Assa Abloy 6100 Series Installation Instructions

6100 & 6150 Series
Double Cylinder Latchead Assembly Exit Device
Installation Instructions
For use with Rim 6100 and SquareBolt
and 626F Keyed Trim.
1. Follow 626F trim installation instructions from the Rim Exit Device Installation Manual and Trim Kit Instructions.
2. Once the trim assembly is complete, continue with Double Cylinder Installation Instructions on page 2.
Level
WARNING
This product can expose you to lead which is known to the state of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.P65warnings.ca.gov.
WARNING
Attention Installer: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening,
and ASSA ABLOY makes no representations or warranties concerning what such impact may be in any specific situation. When
retrofitting any portion of an existing fire-rated opening, or specifying and installing a new fire-rated opening, please consult with a
code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
1-855-557-5078 • www.assaabloy.com
Copyright © 2015, 2024, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
Tools Required
Drill & Bits
Safety Glasses
Phillips
Head
®
6150 Series Double Cylinder Exit Device
80-9460-6007-000 01/24
