TBX-1329 AC/DC C
Introduction
What You Need to Get Started
SCXI ™ is a trademark of National Instruments Corporation. Product and company names are trademarks or trade names of their respective
companies.
321556A-01
OUPLING
This guide describes how to install and use the TBX-1329 AC/DC
coupling terminal block with the SCXI-1120, SCXI-1120D, and
SCXI-1121 modules.
The TBX-1329 is a DIN rail-mountable terminal block that consists of
a shielded board with screw terminals to connect to the SCXI-1120,
SCXI-1120D, or SCXI-1121 front connector. The TBX-1329 mounts
on most European standard DIN EN mounting rails.
The terminal block has 16 screw terminals that unplug for easy
connection. Two screws are provided to connect to the SCXI CHASSIS
GROUND via the SH32-32-A cable shield. With the SCXI-1120 and
SCXI-1120D, the remaining eight pairs of screw terminals connect
signals to the eight SCXI module input channels. With the SCXI-1121,
four pairs of screw terminals connect signals to the four SCXI module
input channels and four pairs connect to the SCXI module excitation
channels.
To set up and use your TBX-1329, you will need the following:
TBX-1329 AC/DC coupling terminal block
TBX-1329 AC/DC Coupling Terminal Block Installation Guide
1
/
in. flathead screwdriver (included in kit)
8
Your SCXI chassis and documentation
SCXI-1120, SCXI-1120D, or SCXI-1121 module and
documentation
© Copyright 1997 National Instruments Corp. All rights reserved.
T
ERMINAL
B
LOCK
September 1997
