EPS-24G4X Carrier Board
Ethernet Switch Module: 4x 10G SFI, 24x GbE
Revision No
1.0
FOR TECHNICAL SUPPORT
PLEASE CONTACT:
www.diamondsystems.com/support/
Site:
Email:
support@diamondsystems.com
User Manual
Release Date
Comments
09/10/2021
Initial Release
© Copyright 2021
Diamond Systems Corporation
158 Commercial Street
Sunnyvale, CA 94086 USA
Tel 1-650-810-2500
Fax 1-650-810-2525
www.diamondsystems.com
Advertisement
Table of Contents
Related Manuals for Diamond Systems EPS-24G4X
Summary of Contents for Diamond Systems EPS-24G4X
- Page 1 EPS-24G4X Carrier Board Ethernet Switch Module: 4x 10G SFI, 24x GbE User Manual Revision No Release Date Comments 09/10/2021 Initial Release FOR TECHNICAL SUPPORT PLEASE CONTACT: © Copyright 2021 www.diamondsystems.com/support/ Site: Diamond Systems Corporation Email: support@diamondsystems.com 158 Commercial Street Sunnyvale, CA 94086 USA...
-
Page 2: Table Of Contents
Access Management Commands ...................... 28 Access-List Commands ........................29 Logging Commands ........................... 29 Spanning Tree Commands ........................ 29 Green-Ethernet Commands ....................... 30 Thermal-Protect Commands ......................31 QoS Commands ..........................31 Privilege Commands .......................... 32 EPS-24G4X Carrier Board www.diamondsystems.com Page 2 User Manual V1... - Page 3 Web Interface Activation/Deactivation ....................48 Firmware Upgrade ..........................49 Saving the Startup Configuration ....................... 49 Factory Default Settings ........................50 13. Techincal Specifications ..........................51 14. Limited Warranty Policy ..........................52 EPS-24G4X Carrier Board www.diamondsystems.com Page 3 User Manual V1...
-
Page 4: Important Safe Handling Information
Diamond Systems recommends that all our boards be stored only in individual ESD-safe packaging units. If multiple boards are stored together, they should be contained in bins with dividers placed between the boards. - Page 5 If a Digital I/O Line of 12V to 24V is connected to a 5V logic chip, the chip will be damaged, and the damage could extend to other chips in the circuit. IMPORTANT! Always check twice before Powering Up! EPS-24G4X Carrier Board www.diamondsystems.com Page 5 User Manual V1...
-
Page 6: Introduction
2. INTRODUCTION The EPS-24G4X is a Carrier Board for the EPSM-10GX4 Ethernet switch module based on VSC7448. It provides access to all features of the module and can be used both for validation of the module’s features and as a product. - Page 7 Telnet and SSH Network Protocol functionalities. Includes complete WebstaX Features and Layer 3 (L3) Routing functionality. Adds support for IEEE 1588/PTP Timing, Telnet and SSH IStaX™ Network Protocol functionalities, and Linear/Ring Protection, including ERPS. EPS-24G4X Carrier Board www.diamondsystems.com Page 7 User Manual V1...
-
Page 8: Functional Overview
3x QSGMII ports. VSC8512 PHY Additional 12x 1G copper ports are derived by VSC8512 PHY on EPS-24G4X carrier via 3x QSGMII interface from the module. The VSC8512 is a low-power 12-port Gigabit Ethernet Transceiver with low Electromagnetic Interference (EMI) line driver and integrated line side termination resistors that conserve both power and space. -
Page 9: Precision Time Protocol Clock
The EPS-24G4X Carrier Board is equipped with a 3-pin Latching Connector Serial Interface on J11. Power Supply The EPS-24G4X is powered through an 8-pin Latching Power Input Connector J14 that uses a +7VDC to +34VDC wide-range power supply unit. Overvoltage protection is provided using onboard TVS diode. -
Page 10: Mechanical Drawing
4. MECHANICAL DRAWING Figure 8-3 delineates the Top View Mechanical Dimensions of the EPS-24G4X Carrier Board. Figure 4-1: Dimensions of EPS-24G4X Carrier Board Figure 8-4 delineates the Mechanical Dimensions of the EPSM-10GX4 and EPS-24G4X Assembled Modules with customized Heat Sink. -
Page 11: Board Layout
5. BOARD LAYOUT The following image displays the Top Layout of the EPS-24G4X Carrier Board with Jumper Locations. A description of the Key Integrated Circuits and Connectors is tabulated below. Figure 5-1: EPS-24G4X Carrier Board Top View J-Pin Connector Locations... -
Page 12: I/O Connectors
Connector Pin-out and Signal Description High-speed B2B Connectors: J1 and J2 The EPS-24G4X Carrier Board contains 2x 120 pin 0.5mm pitch high-speed connectors that accommodate 12x 1 Gbps copper ports, 3x QSGMII ports, 2x 10G ports, power, and other sideband signals. These connectors mate with the EPSM-10GX4 main module. - Page 13 RTX6CP RTX6AP GND_SIGNAL GND_SIGNAL RTX7DN RTX7BN RTX7DP RTX7BP GND_SIGNAL GND_SIGNAL RTX7CN RTX7AN RTX7CP RTX7AP PPS-0 RTX8DN RTX8BN RTX8DP RTX8BP RTX8CN RTX8AN RTX8CP RTX8AP UART_RXD UART_TXD PPS-1 DB CONFIG1 DB CONFIG2 /MR_RST EPS-24G4X Carrier Board www.diamondsystems.com Page 13 User Manual V1...
- Page 14 Table 6-1: J2 Connector Signal Description Connector on EPS-24G4X Carrier: Samtec ERM5-060-05.0-L-DV Mating Connector on EPSM-10GX4 Module: Samtec ERF5-060-05.0-L-DV-K Signal Signal Pin No. Pin No. GND_SIGNAL GND_SIGNAL SFPPLUSA_RXD_N SFPPLUSB_RXD_N SFPPLUSA_RXD_P SFPPLUSB_RXD_P GND_SIGNAL GND_SIGNAL SFPPLUSA_TXD_N SFPPLUSB_TXD_N SFPPLUSA_TXD_P SFPPLUSB_TXD_P GND_SIGNAL GND_SIGNAL B_PCIE_T_P...
- Page 15 GND_SIGNAL SFPPLUS_C_TXD_N SFPPLUS_D_TXD_N SFPPLUS_C_TXD_P SFPPLUS_D_TXD_P GND_SIGNAL GND_SIGNAL RTX10DN RTX10BN RTX10DP RTX10BP GND_SIGNAL GND_SIGNAL RTX10CN RTX10AN RTX10CP RTX10AP GND_SIGNAL GND_SIGNAL RTX11DN RTX11BN RTX11DP RTX11BP GND_SIGNAL GND_SIGNAL RTX11CN RTX11AN RTX11CP RTX11AP GND_SIGNAL GND_SIGNAL EPS-24G4X Carrier Board www.diamondsystems.com Page 15 User Manual V1...
-
Page 16: Cpld Programming Header: J18
CPLD Programming Header: J18 The EPS-24G4X Carrier Board integrates a CPLD to implement the Ethernet LED Logic The LED status signals on the Main Board are transmitted through a serial bus over high-speed B2B connector. The following Table describes the pin and signal specifications of the CPLD Programming Header. -
Page 17: Serial Interface: J11
RXD (Input) Power Input: J14 The EPS-24G4X Carrier Board operates on a wide range of power supply of +7V to +34VDC. Power is supplied through an 8-pin Latching Connector. The pin-out description for input power is shown below. Connector Number: Samtec ASP -194529.2x2.54mm Right Angle... -
Page 18: Led Connector: J22
LED Connector: J22 The EPS-24G4X Carrier Board contains 24 Port LED Connector, LED signals operates on 3.3V 50-pin Latching Connector. Connector Number: Molex 501571-5007 Right Angle Housing: 5011895010 Crimp Terminal: 501193-5000 Pin Signal Pin No. Port Nos Signal R_G_P1 R_Y_P1... -
Page 19: Cable Kit
7. CABLE KIT Cable Kit: 6981508 Quad Ethernet cable-6 Nos 6980512 Power cable 6981050 Serial cable EPS-24G4X Carrier Board www.diamondsystems.com Page 19 User Manual V1... -
Page 20: Assembling Or Disassembling Module
1. The following Figure depicts the BOTTOM view of the EPSM-10GX4 Module. Figure 8-1: EPSM-10GX4 Module B2B Connectors 2. The following Figure depicts the TOP view of the EPS-24G4X Carrier Board. The Connectors marked J1 and J2 correspond to the Connectors marked J1 and J2 on the EPSM-10GX4 Board depicted above. - Page 21 The following Figure shows the Top View of the assembled unit after the Main Board and the EPS-24G4X Carrier Board connectors are locked-in. Figure 8-3: EPSM-10GX4 + EPS-4G4X Module Assembled EPS-24G4X Carrier Board www.diamondsystems.com Page 21 User Manual V1...
-
Page 22: Getting Started
4. Connect a LAN cable between the PC to any one of the desired ports on the cable(s) connected to the EPS-24G4X Switch as instructed in Step 3 5. Connect the power cable Part Number 6980512, from the connector J14 to a regulated power supply with +12V nominal or +7V to +34V. -
Page 23: Using The Cli Interface
To access CLI, the User must be authenticated. On system prompt: • Enter a user name and password, which can be configured. • Enter exit command to Log out at any time and at any context level. EPS-24G4X Carrier Board www.diamondsystems.com Page 23 User Manual V1... -
Page 24: Accessing Help
Negate a command or set its defaults ping Send ICMP echo messages reload system send Send a message to other tty lines show Show running system information terminal Set terminal line parameters # EPS-24G4X Carrier Board www.diamondsystems.com Page 24 User Manual V1... -
Page 25: Resetting System To Factory Defaults
# show ip http server secure status 2. To disable Secure HTTP Web Redirect and Secure HTTP Web Server: (config)# no ip http secure redirect (config)# no ip http secure server EPS-24G4X Carrier Board www.diamondsystems.com Page 25 User Manual V1... -
Page 26: Mac Commands
} [ interface ( <port_type> [ <v_port_type_list> ] ) ] } | { address <v_mac_addr> [ vlan <v_vlan_id> ] } | vlan <v_vlan_id_1> | interface ( <port_type> [ <v_port_type_list_1> ] ) ] EPS-24G4X Carrier Board www.diamondsystems.com Page 26 User Manual V1... -
Page 27: Vlan/Pvlan Commands
(config)# dot1x timeout quiet-period <v_10_to_1000000> (config)# dot1x timeout tx-period <v_1_to_65535> (config)# no dot1x authentication timer inactivity (config)# no dot1x authentication timer re-authenticate (config)# no dot1x re-authentication (config)# no dot1x system-auth-control (config)# no dot1x timeout quiet-period EPS-24G4X Carrier Board www.diamondsystems.com Page 27 User Manual V1... -
Page 28: Lacp Commands
VLAN ID, Start IP Address, End IP Address can be set. The commands can also be issued to define the WEB, SNMP or TELNET Interface from which the Host can access the Switch. To accomplish this, the Host IP address must match the IP address entered in the syntax. EPS-24G4X Carrier Board www.diamondsystems.com Page 28... -
Page 29: Access-List Commands
If the number is exceeded, the transmission of the next BPDU will be delayed. The following command syntaxes can be used to enable or disable Spanning Tree mode. EPS-24G4X Carrier Board www.diamondsystems.com Page 29... -
Page 30: Green-Ethernet Commands
To set the interval at which the LED’s intensity will correspond to a specified intensity: (config)# green-ethernet eee optimize-for-power (config)# green-ethernet led interval <v_0_to_24> intensity <v_0_to_100> (config)# green-ethernet led on-event { [ link-change <v_0_to_65535> ] [ error ] }*1 EPS-24G4X Carrier Board www.diamondsystems.com Page 30 User Manual V1... -
Page 31: Thermal-Protect Commands
# show qos [ { interface [ ( <port_type> [ <port> ] ) ] } | wred | { maps [ dscp-cos ] [ dscp-ingress-translation ] [ dscp-classify ] [ cos-dscp ] [ dscp-egress-translation ] } | storm | { qce [ <qce> ] } ] EPS-24G4X Carrier Board www.diamondsystems.com Page 31... -
Page 32: Privilege Commands
<username> engine-id <engineID> [ { md5 <md5_passwd> | sha <sha_passwd> } [ priv { des | aes } <priv_passwd> ] ] (config)# snmp-server view <view_name> <oid_subtree> { include | exclude EPS-24G4X Carrier Board www.diamondsystems.com Page 32 User Manual V1... -
Page 33: Sntp Commands
Global Timeout to wait for a reply from the RADIUS server before re-transmitting the request. • Global Retransmit number for which RADIUS request is sent to a server that has stopped responding. EPS-24G4X Carrier Board www.diamondsystems.com Page 33 User Manual V1... - Page 34 # show running-config interface ( <port_type> [ <list> ] ) [ all-defaults ] # show running-config interface vlan <list> [ all-defaults ] # show running-config line { console | vty } <list> [ all-defaults ] # show running-config vlan <list> [ all-defaults ] EPS-24G4X Carrier Board www.diamondsystems.com Page 34 User Manual V1...
-
Page 35: Banner Commands
The following syntaxes are used to debug the board. (config)# no debug prompt (config)# line { <0~16> | console 0 | vty <0~15> } # no debug prompt # debug prompt <debug_prompt> EPS-24G4X Carrier Board www.diamondsystems.com Page 35 User Manual V1... -
Page 36: Security Commands
<v_port_type_list> ] ) } | { cpu [ <cpu_switch_range> ] } } POE Commands By default, the EPS-24G4X Carrier Board does not support Power over Ethernet (POE) networking features. However, the Board is POE-enabled which can be implemented via a POE Switch. -
Page 37: Command Parameter And Syntax Examples
Virtual LANs (VLANs) are used to divide the network into separate logical areas. VLANs can also be considered as broadcast domains. The following example depicts VLAN2 and VLAN3 set up with switch port mode set to Access. #configure terminal (config)# vlan 2 (config)# vlan 3 EPS-24G4X Carrier Board www.diamondsystems.com Page 37 User Manual V1... -
Page 38: Snmp Configuration
The following block depicts mirroring of Port 2, Port 3 (RX), and Port 4 traffic through Port 8 (RX) to Port 1. # configure terminal (config)# monitor destination interface GigabitEthernet 1/1 (config)# monitor source interface GigabitEthernet 1/2-3 rx (config)# monitor source interface GigabitEthernet 1/4-8 tx Setting Up QoS EPS-24G4X Carrier Board www.diamondsystems.com Page 38 User Manual V1... -
Page 39: Upgrading The Firmware
# firmware upgrade tftp://<ip_address>/<path>/EPSM-10GX4.mfi Board Detail Commands The User can verify Board details such as the Type and Software Version by entering the syntax shown below. # show board # show version EPS-24G4X Carrier Board www.diamondsystems.com Page 39 User Manual V1... -
Page 40: Using The Web Interface
Upgrade the Software The GUI screens will interchange depending upon the number of connected ports. The Screen below displays the Web Interface for the full-featured EPS-24G4X Board which is equipped with 26 ports. Figure 12-1: EPS-24G4X Carrier Board Home Page EPS-24G4X Carrier Board www.diamondsystems.com... -
Page 41: Web Interface Configuration Examples
Web Interface Configuration Examples IP Configuration To configure the IP address of the Switch: 1. Connect EPS-24G4X Switch to the Web Interface. 2. Navigate to Configuration -> System -> IP screen. 3. Modify the IP Address in the IPv4 Address column. -
Page 42: Changing The System Password
Changing the System Password To change the system login password: 1. Connect EPS-24G4X Switch to the Web Interface. 2. Navigate to Configuration -> Security ->Switch -> Password screen. 3. Enter the Old Password and New Password in the designated fields and click the Save button. - Page 43 Figure 12-4: Changing the System Password EPS-24G4X Carrier Board www.diamondsystems.com Page 43 User Manual V1...
-
Page 44: Vlan Configuration
VLAN Configuration The following example describes how to configure a VLAN. 1. Connect EPS-24G4X Switch to the Web Interface. 2. Navigate to Configuration -> VLANs page. 3. In the Allowed Access VLANs field, enter the number of LANs to be created. -
Page 45: Mirroring Frames Configuration
The following example shows how to mirror the traffic of Port 1 Tx only and 2 Rx only to Port 6. 1. Connect EPS-24G4X Switch to the Web Interface. 2. Navigate to Configuration -> Mirroring page. - Page 46 Figure 12-7: Mirror Frames Screen EPS-24G4X Carrier Board www.diamondsystems.com Page 46 User Manual V1...
-
Page 47: Qos Classification Configuration
2. Under CoS in Port row 3 select 4 from the drop-down list. 3. Under PCP select 1 from the drop-down list. 4. Click the Save button. Figure 12-8: QoS Classification Screen EPS-24G4X Carrier Board www.diamondsystems.com Page 47 User Manual V1... -
Page 48: Web Interface Activation/Deactivation
CLI: #copy running-config startup-config To enable Web access on the Switch, enter the following syntax in CLI: #copy startup-config flash:backup_config #copy flash:{filename} startup-config Reboot the Switch. EPS-24G4X Carrier Board www.diamondsystems.com Page 48 User Manual V1... -
Page 49: Firmware Upgrade
Firmware Upgrade The following section describes the steps for upgrading the firmware. 1. Connect EPS-24G4X Switch to the Web Interface and navigate to Maintenance -> Software -> Upload page. 2. Choose the file to be uploaded and click -> Upload. -
Page 50: Factory Default Settings
Only the IP configuration is retained. The new configuration is executed instantly. The following steps describe resetting the system to factory defaults: 1. Connect EPS-24G4X Switch to the Web Interface. 2. Navigate to Maintenance -> Factory Defaults page. 3. Click the Yes button. -
Page 51: Techincal Specifications
Standalone Network Switch or in Combination with a Host Computer Power Input +7-34V DC/DC power supply; Typ: 12V MTBF 6.142” W x 4.213” H (156 mm x 107 mm) Form factor Operating temp -40°C to +80°C Weight RoHS Complaint EPS-24G4X Carrier Board www.diamondsystems.com Page 51 User Manual V1... -
Page 52: Limited Warranty Policy
14. LIMITED WARRANTY POLICY Diamond Systems Corporation warrants that DSC products will be free from defects and errors in material and workmanship and perform in full accordance with the technical specifications stated in the description of the product for a duration of 2-Year Period from the Date of Shipment.
