6. PURPOSE AND APPEARANCE
OF THE POWER TOOL
Appointment
The rotary hammer is used for a wide
range of construction, repair, dismantling
and assembly works: hammer drilling in
solid materials, drilling holes, corrective
dismantling and mixing construction mix-
tures.
Due to the presence of three modes of
operation (drilling, hammer drilling, chis-
eling), the rotary hammer is a univer-
sal tool that will help to perform a wide
range of work:
– drilling holes in concrete, stone, brick;
– drilling/hammer drilling with crowns in
concrete, brick, tiles;
– corrective disassembly/slotting of con-
crete, bricks, plaster, etc.;
– drilling of metal, wood, tiles, plastic
and other materials;
– mixing construction mixtures.
Appearance RH-16, RH-12, RH-12Q
(Fig. 1)
1 Chuck anther
2 Locking sleeve of the chuck
3 Depth limiter
4 Latch of the mode switch
5 Work mode switch
6 Ventilation holes
7 Rotation direction switch (reverse)
8 Power button fixator
9 Power cord
10 Power button
11 Front auxiliary handle
12 Depth limiter lock button
8
Appearance RH-100, RH-100Q
(Fig. 2)
1 Chuck anther
Quick release cam chuck
2
(in RH-100Q model)
3 Locking sleeve of the chuck
4 Depth limiter
5 Depth limiter lock button
6 Latch of the mode switch
7 Work mode switch
8 Rotation direction switch (reverse)
9 Power button
10 Power button fixator
11 Front auxiliary handle
WA RN IN G!
LLC "DNIPRO M" constantly works
on improving its products and in
this regard reserves the right to
make changes to the appearance,
design, equipment and content of
the original instructions for safety
and operation of the power tool,
without notifying consumers. All
possible changes will be aimed ex-
clusively at the improvement and
modernization of the electric tool.
