Summary of Contents for Diamond Systems JASPER

  • Page 1 JASPER COM Express Type 6 Carrier Board and SBC User Manual Revision No Release Date Comments 02/08/2023 Initial release 05/03/2023 General text and image updates FOR TECHNICAL SUPPORT PLEASE CONTACT: © Copyright 2023 Diamond Systems Corp. Email: support@diamondsystems.com www.diamondsystems.com...
  • Page 2: Table Of Contents

    Contents Important Safe Handling Information ......................4 Introduction ..............................6 Jasper Product Overview ..........................6 Baseboard Variants ............................8 Jasper Ordering Guide ..........................8 Product Photos ............................. 9 Functional Overview ............................11 COM Express Carrier System ........................11 Power Supply Specifications ........................11 Ethernet Ports .............................
  • Page 3 7.20 COM Express type 6 Compact / Basic connector Pinout (J28 & J30) ............32 I/O Connector List ............................37 Specifications ..............................38 10 Limited Warranty............................39 Jasper User Manual V1.2 www.diamondsystems.com Page 3...
  • Page 4: Important Safe Handling Information

    Diamond Systems recommends that all its boards be stored only in individual ESD-safe packaging units. If multiple boards are stored together, they should be contained in bins with dividers placed between the boards.
  • Page 5 Overvoltage on Analog Input: If a voltage applied to an analog input exceeds the power specification of the board, the input multiplexer and/or parts behind it can be damaged. Most Diamond Systems boards will withstand an erroneous connection of up to 36V on the analog inputs, even when the board is powered off, but not on all boards, and not under all conditions.
  • Page 6: Introduction

    A special feature of Jasper is that most I/O connectors are located along the front edge. This makes it possible to design and build I/O boards that mate directly to Jasper without the use of cables, to reduce size and increase ruggedness for rugged systems applications.
  • Page 7 Conduction cooling with bottom side heat spreader (target heat spreader height 13mm as per Cooling Mechanism COM express specification) Power Input Range 18V-36V wide range input or Fixed 12V +/-10% supply Operating -40°C to +85°C ambient (final system capability depends on the COM installed) Temperature Range Jasper User Manual V1.2 www.diamondsystems.com Page 7...
  • Page 8: Baseboard Variants

    Jasper COM Carrier, low cost model, 18-36VDC In JSP-BB02D Jasper COM Carrier, PCIe/104 expansion, Digital I/O, 18-36VDC In JSP-BB03A Jasper COM Carrier, PCIe/104 and Data Acquisition, 18-36VDC In 6882210 Mounting Plate for Jasper Carrier (included with the carrier board) Jasper User Manual V1.2 www.diamondsystems.com Page 8...
  • Page 9: Product Photos

    2.4 Product Photos Figure 2-1: COM module installation side (Bottom) Figure 2-2: I/O expansion side Jasper User Manual V1.2 www.diamondsystems.com Page 9...
  • Page 10 Figure 2-3: Side view showing COM Express module and heat spreader Figure 2-4: Bottom view showing Basic size COM heat spreader nested in mounting plate Jasper User Manual V1.2 www.diamondsystems.com Page 10...
  • Page 11: Functional Overview

    3.4 PCIe Link Routing Jasper x1 PCIe port mapping is provided below. The carrier board routes the PCIe x16 lanes from the COM Express CD connector to the PCIe104 connector banks 2 and 3. Lane 0 – Minicard Socket1 Lane 1 –...
  • Page 12: Usb

    PCIe/SATA interface is supported depending on the type of minicard module inserted. 3.6 USB Jasper supports 2 USB2.0 ports and 3 USB 3.0/USB 2.0 ports from the COM. 2 x USB2.0 ports are routed to one 2x5 headers and 3x USB 3.0 ports are routed to three nos of 2x5 headers.
  • Page 13: Data Acquisition

    For half-size minicards the board contains mounting locations with threaded inserts and a hardware kit to attach one standoff and screw for each minicard. 3.17 PCIe104 Expansion The board contains a PCIe104 Type 1 full-size expansion socket with 22mm stacking height. Jasper User Manual V1.2 www.diamondsystems.com Page 13...
  • Page 14: Led Indicators

    One of the USB2.0 is muxed with minicard and PCIe104 and can be selected using jumper configuration at JP3. 3.18 LED Indicators Jasper provides the following LED indicators. All LEDs are located near a board edge or their respective features. All LEDs are labeled in silkscreen with their function.
  • Page 15: Block Diagram

    4 BLOCK DIAGRAM The following Block Diagram illustrates the key functional block of the JASPER COM Express Carrier board. Figure 4-1: JASPER COM Express Carrier Board Block Diagram Jasper User Manual V1.2 www.diamondsystems.com Page 15...
  • Page 16: Mechanical Drawing

    5 MECHANICAL DRAWING Below Figures Depict the Top and Bottom Mechanical view of the Jasper board. Figure 5-1: Mechanical Top View Jasper User Manual V1.2 www.diamondsystems.com Page 16...
  • Page 17 Figure 5-2: Mechanical Bottom View Jasper User Manual V1.2 www.diamondsystems.com Page 17...
  • Page 18: Connector And Jumper Location

    6 CONNECTOR AND JUMPER LOCATION Figure 6-1: COM module installation side Jasper User Manual V1.2 www.diamondsystems.com Page 18...
  • Page 19: Jumper Selection

    Figure 6-2: I/O expansion side 6.1 Jumper Selection The Jumper blocks on the Jasper board can be configured to enable/disable or alter the default signal routing settings on the circuit, using Jumper shunts. The following table describes the Jumper Blocks on the baseboard.
  • Page 20 Jumper Block JP4 Port RS232 RS485 RS422 Internal Loop Position 1&2 1&2 OUT* 3&4 3&4 OUT* *Default Mode Applicable only for 8242211 model. JP4 Jumper is software overridden by FGPA for 8242212 model. Jasper User Manual V1.2 www.diamondsystems.com Page 20...
  • Page 21 *Default Mode Jumper Block JP7 Function Position Serial Port1 TX Termination Enabled Disabled* Serial Port1 RX Termination Enabled Disabled* Serial Port2 TX Termination Enabled Disabled* Serial Port2 RX Termination Enabled Disabled* *Default Mode Jasper User Manual V1.2 www.diamondsystems.com Page 21...
  • Page 22: Connector Pinout Specifications

    External fan can be connected to conduct heat in a better way. Fan PWM Fan Tach Fan PWR (5V/12V) Connector part no.: Molex 0532610471 4 pin Right Angle Surface Mount shrouded pin header Recommended Fan part number: ASB0305HP-00CP4 Connector part number: Molex 0532610471 Jasper User Manual V1.2 www.diamondsystems.com Page 22...
  • Page 23: Ethernet (J23 & J24)

    USB1 Data+ USB0 Data+ USB1 Data- USB0 Data- USB1 Pwr+ USB0 Pwr+ Connector: FCI 98464-G61-10ULF latching 2x5 2mm pitch RA shrouded pin header Connector part number: FCI 98464-G61-10ULF Mating Cable: DSC # 6980602 Jasper User Manual V1.2 www.diamondsystems.com Page 23...
  • Page 24: Usb 3.0 Ports (J14, J20 & J21)

    D3+ Even D3- Odd D3- Even Ground Ground DDC CLK DDC DATA Connector: Molex 5011903027 1mm pitch vertical shrouded pin header Connector part number: Molex 5011903027 Mating Cable: Custom depending on the target display Jasper User Manual V1.2 www.diamondsystems.com Page 24...
  • Page 25: Lcd Backlight (J29)

    Connector part number: FCI 98464-G61-20ULF Mating Cable: DSC # 6980605 (J17): FCI 98414-F06-20ULF latching 2x10 2mm pitch vertical shrouded pin header on the left edge of board. Connector part number: FCI 98414-F06-20ULF Mating Cable: DSC # 6980605 Jasper User Manual V1.2 www.diamondsystems.com Page 25...
  • Page 26: Vga (J2)

    RX1- TX2+ TX2- RX2+ RX2- RS-485 (SP336) TX1/RX1+ TX1/RX1- TX2/RX2+ TX2/RX2- Connector: FCI 98464-G61-10ULF latching 2x5 2mm pitch right angle shrouded pin header Connector part number: FCI 98464-G61-10ULF Mating Cable: DSC # 6980601 Jasper User Manual V1.2 www.diamondsystems.com Page 26...
  • Page 27: Socket (J15)

    +3.3V +3.3V +3.3V SATA_RX+/ PCIe RX- SATA_RX-/PCIe RX+ SATA_TX-/PCIe TX- SATA_TX+/PCIe TX+ PERST# PCIe CLKREQ# PCIe REFCLK- PCIe WAKE# PCIe REFCLK+ +3.3V +3.3V +3.3V Connector part number: 10128798-005RLF Mating Cable: DSC # TBD Jasper User Manual V1.2 www.diamondsystems.com Page 27...
  • Page 28: Sata (J9)

    DIO C1 DIO C2 DIO C3 DIO C4 VIO (fused) Digital Ground Connector Type: FCI 98414-G06-30LF latching 2x15 2mm pitch vertical shrouded pin header Connector part number: FCI 98414-G06-30LF Mating Cable: DSC # TBD Jasper User Manual V1.2 www.diamondsystems.com Page 28...
  • Page 29: Utility (J27)

    GPI3 is muxed with the TPM IRQ and is available as general purpose input to the COM module by default. GPI0 GPO0 GPI1 GPO1 GPI2 GPO2 GPI3 GPO3 3.3V Fused 0.5A Connector Type: FCI 98414-G06-10LF latching 2x5 2mm pitch vertical shrouded pin header Jasper User Manual V1.2 www.diamondsystems.com Page 29...
  • Page 30: Pcie Mini Card (J11 & J12)

    PCIe RX-/SATA +3.3V PCIe RX+/SATA +1.5V SMB Clk SMB Data PCIe TX-/SATA TX- PCIe TX+/SATA TX+ USB D- USB D+ +3.3V +3.3V Ground +1.5V +3.3V Connector part number: 1759547-1 Mating Cable: DSC # TBD Jasper User Manual V1.2 www.diamondsystems.com Page 30...
  • Page 31: Pcie104 Connector (J1)

    PEx16 Tx11- PEx16 Tx3- Ground Ground PEx16 Tx12+ PEx16 Tx4+ PEx16 Tx12- PEx16 Tx4- Ground Ground PEx16 Tx13+ PEx16 Tx5+ PEx16 Tx13- PEx16 Tx5- Ground Ground PEx16 Tx14+ PEx16 Tx6+ PEx16 Tx14- PEx16 Tx6- Jasper User Manual V1.2 www.diamondsystems.com Page 31...
  • Page 32: Com Express Type 6 Compact / Basic Connector Pinout (J28 & J30)

    This is a 2-connector set. The first connector consists of rows A and B, while the second connector consists of rows C and D. GBE0_MDI3- GBE0_ACT# GBE0_MDI3+ LPC_FRAME# GBE0_LINK100# LPC_AD0 GBE0_LINK1000# LPC_AD1 GBE0_MDI2- LPC_AD2 Jasper User Manual V1.2 www.diamondsystems.com Page 32...
  • Page 33 USB1- USB0+ USB1+ VCC_RTC SYS_RESET# LPC_SERIRQ CB_RESET# PCIE_TX5+ PCIE_RX5+ PCIE_TX5- PCIE_RX5- GPI0 SD_CMD PCIE_TX4+ PCIE_RX4+ PCIE_TX4- PCIE_RX4- SD_WP PCIE_TX3+ PCIE_RX3+ PCIE_TX3- PCIE_RX3- PCIE_TX2+ PCIE_RX2+ PCIE_TX2- PCIE_RX2- GPI1 SD_CD# PCIE_TX1+ PCIE_RX1+ PCIE_TX1- PCIE_RX1- WAKE0# Jasper User Manual V1.2 www.diamondsystems.com Page 33...
  • Page 34 A105 B105 VCC_12V VCC_12V A106 B106 VCC_12V VCC_12V A107 B107 VCC_12V VCC_12V A108 B108 VCC_12V VCC_12V A109 B109 VCC_12V A110 B110 USB_SSRX0- USB_SSTX0- USB_SSRX0+ USB_SSTX0+ USB_SSRX1- USB_SSTX1- USB_SSRX1+ USB_SSTX1+ USB_SSRX2- USB_SSTX2- USB_SSRX2+ USB_SSTX2+ Jasper User Manual V1.2 www.diamondsystems.com Page 34...
  • Page 35 DDI2_PAIR2+ DDI2_PAIR2- DDI2_PAIR3+ DDI2_PAIR3- PEG_RX0+ PEG_TX0+ PEG_RX0- PEG_TX0- PEG_RX1+ PEG_TX1+ PEG_RX1- PEG_TX1- TYPE2# PEG_RX2+ PEG_TX2+ PEG_RX2- PEG_TX2- PEG_RX3+ PEG_TX3+ PEG_RX3- PEG_TX3- PEG_RX4+ PEG_TX4+ PEG_RX4- PEG_TX4- PEG_RX5+ PEG_TX5+ PEG_RX5- PEG_TX5- PEG_RX6+ PEG_TX6+ PEG_RX6- PEG_TX6- Jasper User Manual V1.2 www.diamondsystems.com Page 35...
  • Page 36 PEG_TX15- C103 D103 VCC_12V C104 D104 VCC_12V VCC_12V C105 D105 VCC_12V VCC_12V C106 D106 VCC_12V VCC_12V C107 D107 VCC_12V VCC_12V C108 D108 VCC_12V VCC_12V C109 D109 VCC_12V C110 D110 Connector part number: QT002206-4131-3H Jasper User Manual V1.2 www.diamondsystems.com Page 36...
  • Page 37: O Connector List

    Standard Molex 0678005025 Cable 52-pin Minicard, full size, with PCB mount PCIe Minicard 1759547-1 threaded spacers COM Express Foxconn QT002206- 220 Position Connector Plug, SMT, Outer Shroud Compact 4131-3H Contacts Surface Mount Gold Jasper User Manual V1.2 www.diamondsystems.com Page 37...
  • Page 38: Specifications

    9 SPECIFICATIONS The Jasper board specifications are summarized in the following table. Feature Brief Description Module Jasper COM Express Type 6 Carrier Board Display 2x HDMI 1x VGA (Based on the COMe module) 1x Dual Channel 24-bit LVDS port with 3.3V / 5V power option...
  • Page 39: Limited Warranty

    10 LIMITED WARRANTY Diamond Systems Corporation warrants that its products will be free from defects and errors in material and workmanship and perform in full accordance with the technical specifications stated in the description of the product for a duration of 2-Year Period from the Date of Shipment.
