Bedfont GastroCH4ECK Gastrolyzer Manual page 4

9
The test will automatically stop after 3 seconds or when it is
manually ended
11
A green happy face indicates a successful test
13
Allow the Patient to throw away their used mouthpiece
15
The external surfaces of the GastroCH ECK® and the
4
For a full list of recommended cleaning wipes and solutions, please visit:
https://www.bedfont.com/cleaning-bedfont-monitors
10
The final results will be shown on screen, Note the results
now if recording manually. Press the question mark icon for
a visual indicator of the results
12
If a red unhappy face is displayed, it is recommended to
retake the test.
14
Results can be interpreted using the Gastrolyzer®
interpretation wheel
sample line should be wiped down before and after each test.
How to collect a face mask breath sample:
1
Place the white clamps on the breath bag and leave one open
3
It is best practice for the patient to insert a facemask
adapter into the inlet of the breath bag and a facemask into
the adapter
5
Once the breath bag is full, the patient should firmly close the
clamp at the top; a click will be audible
7
Place a blue plug into the inlet of the breath bag to secure the
breath sample
2
Insert a plug into the end of the bag with the closed clamp
4
The Patient should exhale into the breath bag via the face
mask until it is full
6
Once the clamp is firmly closed, remove the facemask and
adapter from the breath bag
