INSTALLATION INSTRUCTIONS
NI TB-2630B
Terminal Block for the NI PXI-2530B
This guide describes how to install and connect signals to the National Instruments TB-2630B terminal
block to configure your NI PXI-2530B switch module as one of the following:
•
1-wire 128 × 1 multiplexer
•
1-wire dual 64 × 1 multiplexer
•
1-wire quad 32 × 1 multiplexer
•
1-wire octal 16 × 1 multiplexer
•
2-wire 64 × 1 multiplexer
•
2-wire dual 32 × 1 multiplexer
•
2-wire quad 16 × 1 multiplexer
•
4-wire 32 × 1 multiplexer
•
4-wire dual 16 × 1 multiplexer
•
independent
This terminal block is a shielded accessory.
Contents
Introduction.......................................................................................................................................... 1
1. Unpack the Terminal Block............................................................................................................. 2
2. Verify the Components.................................................................................................................... 2
3. Connect Signals ............................................................................................................................... 2
4. Install the Terminal Block ............................................................................................................... 20
Accessories .......................................................................................................................................... 21
Compliance and Certifications............................................................................................................. 22
Introduction
The NI TB-2630B terminal block installs in front of the NI PXI-2530B switch module. The
NI TB-2630B has ribbon cable headers to connect signals to the switch. Screw terminals for the trigger
input and trigger output signals are also available. The NI TB-2630B is designed for use with the
NI PXI-2530B and is not compatible with the NI PXI-2530.
Advertisement
Related Manuals for National Instruments NI TB-2630B
Summary of Contents for National Instruments NI TB-2630B
-
Page 1: Table Of Contents
The NI TB-2630B terminal block installs in front of the NI PXI-2530B switch module. The NI TB-2630B has ribbon cable headers to connect signals to the switch. Screw terminals for the trigger input and trigger output signals are also available. The NI TB-2630B is designed for use with the... -
Page 2: Unpack The Terminal Block
Store the terminal block in the antistatic package when not in use. 2. Verify the Components Make sure you have the following: ❑ NI TB-2630B terminal block ❑ PXI chassis ❑ NI PXI-2530B switch module ❑... - Page 3 Terminal block top cover Strain-relief bar Top cover screws Ribbon cable Safety ground lug Strain-relief screw 10 Ribbon cable connector Chassis screws 11 Ribbon cable header Rear connector Figure 1. NI TB-2630B Terminal Block © National Instruments Corporation NI TB-2630B Installation Instructions...
- Page 4 COM 3 1WREF0 1WREF1 BANK 4 BANK 5 BANK 6 BANK 7 COM 4 COM 5 COM 6 COM 7 1WREF2 1WREF3 TRIGOUT TRIGIN USE SHIELDED CABLE ON TRIGGERS Figure 2. NI TB-2630B Terminal Reference NI TB-2630B Installation Instructions ni.com...
- Page 5 Bank 0, Pin 11 ch11 Bank 0, Pin 12 ch12 Bank 0, Pin 13 ch13 Bank 0, Pin 14 ch14 Bank 0, Pin 15 ch15 Bank 0, Pin 16 ch16 Bank 1, Pin 1 © National Instruments Corporation NI TB-2630B Installation Instructions...
- Page 6 Bank 2, Pin 10 ch42 Bank 2, Pin 11 ch43 Bank 2, Pin 12 ch44 Bank 2, Pin 13 ch45 Bank 2, Pin 14 ch46 Bank 2, Pin 15 ch47 Bank 2, Pin 16 NI TB-2630B Installation Instructions ni.com...
- Page 7 Bank 4, Pin 9 ch73 Bank 4, Pin 10 ch74 Bank 4, Pin 11 ch75 Bank 4, Pin 12 ch76 Bank 4, Pin 13 ch77 Bank 4, Pin 14 ch78 Bank 4, Pin 15 © National Instruments Corporation NI TB-2630B Installation Instructions...
- Page 8 Bank 6, Pin 8 ch104 Bank 6, Pin 9 ch105 Bank 6, Pin 10 ch106 Bank 6, Pin 11 ch107 Bank 6, Pin 12 ch108 Bank 6, Pin 13 ch109 Bank 6, Pin 14 NI TB-2630B Installation Instructions ni.com...
- Page 9 In the 1-wire quad 32 × 1 topology, the driver establishes the following connections: • 1wref0 is connected to com1. • 1wref1 is connected to com3. • 1wref2 is connected to com5. • 1wref3 is connected to com7. © National Instruments Corporation NI TB-2630B Installation Instructions...
- Page 10 Bank 0, Pin 6 – Bank 1, Pin 6 Bank 0, Pin 7 – Bank 1, Pin 7 Bank 0, Pin 8 – Bank 1, Pin 8 Bank 0, Pin 9 – Bank 1, Pin 9 NI TB-2630B Installation Instructions ni.com...
- Page 11 Bank 3, Pin 5 Bank 2, Pin 6 ch21 – Bank 3, Pin 6 Bank 2, Pin 7 ch22 – Bank 3, Pin 7 Bank 2, Pin 8 ch23 – Bank 3, Pin 8 © National Instruments Corporation NI TB-2630B Installation Instructions...
- Page 12 – Bank 5, Pin 4 Bank 4, Pin 5 ch36 – Bank 5, Pin 5 Bank 4, Pin 6 ch37 – Bank 5, Pin 6 Bank 4, Pin 7 ch38 – Bank 5, Pin 7 NI TB-2630B Installation Instructions ni.com...
- Page 13 Bank 7, Pin 3 Bank 6, Pin 4 ch51 – Bank 7, Pin 4 Bank 6, Pin 5 ch52 – Bank 7, Pin 5 Bank 6, Pin 6 ch53 – Bank 7, Pin 6 © National Instruments Corporation NI TB-2630B Installation Instructions...
- Page 14 – Bank 7, Pin 13 Bank 6, Pin 14 ch61 – Bank 7, Pin 14 Bank 6, Pin 15 ch62 – Bank 7, Pin 15 Bank 6, Pin 16 ch63 – Bank 7, Pin 16 NI TB-2630B Installation Instructions ni.com...
- Page 15 A– Bank 1, Pin 3 Bank 4, Pin 3 B– Bank 5, Pin 3 Bank 0, Pin 4 A– Bank 1, Pin 4 Bank 4, Pin 4 B– Bank 5, Pin 4 © National Instruments Corporation NI TB-2630B Installation Instructions...
- Page 16 Bank 0, Pin 10 A– Bank 1, Pin 10 Bank 4, Pin 10 B– Bank 5, Pin 10 Bank 0, Pin 11 A– Bank 1, Pin 11 ch10 Bank 4, Pin 11 B– Bank 5, Pin 11 NI TB-2630B Installation Instructions ni.com...
- Page 17 Bank 3, Pin 1 ch16 Bank 6, Pin 1 B– Bank 7, Pin 1 Bank 2, Pin 2 A– Bank 3, Pin 2 ch17 Bank 6, Pin 2 B– Bank 7, Pin 2 © National Instruments Corporation NI TB-2630B Installation Instructions...
- Page 18 Bank 2, Pin 8 A– Bank 3, Pin 8 ch23 Bank 6, Pin 8 B– Bank 7, Pin 8 Bank 2, Pin 9 A– Bank 3, Pin 9 ch24 Bank 6, Pin 9 B– Bank 7, Pin 9 NI TB-2630B Installation Instructions ni.com...
- Page 19 Bank 3, Pin 15 ch30 Bank 6, Pin 15 B– Bank 7, Pin 15 Bank 2, Pin 16 A– Bank 3, Pin 16 ch31 Bank 6, Pin 16 B– Bank 7, Pin 16 © National Instruments Corporation NI TB-2630B Installation Instructions...
-
Page 20: Install The Terminal Block
The NI PXI-2530B should already be installed in a PXI chassis. Plug the NI TB-2630B into the front connector of the NI PXI-2530B as shown in Figure 3. Tighten the top and bottom chassis screws on the back of the terminal block rear panel to hold it securely in place. -
Page 21: Accessories
NI TB-2630B. You can use any 0.050 in. pitch ribbon cable with the NI TB-2630B. To use a ribbon cable with more than 18 conductors, remove the unwanted conductors before using. Refer to Table 4 for more information about the cable connector assembly. -
Page 22: Compliance And Certifications
For additional environmental information, refer to the NI and the Environment Web page at ni.com/ . This page contains the environmental regulations and directives with which NI environment complies, as well as other environmental information not included in this document. NI TB-2630B Installation Instructions ni.com... - Page 23 At the end of the product life cycle, all products must be sent to a WEEE recycling center. For more information about WEEE recycling centers, National Instruments WEEE initiatives, and compliance with WEEE Directive 2002/96/EC on Waste Electrical and Electronic Equipment, visit ni.com/environment/weee...
- Page 24 LabVIEW, National Instruments, NI, ni.com, the National Instruments corporate logo, and the Eagle logo are trademarks of National Instruments Corporation. Refer to the Trademark Information at ni.com/trademarks for other National Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the National...
