Diamond Systems JASPER User Manual

Com express type 6 carrier board and sbc
Hide thumbs Also See for JASPER:

Advertisement

Quick Links

COM Express Type 6 Carrier Board and SBC
FOR TECHNICAL SUPPORT
PLEASE CONTACT:
Email:
support@diamondsystems.com
JASPER
User Manual
Revision 1.32
© Copyright 2023-2024
Diamond Systems Corporation
www.diamondsystems.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JASPER and is the answer not in the manual?

Questions and answers

Summary of Contents for Diamond Systems JASPER

  • Page 1 JASPER COM Express Type 6 Carrier Board and SBC User Manual Revision 1.32 FOR TECHNICAL SUPPORT © Copyright 2023-2024 PLEASE CONTACT: Diamond Systems Corporation www.diamondsystems.com Email: support@diamondsystems.com...
  • Page 2: Table Of Contents

    Product Photos ............................10 Block Diagrams .............................. 12 Carrier Board Block Diagram ........................12 Jasper with Winsystems COMET6-1100 COM Module ................13 Jasper with Arbor EmETXe-i92U1 COM Module ..................14 Functional Overview ............................15 COM Express Carrier Board ........................15 Power Supply Specifications ........................
  • Page 3 7.21 COM Express type 6 Compact / Basic connector Pinout (J28 & J30) ............42 I/O Connector List & Mating Cables ......................47 Jasper vs COM Module Interface Comparison List ..................48 10 Mounting Plate ............................... 50 Jasper User Manual v1.32 www.diamondsystems.com...
  • Page 4: Important Safe Handling Information

    Diamond Systems recommends that all its boards be stored only in individual ESD-safe packaging units. If multiple boards are stored together, they should be contained in bins with dividers placed between the boards. Do not pile boards on top of each other or cram too many boards within a small location.
  • Page 5 Overvoltage on Analog Input: If a voltage applied to an analog input exceeds the power specification of the board, the input multiplexer and/or parts behind it can be damaged. Most Diamond Systems boards will withstand an erroneous connection of up to 36V on the analog inputs, even when the board is powered off, but not on all boards, and not under all conditions.
  • Page 6: Introduction

    A special feature of Jasper is that most I/O connectors are located along the front edge. This makes it possible to design and build I/O boards that mate directly to Jasper without the use of cables, to reduce size and increase ruggedness for rugged systems applications.
  • Page 7 13mm as per COM express specification) 15V-36V wide range input or Fixed 12V +/-10% supply Power Input Range Operating Temperature -40°C to +85°C ambient (final system capability depends on the COM installed) Range Jasper User Manual v1.32 www.diamondsystems.com Page 7...
  • Page 8: Baseboard Variants

    4 GPI, 4 GPO 4 GPI, 4 GPO 4 GPI, 4 GPO Others I2C,1x RS232 I2C, 1x RS232 Reset & Power Button Reset & Power Button Reset & Power Button *Based on the COMe Module Jasper User Manual v1.32 www.diamondsystems.com Page 8...
  • Page 9: Jasper Ordering Guide

    1185GRE processor (Inclusive of OS, Instruction for flashing, USB2.0 8GB Flash drive, M.2 2242 SATA 64GB wide temperature flash disk) DK-JSP-1185G7E-LNX64 Development Kit: Jasper 11th Gen Core i7 SBC with DIO, 64GB RAM, Linux 64-bit OS DK-JSP-1185G7E-WE1064 Development Kit, Jasper SBC, 1185G7E CPU, Windows 10 64-Bit OS...
  • Page 10: Product Photos

    2.4 Product Photos Figure 1: COM module installation side Figure 2: I/O expansion side Jasper User Manual v1.32 www.diamondsystems.com Page 10...
  • Page 11 Figure 3: Side view showing COM Express module and heat spreader. Figure 4: Bottom view showing Compact size COM heat spreader nested in mounting plate. Jasper User Manual v1.32 www.diamondsystems.com Page 11...
  • Page 12: Block Diagrams

    3 BLOCK DIAGRAMS 3.1 Carrier Board Block Diagram The following Block Diagram illustrates the key functional block of the JASPER COM Express Carrier board. The diagram shows all available features. Exact implemented features depend on the installed COM. Figure 5: JASPER COM Express Carrier Board Block Diagram Jasper User Manual V1.3...
  • Page 13: Jasper With Winsystems Comet6-1100 Com Module

    3.2 Jasper with Winsystems COMET6-1100 COM Module Figure 6: Jasper with Winsystems COMET6-1100 COM Module Jasper User Manual v1.32 www.diamondsystems.com Page 13...
  • Page 14: Jasper With Arbor Emetxe-I92U1 Com Module

    3.3 Jasper with Arbor EmETXe-i92U1 COM Module Figure 7: Jasper with Arbor EmETXe-i92U1 COM Module Jasper User Manual v1.32 www.diamondsystems.com Page 14...
  • Page 15: Functional Overview

    4.4 PCIe Link Routing Jasper’s PCIe x1 port mapping is provided below. The carrier board routes the PCIe x16 lanes from the COM Express CD connector to the PCIe104 connector banks 2 and 3. Lane 0 – Minicard Socket1 Lane 1 –...
  • Page 16: Sata M.2 Socket

    4.6 USB Jasper supports 2 USB2.0 ports and 3 USB 3.0/USB 2.0 ports from the COM. 2x USB2.0 ports are routed to one 2x5 headers and 3x USB 3.0/USB2.0 ports are routed to three nos of 2x5 headers.
  • Page 17: Hdmi

    4.9 HDMI Jasper offers two HDMI 2.0 video outputs. HDMI ports are made available on two 2x10 2mm pitch pin header. SN65DP159RSBT IC is used for DP++ to HDMI level translation. 4.10 Serial Ports Jasper supports 4 serial ports using a USB to Quad UART controller (FT4232HL) in Full feature variant (JSP BB02D and JSP BB03A) and 2 RS232 ports on Low-cost baseboard variants (JSP BB01D).
  • Page 18: Utility

    General purpose input and outputs pins are defined to be in push-pull CMOS configuration with 3.3V levels as in COM specification. These are directed to / from COM module to the J5 GPIO connector on Jasper with no pullup or pull-down resistors mounted on carrier board.
  • Page 19: Led Indicators

    LED Indicators Jasper provides the following LED indicators. All LEDs are located near a board edge or their respective features. All LEDs are labeled in silkscreen with their function. Function LED color and operation PCB label Power input Input power applied...
  • Page 20: Mechanical Drawings

    5 MECHANICAL DRAWINGS The illustrations below provide dimensions of the key connectors and features of Jasper. Figure 8: Mechanical Top View Jasper User Manual v1.32 www.diamondsystems.com Page 20...
  • Page 21 Figure 9: Mechanical Bottom View Figure 10: Jasper Stacking Height Details Jasper User Manual v1.32 www.diamondsystems.com Page 21...
  • Page 22: Connector And Jumper Locations

    6 CONNECTOR AND JUMPER LOCATIONS Figure 11: COM module installation side Jasper User Manual v1.32 www.diamondsystems.com Page 22...
  • Page 23 Figure 12: I/O expansion side Jasper User Manual v1.32 www.diamondsystems.com Page 23...
  • Page 24: Jumper Selection

    6.1 Jumper Selection The Jumper blocks on the Jasper board can be configured to enable/disable or alter the default signal routing settings on the circuit, using Jumper shunts. The following table describes the Jumper Blocks on the baseboard. Description Jumper...
  • Page 25: Jumper Block Jp1

    FPGA Address - Reserved FPGA Address - Reserved *Default setting Note: 1. Base address must be selected based on addresses available on the COM module used with Jasper. Check the COM user manual for available addresses. Jasper User Manual v1.32 www.diamondsystems.com...
  • Page 26: Jumper Block Jp2

    1 & 2 and SC2 and SC3 jumpers are used to select mode for serial ports 3 & 4. Position Port RS232 RS485 RS422 Internal Loop 1&2 OUT* 1&2 3&4 OUT* 3&4 *Default setting Applicable only for JSP-BB02D model. JP4 Jumper is software overridden by FGPA for JSP-BB03A model. Jasper User Manual v1.32 www.diamondsystems.com Page 26...
  • Page 27: Jumper Block Jp5

    Position Function IN (Installed) OUT (Not Installed) Enabled Disabled* Serial Port1 TX Termination Enabled Disabled* Serial Port1 RX Termination Enabled Disabled* Serial Port2 TX Termination Enabled Disabled* Serial Port2 RX Termination *Default setting Jasper User Manual v1.32 www.diamondsystems.com Page 27...
  • Page 28: Connector Pinouts

    Ground Connector PN: 053398-0271 Connector Type: 2 position 1.25 mm pitch vertical SMD header Mating Cable PN: DSC no. 4713001 (CR2032 Battery with Wire Leads) DSC no. 6980529 (Battery cable with free wires) Jasper User Manual v1.32 www.diamondsystems.com Page 28...
  • Page 29: Fan Connector (J31)

    7.4 Ethernet (J23 & J24) There are two identical on-board connectors for 10/100/1000 BASE T Ethernet. Chassis Gnd Connector PN: 98464-G61-10ULF Connector Type: latching 2x5 2mm pitch RA shrouded pin header. Mating Cable PN: 6980604 Jasper User Manual v1.32 www.diamondsystems.com Page 29...
  • Page 30: Audio (J3)

    USB1 Pwr- USB0 Pwr- USB1 Data+ USB0 Data+ USB1 Data- USB0 Data- USB1 Pwr+ USB0 Pwr+ Connector PN: 98464-G61-10ULF Connector Type: latching 2x5 2mm pitch RA shrouded pin header Mating Cable PN: 6980602 Jasper User Manual v1.32 www.diamondsystems.com Page 30...
  • Page 31: Usb 3.0 Ports (J14, J20, J21)

    Connector Type: latching 2x5 2mm pitch RA shrouded pin header on the front edge of the board. Mating Cable PN: 6980603 Connector PN (J14): 98414-G06-10LF Connector Type: latching 2x5 2mm pitch vertical shrouded pin header on the right edge of board. Mating Cable PN: 6980603 Jasper User Manual v1.32 www.diamondsystems.com Page 31...
  • Page 32: Lvds (J4)

    Mating Cable: Custom depending on the target display. 7.10 HDMI (J17 & J22) The board supports 2 HDMI ports. HDMI signals come through a level translator IC from COM module over DDI lanes. Jasper User Manual v1.32 www.diamondsystems.com Page 32...
  • Page 33: Vga (J2)

    VGA availability is dependent on the installed COM. VGA_RED VGA_GREEN VGA_BLUE VGA_HSYNC VGA_DDC_DATA VGA_VSYNC VGA_DDC_CLK Connector PN: FCI 98414-G06-10LF Connector Type: latching 2x5 2mm pitch vertical shrouded pin header Mating Cable PN: 6981084 Jasper User Manual v1.32 www.diamondsystems.com Page 33...
  • Page 34: Serial Ports (J19 & J26)

    CTS2 RS-422: TX1+ TX1- RX1+ RX1- TX2+ TX2- RX2+ RX2- RS-485: TX1/RX1+ TX1/RX1- TX2/RX2+ TX2/RX2- Connector PN: 98464-G61-10ULF Connector Type: latching 2x5 2mm pitch right angle shrouded pin header Mating Cable PN: 6980601 Jasper User Manual v1.32 www.diamondsystems.com Page 34...
  • Page 35: Socket (J15)

    SATA_RX+/ PCIe RX- SATA_RX-/PCIe RX+ SATA_TX-/PCIe TX- SATA_TX+/PCIe TX+ PERST# PCIe CLKREQ# PCIe REFCLK- PCIe WAKE# PCIe REFCLK+ +3.3V +3.3V +3.3V Connector PN: 10128798-005RLF Connector Type: 75 Position Female Connector M.2 (NGFF) Mini Card Jasper User Manual v1.32 www.diamondsystems.com Page 35...
  • Page 36: Sata (J9)

    Analog Ground DIO C0 DIO C1 DIO C2 DIO C3 DIO C4 VIO (fused) Digital Ground Connector PN: 98414-G06-30LF Connector Type: latching 2x15 2mm pitch vertical shrouded pin header Mating Cable PN: 6980612 Jasper User Manual v1.32 www.diamondsystems.com Page 36...
  • Page 37: Digital I/O (J13)

    DIO B2 DIO B3 DIO B4 DIO B5 DIO B6 DIO B7 DIO C5 Ground Ground Connector PN: 98414-F06-20ULF Connector Type: latching 2x10 2mm pitch vertical shrouded pin header Mating Cable PN: 6980611 Jasper User Manual v1.32 www.diamondsystems.com Page 37...
  • Page 38: Utility (J27)

    COM module by default. GPI0 GPO0 GPI1 GPO1 GPI2 GPO2 GPI3 GPO3 3.3V Fused 0.5A Connector PN: 98414-G06-10LF Connector Type: latching 2x5 2mm pitch vertical shrouded pin header Mating Cable PN: 6980609 Jasper User Manual v1.32 www.diamondsystems.com Page 38...
  • Page 39: Pcie Mini Card (J11 & J12)

    +1.5V SMB Clk PCIe TX-/SATA TX- SMB Data PCIe TX+/SATA TX+ USB D- USB D+ +3.3V +3.3V Ground +1.5V +3.3V Connector PN: 1759547-1 Connector Type: 52 Position Female Connector PCI Express Mini Card Jasper User Manual v1.32 www.diamondsystems.com Page 39...
  • Page 40: Pcie104 Connector (J1)

    PEx16 Tx11- PEx16 Tx3- Ground Ground PEx16 Tx12+ PEx16 Tx4+ PEx16 Tx12- PEx16 Tx4- Ground Ground PEx16 Tx13+ PEx16 Tx5+ PEx16 Tx13- PEx16 Tx5- Ground Ground PEx16 Tx14+ PEx16 Tx6+ PEx16 Tx14- PEx16 Tx6- Jasper User Manual v1.32 www.diamondsystems.com Page 40...
  • Page 41 Ground PEx16 Rx14+ PEx16 Rx6+ PEx16 Rx14- PEx16 Rx6- Ground Ground PEx16 Rx15+ PEx16 Rx7+ PEx16 Rx15- PEx16 Rx7- Ground Ground Connector PN: ASP-142781-03 Connector Type: 156 Position Connector Header, Outer Shroud Contacts Jasper User Manual v1.32 www.diamondsystems.com Page 41...
  • Page 42: Com Express Type 6 Compact / Basic Connector Pinout (J28 & J30)

    BIOS_DIS0# I2C_DAT USB6- USB7- USB6+ USB7+ USB_6_7_OC# USB4- USB5- USB4+ USB5+ USB2- USB3- USB2+ USB3+ USB_2_3_OC# USB_0_1_OC# USB0- USB1- USB0+ USB1+ VCC_RTC SYS_RESET# LPC_SERIRQ CB_RESET# PCIE_TX5+ PCIE_RX5+ PCIE_TX5- PCIE_RX5- GPI0 GPO1 PCIE_TX4+ PCIE_RX4+ Jasper User Manual v1.32 www.diamondsystems.com Page 42...
  • Page 43 FAN_PWMOUT SER1_RX A102 B102 FAN_TACHIN A103 B103 VCC_12V A104 B104 VCC_12V VCC_12V A105 B105 VCC_12V VCC_12V A106 B106 VCC_12V VCC_12V A107 B107 VCC_12V VCC_12V A108 B108 VCC_12V VCC_12V A109 B109 VCC_12V A110 B110 Jasper User Manual v1.32 www.diamondsystems.com Page 43...
  • Page 44 DDI1_PAIR1- DDI2_CTRLCLK_AUX+ DDI1_PAIR2+ DDI2_CTRLDATA_AUX- DDI1_PAIR2- DDI2_DDC_AUX_SEL DDI1_DDC_AUX_SEL DDI1_PAIR3+ DDI1_PAIR3- DDI2_PAIR0+ DDI2_PAIR0- DDI2_PAIR1+ DDI2_PAIR1- DDI2_HPD DDI2_PAIR2+ DDI2_PAIR2- DDI2_PAIR3+ DDI2_PAIR3- PEG_RX0+ PEG_TX0+ PEG_RX0- PEG_TX0- PEG_RX1+ PEG_TX1+ PEG_RX1- PEG_TX1- TYPE2# PEG_RX2+ PEG_TX2+ PEG_RX2- PEG_TX2- PEG_RX3+ PEG_TX3+ Jasper User Manual v1.32 www.diamondsystems.com Page 44...
  • Page 45 PEG_TX15+ PEG_RX15- C102 D102 PEG_TX15- C103 D103 VCC_12V C104 D104 VCC_12V VCC_12V C105 D105 VCC_12V VCC_12V C106 D106 VCC_12V VCC_12V C107 D107 VCC_12V VCC_12V C108 D108 VCC_12V VCC_12V C109 D109 VCC_12V C110 D110 Jasper User Manual v1.32 www.diamondsystems.com Page 45...
  • Page 46 Connector PN: QT002206-4131-3H Jasper User Manual v1.32 www.diamondsystems.com Page 46...
  • Page 47: O Connector List & Mating Cables

    COM Express Foxconn QT002206- 220 Position Connector Plug, SMT, Outer Compact 4131-3H Shroud Contacts Surface Mount Gold * Representative part; other manufacturers / part numbers are also acceptable; confirm selection with DSC Jasper User Manual v1.32 www.diamondsystems.com Page 47...
  • Page 48: Jasper Vs Com Module Interface Comparison List

    9 JASPER VS COM MODULE INTERFACE COMPARISON LIST Available on Carrier Board Available on SBC Assembly Interfaces as in COM Winsystems Arbor Specification Models JSP-BBxxx COMET6-110 EmETXe-i92U1 Minicard 1 PCIe Port0 on AB SATA & PCIe Muxed Minicard 2 PCIe Port1 on AB SATA &...
  • Page 49 SATA & PCIe Muxed HD Audio Audio Data acquisition circuit Model JSP-BB03A only GbE Lan Yes (2.5G) Yes (1G) UART 0 1x RS-232 UART 1 1x RS-232 4x GPI & 4x GPO 4x GPI, 4x GPO Jasper User Manual v1.32 www.diamondsystems.com Page 49...
  • Page 50: Mounting Plate

    The plate contains a cutout in the center to fit the standard heat spreader provided by the COM vendor. The COM Express standard defines a standard height for all heat spreaders, enabling the Jasper mounting plate to be used with any compliant COM heat spreader. The mounting pate is 0.9mm taller than the standard heat spreader height to allow for installing a 1mm thick thermal pad between the heat spreader and the enclosure surface for improved thermal conductivity.
