Quicksilver 805PH Owner's Manual page 39

Quicksilver 805PH — System & Component Overview and Operation
Fishwell Drain / Electric Pumpout
Recirculating Water System Operation
Before operating the system, make sure that the water pickup valve is in the open position. The water
pickup valve can be accessed through the aft cockpit floor hatch, on the starboard side of the bilge. To
fill the fishwell, press the switch marked "FISHWELL AERATOR" on the fish station control panel,
located under the starboard coaming cap. The fishwell overflow drain, located on the aft wall of the
fishwell, allows excess water to flow overboard.
The flow of water into the fishwell can be controlled at the aerator spray head, located on the port
side of the fishwell. To increase the flow of water, turn the spray head counterclockwise. To decrease
the flow, turn the spray head clockwise.
Fishwell Drain / Electric Pumpout
The fish box drain plugs must be installed before
putting your boat in the water.
Water pickup
Shutoff valve
Water pump
Water pickup hose
27
Fishwell drain plug (P&S)
Fishwell drain pickup
Fishwell drain hose
Fishwell macerator
Fishwell drain hose
Fishwell thru hull
Aerator
Overflow drain
Overflow drain hose
Overboard thru hull
