN (Text console) • Event Log and Alerting support • Automatic Notification and Alerts (SNMP and email) •...

  • Page 11: Content Specifications

    Front Side (Option): 4x3.5” SAS hot-swappable HDD bays (Add-in SAS HBA Card) Internal: 2 x 2.5” SAS hot-swappable SSD bays (Onboard) GS-S12-P10R: Š Front Side: 10 x 2.5” SATA hot-swappable HDD bays (Onboard) Front Side (Option): 10 x 2.5” SAS hot-swappable HDD bays (Add-in...
  • Page 12 Internal 1 x 24-pin ATX main power connector Š Connectors 2 x 8-pin ATX 12V power connectors Š 2 x CPU fan headers Š 6 x system fan headers Š 1 x M.2 Socket 3 connector Š 10 x SATA 6Gb/s connectors Š...
  • Page 13 Non-operating humidity: 5% - 95% Š System Š Dimension 438.5mm (W) x 43.5mm (H) x 660mm (D) Š * GIGABYTE reserves the right to make any changes to the product specifications and product-related information without prior notice. - 13 -...

  • Page 14: Motherboard Layout

    Motherboard Layout 34 BMC_LED1 32 F_LED1 BMC_VGA S_SGPIO BMC_WATCHD SATA_DOM0 CLR_CMOS F_LED1 Buzzer SATA_DOM1 F_LED2 VRM_SCL CPU_FAN1~2 BMC_LED1 SMB_IPMB VRM_SDA SYS_FAN1~6 SMD_VMD I_SGPIO1 FUSB30 I_SGPIO2 VROC ATX8P_1~2 FUSB2 F_PANEL S-SATA0~1 PMBUS I-SATA0~7 - 14 -...

  • Page 15: Motherboard Block Diagram In Gs-S12-P10R/P04R/P04S

    Motherboard Block Diagram in GS-S12-P10R/P04R/P04S ◎ Reserved I/O connector in GS-S12-P10R/P04R/P04S ● Available I/O connector in GS-S12-P10R/P04R/P04S SATA/SATADOM connector configuration in GS-S12-P10R/P04R/P04S ★ ★: GS-S12-P10R GS-S12-P04R GS-S12-P04S SATA P0 ● ● ● SATA P1 ● ● ● SATA P2 ●...

  • Page 16: Hard Disk Backplane Layout

    (Onboard SATA Port 1) JP01 SATA Connector (Onboard SATA Port 2) JC01(I2C) SATA Connector CN03(SGPIO) (Onboard SATA Port 3) • GS-S12-P10R (10-Bay, 2.5” Backplane) MiniSAS HD Connector PWR CONN (OnBoard SATA Port 0~Port 3) MiniSAS HD Connector JP02 (OnBoard SATA Port 4~Port 7) MiniSAS HD Connector...

  • Page 17: Chapter 3 System Appearance

    Chapter 3 System Appearance Front View and LEDs • GS-S12-P04R/GS-S12-P04S (4-Bay) HDD00 HDD01 HDD02 HDD03 Front Panel LEDs Front Panel LEDs 4-Bay Front Panel LEDs: Name Color Status Description Power Button Press the button to power on the system. Green Solid on Link between system and network but no access.
  • Page 18 Hard Disk Drive LEDs Hard Disk Drive LEDs Name Color LED 1 HDD Presence Blue LED LED 2 Activity Green LED & Fault Red LED 3.5” Hard Disk Drive LEDs: LED 1 LED 2 Presence Blue Activity Green LED by SGPIO or RAID SKU Status Fault/Fail Red LED...
  • Page 19 • GS-S12-P10R (10-Bay) HDD01 HDD03 HDD05 HDD07 HDD09 HDD00 HDD02 HDD04 HDD06 HDD08 Front Panel LEDs Front Panel LEDs 10-Bay Front Panel LEDs: Name Color Status Description Blue Solid on System is powered on. Power Button with LED System is not powered on or is in ACPI S5 state (power off).
  • Page 20 Hard Disk Drive LEDs Hard Disk Drive LEDs Name Color LED 1 HDD Presence Blue LED LED 2 Activity Green LED & Fault Red LED 2.5” Hard Disk Drive LEDs: LED 1 LED 2 Presence Blue Activity Green LED by SGPIO or RAID SKU Status Fault/Fail Red LED...

  • Page 21: Chapter 4 System Hardware Installation

    Chapter 4 System Hardware Installation Pre-installation Instructions Computer components and electronic circuit boards can be damaged by discharges of static electricity. Working on computers that are still connected to a power supply can be extremely dangerous. Follow the simple guidelines below to avoid damage to your computer or injury to yourself.

  • Page 22: Removing Chassis Cover

    Removing Chassis Cover Before you remove or install the system cover • Make sure the system is not turned on or connected to AC power. Follow these instructions to remove the chassis covers: 1. Push down on the indentations located on the side of the chassis cover. 2.

  • Page 23: Removing And Installing The Fan Duct

    Removing and Installing the Fan Duct Follow these instructions to remove/install the fan duct: 1. Lift up to remove the fan duct. 2. To install the fan duct, tear off the double-sided adhesive tape and stick it on the edge of the fan. - 23 -...

  • Page 24: Installing The Cpu And Heatsink

    Installing the CPU and Heatsink Read the following guidelines before you begin to install the CPU: • Make sure that the motherboard supports the CPU. • Always turn off the computer and unplug the power cord from the power outlet before installing the CPU to prevent hardware damage.

  • Page 25: Installing The Memory

    Installing the Memory Read the following guidelines before you begin to install the memory: • Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used. • Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage.
  • Page 26 Due to CPU limitations, read the following guidelines before installing the memory in 4 Channel mode. 4 Channel mode cannot be enabled if only one memory module is installed. When enabling 4 Channel mode with two or four memory modules, it is recommended that memory of the same capacity, brand, speed, and chips be used.

  • Page 27: Installing The Pci Expansion Card

    Installing the PCI Expansion Card • Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power switch is in the off position. Ensure that the system is powered- down and all power sources have been disconnected from the server prior to installing a PCI card.
  • Page 28 - 28 -...

  • Page 29: Installing The Hard Drive

    1. Press the release button and pull the locking lever to remove the hard drive tray. 2. Pull apart the hard drive tray and slide hard disk into the tray. 3. Slide the hard drive tray and push firmly into to the chassis. GS-S12-P10R GS-S12-P04R/GS-S12-P04S - 29 -...

  • Page 30: Installing The Redundant Power Supply For Gs-S12-P04R/Gs-S12-P10R

    Installing the Redundant Power Supply for GS-S12-P04R/GS-S12-P10R Before you remove or install the system cover, make sure the system is not turned on or connected the AC power. Follow these instructions to replace the power supply: 1. Insert the replacement power supply firmly into the chassis.

  • Page 31: Back Panel Connectors

    Back Panel Connectors D-Sub Port The D-Sub port supports a 15-pin D-Sub connector and supports a maximum resolution of 1920x1200@60 Hz (the actual resolutions supported depend on the monitor being used). Connect a monitor that supports D-Sub connection to this port. IPMI Port (LAN1) The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate.

  • Page 32: Internal Connectors

    Internal Connectors 34 BMC_LED1 32 F_LED1 BMC_VGA S_SGPIO BMC_WATCHD SATA_DOM0 CLR_CMOS F_LED1 Buzzer SATA_DOM1 F_LED2 VRM_SCL CPU_FAN1~2 BMC_LED1 SMB_IPMB VRM_SDA SYS_FAN1~6 SMD_VMD I_SGPIO1 FUSB30 I_SGPIO2 VROC ATX8P_1~2 FUSB2 F_PANEL S-SATA0~1 PMBUS I-SATA0~7 Read the following guidelines before connecting external devices: •...
  • Page 33 1) BMC_VGA Definition Enable (Default) Disable 2) BMC_WATCHD Definition Enable Disable (Default) 3) Buzzer 4) COM (Serial Port Header) Definition Definition NDCD- NSIN NSOUT NDTR- NDSR- NRTS- NCTS- NRI- - 33 -...
  • Page 34 5) SMB_IPMB Definition SMB_DATA SMB_CLK 6) I_SGPIO1 (For I-SATA0~3) 7) I_SGPIO2 (For I-SATA4~7) Definition Definition SATA_DATA SATA_LOAD SATA_CLK 8) WOL (Wake On Lan) Definition P5V_AUX WAKE_EN 9) SMB Definition SMB_DATA SMB_CLK - 34 -...
  • Page 35 10) TPM (Trusted Platform Module/Port 80 Header) Definition Definition LPC_IO0 P3V3 LPC_IO1 LPC_IO2 TPM_CLK LPC_IO3 LFRAME# SERIRQ TPM_RST 11) S_SGPIO (For S-SATA0~1) Definition Definition SATA_DATA SATA_LOAD SATA_CLK 12) SATA_DOM0 (SATA DOM0 Power Header) 13) SATA_DOM1 (SATA DOM1 Power Header) Definition 14) VRM_SCL (For VRM SMB_CLK) 15) VRM_SDA (For VRM SMB_DATA) Definition...
  • Page 36 16) FUSB30 Definition Definition VBUS SSRX1- SSRX1+ SSTX2+ SSTX1- SSTX2- SSTX1+ SSRX2+ SSRX2- VBUS 17) VROC (RAID Key for CPU NVMe SSD) Definition P3V3_AUX PCH RAID KEY 18) FUSB2 Definition Definition Power (5V) Power (5V) USB DX- USB DY- USB DX+ USB DY+ - 36 -...
  • Page 37 19) F_PANEL Definition Definition Power LED+ 5V Standby ID LED+ Power LED- ID LED- HDD LED+ System Status LED+ HDD LED1 System Status LED- Power Button LAN1 Active LED+ LAN1 Link LED- Reset Button SMBus Data SMBus Clock ID Button Case Open LAN2 Active LED+ NMI Switch...
  • Page 38 22) CLR_CMOS Definition NA (Default) Clear CMOS 23) CI Definition Intrusion Input 24) CPU_FAN1/CPU_FAN2 Definition CPU_FAN1 P12V FAN_TACH FAN_PWM CPU_FAN2 25) SYS_FAN1~6 Definition P12V FAN_TACH FAN_PWM - 38 -...
  • Page 39 26) ATX (2x12 Main Power Connector) 27) ATX8P_1~2 (2x4, 12V Power Connectors) ATX8P_2 ATX8P_1 28) M.2 (M.2 Socket 3 Connector) - 39 -...
  • Page 40 29) S-SATA0~1 (SATA 6Gb/s Connectors, Supported by the Intel PCH) ® S-SATA0 S-SATA1 30) I-SATA0~7 (SATA 6Gb/s Connectors, Supported by the Intel SCU) ® I-SATA0 I-SATA1 I-SATA2 I-SATA3 I-SATA4 I-SATA5 I-SATA6 I-SATA7 31) BAT - 40 -...
  • Page 41 32) F_LED1 (Onboard Power LED) 33) F_LED2 (UID LED, Unit Identifier LED) F_LED1 F_LED2 State Description State Description Solid Red Standby Solid Blue Unit Identified Solid Green Power On 34) BMC_LED1 (BMC Heartbeat LED) State Description Blinking Yellow BMC Normal 35) SMD_VMD (NVMe SMBUS Control Header) Definition Definition...

  • Page 42: Chapter 5 Bios Setup

    Chapter 5 BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the CMOS on the motherboard. Its major functions include conducting the Power-On Self-Test (POST) during system startup, saving system parameters and loading operating system, etc. BIOS includes a BIOS Setup program that allows the user to modify basic system configuration settings or to activate certain system features.

  • Page 43: Main

    Main Once you enter the BIOS Setup program, the Main Menu (as shown below) appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. Main Menu Help The on-screen description of a highlighted setup option is displayed on the right of the Main Menu. Submenu Help While in a submenu, press <F1>...

  • Page 44: Advanced

    Advanced ` Trusted Computing(TPM) Enables or disables Trusted Platform Module (TPM). & Security Device Support Enables or disables BIOS support for security device. OS will not show security device. TCG EFI protocol and INT1A interface will not be available. ` Serial Port Console Redirection This section allows you to enable/disable serial port console redirection for remote server management through a serial port.
  • Page 45 ` CSM Configuration & CSM Support ◎ Enables or disables UEFI CSM (Compatibility Support Module) to support a legacy PC boot process. Enables UEFI CSM. Enabled Disables UEFI CSM and supports UEFI BIOS boot process only. Disabled & GateA20 Active Upon Request GA20 can be disabled using BIOS services.
  • Page 46 ` Performance Item & PERFORMANCE Table Selector Allows you to select performance table. & Fan Table Selector, SpeedStep (Pstates), Hardware Prefetcher, Adjacent Cache Prefetch, DCU Streamer Prefetcher, Turbo Mode, Uncore Freq Scaling (UFS), Hardware P-States, Autonomous Core C-State, CPU C6 report, Enhanced Halt State (C1E), Package C State, Link L0p Enable, Link L1 Enable, Data Scrambling for DDR4, Patrol Scrub These items' settings depend on the configuration of PERFORMANCE Table Selector.

  • Page 47: Platform Configuration

    Platform Configuration ` PCH Configuration ` PCH Devices & PCH state after G3 Allows you to select S0 or S5 for ACPI state after a G3. ` PCI Express Configuration & Max Read Request Size Allows you to select the PCI Exprss max read request size. ` PCH SATA Configuration (I-SATA0~I-SATA7 Connectors) &...
  • Page 48 & Load EFI Driver for RAID Allows you to select whether to load EFI driver in RAID mode. If disabled, loads legacy OPROM. & SATA Port 0/1/2/3/4/5/6/7 Enables or disables each SATA port. ` PCH sSATA Configuration (S-SATA0, S-SATA1 Connectors) &...

  • Page 49: Socket Configuration

    Socket Configuration ` Processor Configuration The sub-menu displays and provides options to change the processor settings. & Hyper-Threading [ALL] The Hyper Threading Technology allows a single processor to execute two or more separate threads concurrently. When hyper-threading is enabled, multi-threaded software applications can execute their. &...
  • Page 50 ` Common RefCode Configuration & MMCFG Base Selects MMCFG Base. & MMIO High Base Selects MMIO High Base. & MMIO High Granularity Size Selects the allocation size used to assign mmioh resources. Total mmioh space can be up to 32x granularity. Per stack mmioh resource assignments are multiples of the granularity where 1 unit per stack is the default allocation.
  • Page 51 & Enforce POR Enable enforces Plan of Record restrictions for DDR4 frequency and voltage programming. Disable will disable this feature. Auto sets it to the MRC default setting. & PPR Type Selects Post Package Repair Type. Auto sets it to the MRC default setting. Options are: Hard PPR, Soft PPR, PPR Disabled &...
  • Page 52 ` Socket0 Configuration Press [Enter] for configuration of advanced items. ` Socket1 Configuration Press [Enter] for configuration of advanced items. ` IOAT Configuration The sub-menu provides options enable or disable the IIO IOAPIC Stacks 0~5. & Disable TPH Enables or disables TLP Processing Hint disable. &...
  • Page 53 ` Package C State Control & Package C State Configures the state for the C-State package limit. Options are C0/C1 state, C2 state, C6(non Retention) state, C6(Retention) state, No Limit, Auto. ` CPU Thermal Management ` CPU T State Control &...

  • Page 54: Server Mgmt

    Server Mgmt & BMC Support Enables or disables interfaces to communicate with BMC. & Wait For BMC Allows you to determine whether to wait for BMC response for specified time out. In PILOTII, BMC starts at the same time when BIOS starts during AC power ON. It takes around 30 seconds to initialize Host to BMC interfaces.
  • Page 55 ` View FRU information Press [Enter] to view FRU information. ` BMC network configuration Press [Enter] to configure BMC network parameters. ` View System Event Log Press [Enter] to view the system event log records. - 55 -...

  • Page 56: Security

    Security & Administrator Password Allows you to configure an administrator password. Press <Enter> on this item, type the password, and then press <Enter>. You will be requested to confirm the password. Type the password again and press <Enter>. You must enter the administrator password (or user password) at system startup and when entering BIOS Setup.
  • Page 57 ` Reset To Setup Mode Deletes all Secure Boot key databases from NVRAM. This item is configurable only when Secure Boot Mode is set to Custom. ` Key Management Enables expert users to modify Secure Boot Policy variables without full authentication. &...

  • Page 58: Boot

    Enables or disables Numlock feature on the numeric keypad of the keyboard after the POST. & Quiet Boot Allows you to determine whether to display the GIGABYTE Logo at system startup. & Optimized Boot Enables or disables Optimized Boot. Enabling Optimized Boot will disable CSM support and disable connecting Network devices to decrease boot time.

  • Page 59: Save & Exit

    Save & Exit & Save Changes and Exit Press <Enter> on this item and select Yes. This saves the changes to the CMOS and exits the BIOS Setup program. Select No or press <Esc> to return to the BIOS Setup Main Menu. &...

  • Page 60: Chapter 6 Bmc Web

    Chapter 6 BMC Web You can use the IP from BIOS Setup Manu to connect to BMC Web UI. For example, https://10.8.1.48 After entering the IP address into web browser, you can enter your username and password (Default Account: admin Default Password: admin) to enter the Web UI. Dashboard This page shows the summary monitoring information of the board.
  • Page 61 Sensor On this page, details for all the available sensors e.g. Name, Type, Status, Current Reading and Behavior are displayed. The sensor readings are available for Temperature, Fan, Watchdog and Voltage Sensors as well as for supported Discrete Sensors. This page will refresh automatically with the latest data retrieved from the database.
  • Page 62 System Information This page displays BIOS, CPU, DIMM and Back Plane Firmware information. IPMI Event Log This page displays the list of events incurred by the different sensors on this device. Click on a record to see the details of that entry. With your cursor, hover over the graph to view the number of events by date. You can also select between BMC or Client Time zone.
  • Page 63 System Log This page displays logs of system events for this device (if the options have been configured). Note: Logs must be configured under "Settings/Log Settings/Advanced Log Settings" to display any entries. Filtering options are also available for this and all logs in this section. Audit Log This page displays audit events for this device (if configured).
  • Page 64 Video Log This page displays available recorded video files (if the options have been configured). Note: For configuration, go to "Settings/Video Recording/Auto Video Settings/Video Trigger Settings." Settings This page allows you to configure BMC options. The options are: Captured BSOD, Date & Time, External User Services, KVM Mouse Setting, Log Settings, Media Redirection Settings, Network Settings, PAM Order Settings, Platform Event Filter, Services, SMTP Settings, SSL Settings, System Firewall, User Management, and Video Recording.
  • Page 65 Remote Control On this page, you can remote control your host system on BIOS Setup or Operating System. Remote Control- Example (BIOS Setup menu) This page shows the BIOS Setup settings. - 65 -...
  • Page 66 Power Control On this page, you can remote control the power of your host system. Maintenance This page allows you to configure BMC options. The options are Backup Configuration, BMC Recovery, Firmware Image Location, Firmware Information, Firmware Update, Preserve Configuration, Restore Configuration, Restore Factory Defaults, and System Administrator.
  • Page 67 Image Redirection The displayed table shows remote images available to the BMC. You can start redirection or clear the images from here. Up to 4 images can be added for each image type, depending on your configuration. - 67 -...
  • Page 68 Regulatory Notices/ 管理声明 WEEE Symbol Statement The symbol shown below is on the product or on its packaging, which indicates that this product must not be disposed of with other waste. Instead, the device should be taken to the waste collection centers for activation of the treatment, collection, recycling and disposal procedure.
  • Page 69 (e.g. use of power strips). Disconnect 2 power supply cords before servicing CAUTION: Slider/rail mounted equipment is not to be used as a shelf or a work space. For more information, visit our website at: https://www.gigabyte.com - 69 -...
  • Page 70 - 70 -...
  • Page 71 - 71 -...

  • Page 72: Contact Us

    Contact Us GIGA-BYTE TECHNOLOGY CO., LTD. Address: No.6, Baoqiang Rd., Xindian Dist., New Taipei City 231, Taiwan TEL: +886-2-8912-4000, FAX: +886-2-8912-4005 Tech. and Non-Tech. Support (Sales/Marketing) : https://esupport.gigabyte.com WEB address (English): https://www.gigabyte.com WEB address (Chinese): https://www.gigabyte.com/tw GIGABYTE eSupport • To submit a technical or non-technical (Sales/Marketing) question, please link to: https://esupport.gigabyte.com...
