Quicksilver® 805PH — General Information
15. Dash Layout (Standard Boat)
Dash Layout (Optional Equipment)
Please note that operator vision from the helm may be obstructed by high trim angles of the craft,
along with other factors such as outboard engine trim angles, hull trim plane angles, loading and load
distribution, speed & acceleration, transition from displacement to planing mode, sea conditions, rain
and spray, darkness and fog, interior lights, position of tops and curtains, and persons or movable
gear in the operator's field of vision.
13
Helm switch panel
Steering wheel
SC1000 air temperature sensor
Hydraulic steering
Lanyard
Engine key
USB charging port
Helm breaker panel
Engine throttle shift control
SC1000 Tachometer
SC1000 Speedometer
GPS
Bow thruster control
Stereo
Port engine key
Starboard engine key
Active trim keypad
Engine throttle shift control
Zipwake controller
SC1000 port tachometer
SC1000 starboard tachometer
SC1000 speedometer
