Quicksilver 805PH — System & Component Overview and Operation
To move the bow to the port direction push the left button. To move the bow to the starboard
direction, push the right button. Refer to the thruster owner's manual for complete details on the
operation and warranty information.
If your boat comes equipped with an optional exterior helm, you will be able to control the bow
thruster from either location.
To turn off the bow thruster controls, press the on/off switch once.
Bow Thruster
Bow Thruster Movement
Battery switch
Battery
Charging relay
Do NOT test the bow thruster while the boat is out of the
water, unless you are certain that everyone is a safe
distance from the thrust tube.
Never allow the bow thruster to run for longer than 5
seconds with the boat is out of the water.
If 2 control panels are installed at separate helms, never
operate the bow thruster from both panels simultaneously.
Refer to the bow thruster owner's manual for exact battery
33
Thruster
Control panel
requirements
