When using Mac OS X®
1
Check USB ports
S
tep
Check the USB port on your computer.
USB port
Any USB port may be used.
y
This product can be connected to a USB hub. However, it may not work depending
y
on the power supply capability of the USB hub.
2
Connecting the Mouse
S
tep
Start up your Mac.
y Wait until Mac OS X has started up completely.
Connect the product's USB connector to a USB port on your Mac.
Insert here.
USB port
USB Connector
Carefully check the orientation of the connector and the place where you
will connect the USB connector.
The driver is installed automatically.
Disconnecting the Mouse
„
This product is hot-pluggable. It is possible to disconnect the mouse when Mac OS
X is running.
Operation may become unstable if the mouse is disconnected and
reconnected several times when Mac OS X is running. If this occurs, restart
Mac OS X.
3
S Checking wheel operation
tep
Check that the vertical and horizontal scrolling functions are working correctly in Safari.
Click the Safari icon in the Dock.
Safari will launch.
If Safari is not in the Dock, double-click the Safari icon in the Applications
folder.
Display your favourite web site in Safari and change the size of the window so that
the vertical and horizontal scrollbars appear.
* The sample website used here is the ELECOM homepage.
Scrollbar
Scroll the wheel back and forth.
The mouse is operating normally if the
screen moves up and down as you scroll the
wheel.
In applications that do not support scrolling, the screen will not move when
you scroll the wheel.
Troubleshooting
When the product appears to be malfunctioning
When the mouse pointer on the screen does not move, or moves
„
unstably, when the mouse is moved
 It is possible that the reflectivity of the surface on which this product is being used is not
suitable for an optical mouse. Use this product on a mouse pad that is designed for use with
optical mice.
When the mouse was connected to the USB port, it is possible that the standard Windows
mouse driver did not install correctly and that this product is detected as an unknown device
by Windows®. This product is usually detected as a USB human interface device. If it is detected
as an unknown device, see "Removing an unknown device," and after removing the device
from Device Manager, repeat "Step 2 - Connecting the Mouse" on the front of this sheet.
It is possible that the driver is conflicting with another driver such as that for a laptop touch
pad. To use this product correctly, you must delete the touch pad driver. However, if you delete
this driver, you may not be able to use the touch pad or touch pad functions. Contact the PC
manufacturer for more details.
The wheel moves, but the mouse cursor does not
„
In certain applications that do not support the scrolling function, the mouse cursor will not
move when you move the wheel.
When the computer is turned off while the mouse is connected, the
„
optical sensor unit is still illuminated
If a computer uses standby power, an optical sensor may be illuminated depending on the
computer's specifications. This is due to the design of the computer and does not mean
that the mouse is faulty. Either disconnect the mouse from the computer or disconnect the
computer's power cable from the power outlet. Contact the computer manufacturer for how to
stop the supply of standby power to the mouse without removing the computer's power cable
from the power outlet. (With some computers it is not possible to stop the supply of standby
power.)
Removing an unknown device
If the standard Windows mouse driver did not install correctly and this product is detected as an
unknown device, remove the unknown device from Device Manager, and then repeat "Step 2 -
Connecting the Mouse" on the front of this sheet.
If there are multiple unknown devices, before removing a device, check that it is actually
y
this product. Disconnect the receiver unit and check which unknown device disappears.
The device that disappears is this product.
y If the unknown device does not disappear even after you have deleted the driver
following the instructions below, it is possible that there is something wrong with the
PC. Contact the PC manufacturer.
With the product connected to the PC, follow the procedure below to remove the unknown device.
Display Device Manager.
Windows® 7 and Windows Vista®
y
1. From the [Start] menu, right-click [Computer].
2. Click [Properties].
3. Click [Device Manager].
Windows® XP
y
1. From the [Start] menu, right-click [My Computer].
2. Click [Properties].
3. Click the [Hardware] tab.
4. Click
.
The Device Manager window appears. Right-click the unknown device, and click [Uninstall].
Click .
Disconnect the receiver unit and restart the PC.
Repeat the procedure from "Step 2 - Connecting the Mouse" on the front of this sheet.
Basic specifications
Article No. M-SP1UR Series
Product name Optical Mouse
Windows Vista (up to SP2), Windows XP (SP2 to SP3)
OS
Mac OS X (10.5 to 10.5.8, 10.6 to 10.6.4)
Resolution (dpi) 800
Interface USB
Cable length 1.5 m
Dimensions 91.0(W) x 66.2 (D) x 28.9 (H) mm
Operating temperature/
5 to 40°C, 90% RH max. (no condensation)
humidity
Storing temperature/
-10 to 60°C, 90% RH max. (no condensation)
humidity
- 2 -
B 급 기기 ( 가정용 정보통신기기 )
이 기기는 가정용으로 전자파적합등록을 한 기기로서
주거지역에서는 물론 모든 지역에서 사용할 수 있습니다 .
ELECOM CO., LTD.
1-1 Fushimi-machi 4-Chome Chuoku, Osaka Japan 541-8765
宜麗客 （上海） 貿易有限公司
上海市徐匯区肇嘉浜路 1065 甲号飛雕国際大厦 704 号
電話 : 86-21-33680011
FAX : 86-21-64271706
URL : http://www.elecom-china.com/
ELECOM (SHANGHAI) TRADING CO. , LTD.
Rm 704 , Feidiao International Bldg , 1065 ZhaoJiaBang Rd , Shanghai ,
China 200030
TEL : 86-21-33680011
FAX : 86-21-64271706
URL : http://www.elecom-china.com/
Elecom Korea Co., Ltd.
5F Suam Bldg. 1358-17, Seocho2-dong, Seocho-gu, Seoul 137-862,
Korea
TEL : 1588-9514
FAX : (02)3472-5533
URL : www.elecom.co.kr
Optical mouse
M-SP1URSeries
User's Manual
2nd edition, November 20, 2009
ELECOM Co., Ltd.
• This manual is copyright of ELECOM Co., Ltd.
• Unauthorised copying and/or reproducing of all or part of this manual is prohibited.
• The specifications and appearance of this product may be changed without prior notice for
product improvement purposes.
• ELECOM Co., Ltd. shall bear no responsibility for any and all affects resulting from the use of this product
regardless of the above reasons.
• Export or service transaction permission under the Foreign Exchange and Foreign Trade Control Law
is required in order to export this product or parts of this product that constitute strategic materials or
services.
• Windows and the Windows logo are trademarks of the Microsoft group of companies.
• Mac, Mac OS, and Macintosh are registered trademarks or trademarks of Apple Inc., in the United
States
• Company names, product names, and other names in this manual are generally trademarks or
registered trademarks.
©2009 ELECOM Co., Ltd. All Rights Reserved.
